Telephone

254

L

Telephone

GENERAL INFORMATION

Note: The vehicle telephone system is
designed to function with a wide variety of
Bluetooth telephones. As these telephones
have a wide range of audio and echo
performance characteristics, it may take a few
seconds for the vehicle telephone system to
adapt and deliver optimum audio performance.
It may be necessary to reduce the in-vehicle
volume slightly to fully optimise audio
performance and reduce echo.

Note: The vehicle's Bluetooth telephone
system can be used with an appropriate
Bluetooth-equipped mobile telephone.

Note: Please refer to your Land Rover
Dealer/Authorised Repairer for a list of
compatible telephones.

Telephone networks

The Telephone network standard allows you to
use your telephone in many countries.

However, telephone reception may be poor or
unavailable in remote regions. This may be due
to the inadequate power of the transmitter,
which results in a weak signal or incomplete
coverage.

WARNINGS

Using the telephone near the car: do not
telephone inside a garage or near an

open car bonnet. The air may contain fuel
vapours and the telephone could produce
sparks and start a fire.

Unusual ambient conditions: Switch off
the telephone in areas where high

explosives are being used. High frequency
remote controls could be interfered with and
cause an explosion. Switch off your telephone
in areas with a high explosion risk. This
includes filling stations, fuel storage areas or
chemical factories, as well as places where the
air contains fuel vapour, chemicals or metal
dust. The telephone might possibly produce
sparks and cause a fire or explosion.

Medical equipment: The functioning of
cardiac pacemakers or hearing aids

may be impaired when the phone is in use.
Check with a doctor or manufacturer whether
any such devices you or your passengers are
using are sufficiently protected against
high-frequency energy.

Always stow your mobile phone
securely. In an accident loose items can

cause injury.

255

Telephone

R

TELEPHONE CONTROLS

1. Call status icon

• Indicates whether the telephone is in

use.

2. Paired telephone name

• The name of the telephone which is

paired to the vehicle system.

3. Clock

4. Telephone mode button

• Press to enable operation of telephone.

(Press and hold to switch telephone
operation off).

5. MENU button

• Press to enter the telephone main menu.

6. EXIT button

• Press to exit a menu or to delete entered

numbers.

7. ENTER button

• Rotate to select menu options. Press to

confirm selections.

8. Keypad

• Use to enter numbers. Also used to

select phonebook letters.

9. On or off or volume button

• Rotate (when in Ring Volume menu) to

adjust the ring volume.

Ericsson T39

14 : 54

E83781

7

5

6

4

8

1

2

3

9

Telephone

256

L

 Telephone controls - Steering wheel

1. Answer call or dial switch

• Pull the switch towards the steering

wheel to answer an incoming call, or to
view the list of the last 10 dialled
numbers (if the audio unit is in
telephone mode). A second pull of the
switch will dial the highlighted number.
Pull and hold the switch (for
approximately two seconds) to activate
voice tag dialling.  See TELEPHONE
VOICE CONTROL (page 270).

2. End or reject call switch

• Pull the switch towards the steering

wheel to end the current call or reject an
incoming call.

3. Menu next button

• Press to scroll down through a menu.

4. Menu previous button

• Press to scroll up through a menu.

5. To leave the menu press the EXIT button.

BLUETOOTH SETUP

Before you can use your telephone with your
vehicle it must be paired to the vehicle
telephone system.

When pairing a Bluetooth telephone with the
vehicle system make sure that the telephone is
switched on, Bluetooth is enabled and
discoverable, its battery is fully charged and
the telephone User’s Handbook is available.

Note: A maximum of five pairings can be made
to the vehicle, but only one telephone can be
used at any time.

Pairing a telephone to the system

Your Bluetooth mobile telephone pairing or
discovery process will also be described in
your mobile telephone User's Handbook.

1. Make sure the telephone to be paired is

within 10 metres (30 feet) of the vehicle.

2. With the vehicle ignition on, press the

telephone mode button on the audio unit.
The system will search for the last
connected telephone. If a telephone is not
detected, the system will ask if you want to
pair. Briefly press the ENTER button. If you
do not want to pair a telephone, press the
EXIT button.

3. The audio unit display will show a message

to make sure that your Bluetooth telephone
is switched on. Briefly press the ENTER
button. The system will then start a search
for your telephone.

4. After the search is completed, a list of all

telephones found will be displayed on the
audio unit screen. If more than one
telephone is found, rotate the ENTER
button to move up or down the list to
select your telephone and then press the
ENTER button.

4

3

2

1

E83782

257

Telephone

R

5. The audio unit will now display a Bluetooth

access code number which must be
entered into your telephone.

6. A message on the audio unit display will

confirm the system is connecting with
your telephone. When it is successfully
connected, the telephone will be paired
and connected with the vehicle and can
now be used with the vehicle telephone
system.

7. If the pairing fails, a message will appear

on the audio unit display; press the ENTER
button to retry or press the EXIT button
and restart the process.

8. The last connected telephone will be

available for use when the system and
telephone are switched on again.

9. If you wish to pair additional telephones,

repeat the process.

Adding or changing a telephone

1. Select the telephone main menu.  See

TELEPHONE SETUP (page 258).

2. Select Bluetooth, then select the option to

change a telephone.

3. Add new phone will appear at the top of

the list. Repeat the procedure for pairing a
telephone to the system.

If the maximum number of telephones are
already paired to the system, a message will be
displayed and you are given the option to
remove one. This must be carried out before a
new telephone can be paired.

Removing a telephone from the system

1. Select the telephone main menu.  See

TELEPHONE SETUP (page 258).

2. Select Bluetooth, then select the option to

remove a telephone.

3. Select a telephone by rotating the ENTER

button, highlight the telephone to be
removed then press the ENTER button. A
confirmation message to remove a
telephone will appear on the audio unit
display, press the ENTER button.

4. The remove telephone screen will be

displayed, and if no further telephones are
to be removed, press the EXIT button.

Loss of Bluetooth link

If the link between the telephone and the
vehicle is lost, you have the choice to
reconnect or to exit from the telephone system.
To reconnect press the ENTER button. There
will be a short delay whilst the connection is
established and then your telephone name will
be shown in the display.

Alternatively, press the EXIT button if you do
not wish to reconnect your telephone.
