19. WARNING: Make sure that new nuts are installed. CAUTION: Make sure that the ball joint ball does not rotate. Connect both front stabilizer bar links to the stabilizer Torque: 55 Nm 19. 20. NOTE: RH illustration shown, LH is similar. Install both the fender splash shield extension panels. 20. Install the front wheels and tires. Refer to: Wheel and Tire (204-04 W heels and Tires, Removal and Installation). 21. Install the 2 bolts securing the transmission mounting Torque: 175 Nm 22. Remove the engine support. 23. Install the starter motor. Refer to: Starter Motor (303-06B Starting System - TD4 2.2L Diesel, Removal and Installation). 24. Install the gear selector assembly. Refer to: Gearshift Linkage (308-06 Manual Transmission/Transaxle External Controls, Removal and Installation). 25. |
