Inspecting

Solenoid

23.  Check  the  continuity  and  resistance  value

of

windings by

an ohmmeter as shown.

(a)  Resistance value should be:

1.074  0.035 ohms

(b)  Resistance value should be:

0.298  0.015 ohms

If  test results are unsatisfactory  replace the solenoid.
If results arc correct proceed  to 24.

24.

Check  the contacts by  connecting an  ohmmeter as
shown.
Solenoid plunger removed,  ohmmeter should read

infinity.

Solenoid  plunger  operated  by  hand,  ohmmeter
should read zero.
If  test  results  are  unsatisfactory,  replace  the

If  results are correct proceed to

25.

movement.

solenoid.

25.  Check  operation  of  spring  for  freedom

of

Brush gear

26.  Check  brush  springs  and

that  the  brushes

move freely in their holders.
Clean the brushcs  with  a petrol

cloth, if

Brush  length  new,  Dimension  A  is

(0.354 in).
Minimum  brush  length,  Dimension

is  3.5

(0.138 in).

46

ELECTRICAL

Armature

33.  Commutator  end  bracket;  thread  a

o r  suitable similar tap firmly into the bush. Extract
the  bush  with

the  tap  using  a  power  press  in

reverse.

NOTE:  Soak  new  bushes  in  engine  oil  for  thirty
minutes before fitting.

Check  the  armature  insulation  using  suitable  test

equipment.  Connect  the  tester  between  any  one
commutator  segment  and  the  shaft.  The  method
illustrated  uses  a

110 V,

W  test  lamp.  If  the

lamp  illuminates  the  armature  is  faulty,  and  a
replacement component is required.

Reassembly

34.  Reverse  the  instructions

1 to  22.  Smear the  teeth

and operating collar

of  the roller  clutch  with  Shell

Retinax

'A'

grease.  Smear  the  pivot  lever  of  the

drive  assembly  with  Mobil

22  grease.  Smear

the

drive  shaft  sun  and  planet  gears  with  Rocol

grease.

35.  Tighten  all the fixings to the correct  torque

see

15w

Torque Wrench Settings.

28.  If  necessary,  the  commutator  may  be  machined,

providing

finished  surface  can  be  obtained

without  reducing  the  diameter  below

28.8

(1.13 in),  otherwise  a  new  commutator  must  be

fitted. Finish  the surface with  fine emery cloth.

Do

not undercut the insulation slots.

Drive

assembly

29.  Test the  roller clutch.

The pinion  should

in

one direction only, independent of  the clutch body.
Replace  the  unit  if  unsatisfactory  o r   if  teeth  are
damaged or worn.

Bearings

30.  Renew  the  bearing  bushes  if  there  is  evidence of

armature fouling magnets or if  there

is perceptible

side play between  the shaft and bush.

31.  Drive

end  bracket:  press out the

bush using a suitable press and mandrel.

32.  Press  the  new  bush  in,  ensuring  that

on  the  drive

end bracket, the bush is flush with the casting.

..

. .

ELECTRICAL

EQUIPMENT-

LAMPS

REMOVE AND OVERHAUL HEADLAMPS

Remove and dismantle

NOTE:  Instructions 1 to 8 cover renewal of the bulb or
light unit only.

1.  Disconnect the battery for safety.

2.  Remove the six screws and remove the plastic

3.

Remove  the  three  screws  retaining  the  rim  and

4.  Withdraw the light unit or reflector and pull-off the

5 .

Remove the rubber grommet.

6.

Discard the light unit, if  faulty, or the bulb if failed.

7.  Release the spring clip to remove the bulb from the

surrounding the head, side and flasher lamps.

light unit, and remove the rim.

electrical connector.

reflector unit.

and secure with the spring clip, as illustrated.

9.  Remove the four screws and release

headlamp

10.  Disconnect  the  electrical  leads  from  the  bullet

11.  Remove the rubber seal.
12.  Release the two trimmer screws and coil spring and

detach the rim

from the

shell.

8.  If  required,  fit

bulb  of  the  correct  wattage

shell from

front wing.

connectors and remove

t h e

headlamp shell.
