ENGINE 23 REPAIR 43. Check and adjust valve clearances. See Adjustment, Valve clearances - check and adjust 44. Fit rocker cover, ensuring oil seal is satisfactory for continued use, and renew if necessary. 45. Secure rocker cover with special seal washers and nuts. Tighten to 10 Nm (7 lbf/ft). 46. Fit rear engine lifting bracket, securing breather pipe and multi-plug retaining clips. Tighten fixing 25 Nm (18 lbf/ft). 47. Fit engine harness bracket to cylinder head. strut. 49. Connect heater hose to rear of cylinder head. pump. 51. Fit exhaust manifold and turbocharger assembly. See MANIFOLD AND EXHAUST SYSTEM, Repair, Exhaust manifold 52. Fit induction manifold. See MANIFOLD AND EXHAUST SYSTEM, Repair, Induction 53. Connect water temperature sensor lead. See FUEL SYSTEM, Repair, Heater plugs 58. Fit fuel injectors. See FUEL SYSTEM, Repair, Fuel injectors 59. Fit crankcase ventilation valve and side breather hose. 60. Fit air cleaner. See FUEL SYSTEM, Repair, Air cleaner 61. Refill cooling system. See COOLING SYSTEM, Repair, Drain and refill cooling system 62. Fit bonnet. OIL PUMP Service repair no - 12.60.26 Remove 1. Remove engine front cover. See Front cover gasket 2. Remove 7 screws and release oil pump retaining plate from engine front cover. 3. Mark oil pump inner gear rotor, outer gear rotor and front cover housing for reassembly. 4. Check for rotor clearances: Outer rotor to housing, 0,025 - 0,075 mm (0.010 5. Remove inner and outer rotors. NOTE: If the oil pump seating in the front be fitted. See Front cover gasket Always renew oil pump rotors as a pair. 7. Clean sealant from pump retaining plate and front cover. |
