CLUTCH - V8 REPAIRS 33-2-13 REPAIRS Clutch assembly $% 33.10.01 Remove 1. Remove gearbox assembly. 2. Restrain flywheel. 3. Working in diagonal sequence, progressively loosen 6 bolts securing clutch cover to flywheel. 4. Remove clutch cover. Refit 1. Clean clutch cover and flywheel mating faces and spigot bush in end of crankshaft. 2. Fit LRT-12-001 to spigot bearing in crankshaft. marked 'flywheel side' is against flywheel. 4. Fit clutch cover and locate on dowels. 5. Fit clutch cover bolts and progressively tighten, in diagonal sequence shown, to 40 Nm. (30 6. Fit gearbox assembly. |
