1.

CAUTION: Take extra care not to damage the

seal.

Special Tool(s):

307-595

1.

Install the power transfer unit.

Refer to:

Power Transfer Unit - TD4 2.2L Diesel, Vehicles With: M66

6-Speed Manual Transmission AWD

 (308-07B Transfer Case,

Removal and Installation).

2.

Manual Transmission/Transaxle - Transmission

Removal

Special Tool(s)

205-754A
Splitter, Ball Joints

211-316
Separator, Ball Joint

General Equipment

Powertrain Jack

Remove the battery tray.

Refer to:

Battery Tray

 (414-01 Battery, Mounting and Cables,

Removal and Installation).

1.

2.

WARNING: Make sure to support the vehicle with axle

stands.

Raise and support the vehicle.

2.

Siphon the fluid from the power steering reservoir.

3.

4.

WARNING: Make sure that a new steering

column flexible coupling bolt is installed.

Disconnect the lower steering column from the steering
gear.

4.

Remove the gear selector assembly.

Refer to:

Gearshift Linkage

 (308-06 Manual Transmission/Transaxle

External Controls, Removal and Installation).

5.

Remove the starter motor.

Refer to:

Starter Motor

 (303-06B Starting System - TD4

2.2L Diesel, Removal and Installation).

6.

Support the engine.

7.

8.

9. NOTE: If equipped.

9.

10.

11.
