MANUAL GEARBOX - R380 OVERHAUL 37-49 5. Remove 2 bolts securing spool retainer to gearbox case. Remove retainer, remove and 6. Remove interlock spool from selector shaft. 7. Remove filter from gearbox case. 8. Align selector shaft pin with slot in centre plate and using wooden blocks and hide mallet, 9. Press out reverse idler shaft using a suitable press. 10. Remove idler gear, needle roller bearing and spacer. |
