ENGINE - V8 REPAIRS 12-2-25 Mounting - rear - RH $% 12.45.09 Remove 1. Raise vehicle on lift. 2. Remove 8 bolts securing rear cross member and remove cross member. 3. Support transfer gearbox on jack. CAUTION: To prevent damage to 4. Remove nut securing mounting to body bracket. 5. Remove nut securing mounting to mounting bracket. 6. Remove 4 bolts securing mounting bracket to gearbox. 7. Remove mounting and mounting bracket assembly. 8. Remove mounting rubber. Refit 1. If fitted, position heatshield, fit mounting rubber to mounting bracket, fit nut but do not tighten. 2. Position mounting bracket assembly, fit bolts securing mounting bracket to gearbox and 3. Fit nut securing mounting to body bracket and tighten to 48 Nm (35 lbf.ft). 4. Tighten nut securing mounting to gearbox bracket to 48 Nm (35 lbf.ft). 5. Position rear cross member, fit bolts and tighten to 26 Nm (19 lbf.ft). 6. Lower vehicle. |
