MAINTENANCE

PROCEDURES

10-7

Road wheels

Remove

1. Mark the wheel to stud relationship to ensure

that the wheels  are refitted in the same
position.

2. Loosen wheel nuts. Raise the vehicle to a

wheel-free condition and remove the wheel
nuts.

Tyres

Check

1. Check tyres for compliance with manufacturer's

specification;  visually for cuts, lumps, bulges,
uneven tread wear and depth.

2. Check tyre pressures, condition and tread

depth. Measure the tread depth across the
width of the tyre and around  the circumference.

Brake pads, discs and calipers

 Check

1.  Check front and rear brake pads for wear,

ensure all pads are wearing evenly.

2. Check brake discs for signs of cracking,

excessive scoring or oil contamination.

3. Check calipers for signs of fluid leaks.
4. Clean excessive deposits of brake dust from

pads, calipers and disc shields  using brake
cleaner.

Road wheel speed sensors

Inspect

Front wheel

Rear wheel

1. Inspect each sensor harness for damage.

MAINTENANCE

10-8

PROCEDURES

Brake fluid

Replace

1. Replace brake fluid.



 +

 BRAKES, ADJUSTMENTS, Brake

system bleeding.

Fuel filter - diesel engine

Replace

1. Replace filter element.



 +

 ENGINE MANAGEMENT SYSTEM -

Td5, REPAIRS, Element - fuel filter.

Fuel filter sedimenter

Drain

1. Position suitable container beneath fuel filter.

2. Disconnect multiplug from sedimenter.
3. Rotate sedimenter anti-clockwise until water

flows from drain tube.

4. Allow to drain until diesel fuel flows from drain

tube.

5. Rotate sedimenter fully clockwise.
6. Connect multiplug.

Road wheels

Refit

1. Apply anti-seize compound  to wheel hub

centre.

2. Refit road wheels to original hub position.

Tighten wheel nuts to 140 Nm (103 lbf.ft).

Radiator/Intercooler

Check

1. Visually check radiator/intercooler for external

obstructions, remove debris.

2. Visually check fan blades for damage.

Ambient air Temperature and pressure
sensor

Check

1. Check ambient air temperature and pressure

sensor for damage.

MAINTENANCE

PROCEDURES

10-9

Doors, bonnet and fuel filler flap

Check

1. Check operation of each door, door lock,

bonnet catch and fuel filler flap. Ensure doors
close securely.

Lubricate

1. Lubricate door locks, hinges, check straps,

bonnet catch and fuel filler flap.


 +

 CAPACITIES, FLUIDS AND

LUBRICANTS, Lubrication.

Air suspension intake filter

Check

1. Check condition of filter and that filter is clean,

replace if necessary.


+

 REAR SUSPENSION, REPAIRS,

Filter - intake - SLS.

Anti-freeze

Replace

1. Replace anti-freeze.



+

 COOLING SYSTEM - Td5,

ADJUSTMENTS, Drain and refill.


 +

 COOLING SYSTEM - V8,

ADJUSTMENTS, Drain and refill.

Cooling system

Check

1. Check cooling, intercooler and heating systems

for leaks; hoses and oil pipes for security and
condition.

2. Check accessible hose clips for tightness.
3. Check coolant level, top-up if necessary.

Top-up

1. With engine cold, remove expansion tank filler

cap.

2. Top-up with recommended mixture of coolant

until level reaches  mark on expansion tank.


+

 CAPACITIES, FLUIDS AND

LUBRICANTS, Anti-Freeze Concentration.

3. Fit expansion tank filler cap.

MAINTENANCE

10-10

PROCEDURES

Spark plugs - V8 engine

Replace

Take great care when fitting spark plugs not
to cross-thread plug, otherwise costly
damage to cylinder head will result. It is
essential that correct grade of spark plugs
are fitted. Incorrect grade of spark plugs
may lead to piston overheating and engine
failure. Use only approved spark plugs, use
of unapproved spark plugs may cause the
misfire detection system to malfunction.

1. Disconnect battery earth lead.
2. Noting their fitted position, disconnect ht leads

from spark plugs.

3. Remove 8 spark plugs.
4. Ensure that  gap of new spark plugs is 1.0

±



0.05 mm (0.040

±

 0.002 in).

Do not attempt to clean or adjust gaps. If a
spark plug problem exists, try substituting
defective spark plug(s) with new one(s).

CAUTION: Do not attempt to clean or adjust
spark plug gaps.  If a spark plug problem
exists, try substituting the defective spark
plug with a new one.

5. Fit spark plugs and tighten to 20 Nm (15 lbf.ft).

6. Connect ht leads to spark plugs.
7. Connect battery earth lead.
