CONNECTOR VIEWS

Z6

55

C340

R060026



1

S

2

SN

3

WK

4

B

5

WK

6

RN











C341

R050024

1

LGP

2

RN

3

–

4

UK

5

B











C342

R050024

1

LGP

2

RN

3

–

4

US

5

B











C343

R080029

1

B

2

–

3

–

4

SG

5

–

6

–

7

–

8

–















C344

1

P

2

GP

3

B

4

BR

5

KS

6

KS

















C346

R020069

1

B

2

RG/GLG





CONNECTOR VIEWS

Z6

56

C348

85

PU,PU

87

WN

87a

–

86

NP

30

NP
















C349

30

LGW

86

UK

87a

–

87

GR

85

B
















C350

1

PU

2

–

3

PN

R030040







C351

R020057

1

LGW

2

B





C352

R020057

1

LGW

2

B





C353

1

B

2

LGW









CONNECTOR VIEWS

Z6

57

C357

30

LGW

86

US

87a

–

87

GR

85

B
















C358
















85

B

87

BP

87a

–

86

LGW

30

B

C368

1

–

2

B

3

BK











C369

1

SB

2

B

2

1





C370












1

GY

2

–

3

BR

C371

1

BG

2

B










CONNECTOR VIEWS

Z6

58

C372

1

GN

2

GY

2

1






C378

1

RW

2

B







1

2

C381

1

B

2

–

3

P







R030048

C382

1

–

2

–

3

GO

4

OG

5

–

6

GW

7

GU

8

OU

















C383

A

P

B

U

C

NR

D

B

E

W

J

O

F

WG

G

GB

H

GK

I

GR























C384

1

GO

2

GR

3

–

5

–

7

–

6

–

4

B

1

6

5

2

4

3
