23. NOTE: Close the coolant supply valve when the
coolant expansion tank MAX mark is reached or coolant
movement has ceased.

Open the coolant supply valve and allow the coolant to
be drawn into the system.

23.

Remove the vacuum filler gauge and cooling system vacuum refill
adaptor assembly.

24.

Connect exhaust extraction hoses to the tail pipes.

25.

Start and run the engine.

26.

Install the coolant expansion tank cap.

27.

Hold the engine speed at 2000 rpm until warm air is expelled from
the heater.

28.

Switch the engine off and allow to cool.

29.

Clean any spilt coolant from the vehicle.

30.

31.

WARNING: Since injury such as scalding could be caused by

escaping steam or coolant, allow the vehicle cooling system to cool
prior to carrying out this procedure.

Check and top-up the coolant if required.

31.

Install the front RH splash shield.

32.

Install the engine undershield.

Refer to:

Engine Undershield

 (501-02 Front End Body Panels,

Removal and Installation).

33.

Engine Cooling - TD4 2.2L Diesel - Thermostat

Removal and Installation

Removal

Disconnect the battery ground cable.

Refer to:

Specifications

 (414-00 Battery and Charging System -

General Information, Specifications).

1.

Remove the engine cover.

Refer to:

Engine Cover - TD4 2.2L Diesel

 (501-05 Interior Trim and

Ornamentation, Removal and Installation).

2.

3.

WARNING: Do not work on or under a vehicle supported only

by a jack. Always support the vehicle on safety stands.

Raise and support the vehicle.

3.

Drain the cooling system.

Refer to:

Cooling System Draining, Filling and Bleeding

 (303-03B

Engine Cooling - TD4 2.2L Diesel, General Procedures).

4.

Remove the air cleaner assembly.

Refer to:

Air Cleaner

 (303-12A Intake Air Distribution and Filtering -

I6 3.2L Petrol, Removal and Installation).

5.

6.

7.

8.

9.

10. CAUTIONS:

 The O-ring seal is to be reused unless damaged.

 Be prepared to collect escaping coolant.

10.

11.

12.

13.
