ELECTRONIC IGNITION -

V8

ENGINE

It  is  essential  that  the  following  procedures  are

adhcrcd  to.  Inaccurate  timing  can  lead  to
engine  damage  and  additionally  create

to

comply  with  the  emission  regulations  applying  to
the  country  of  destination.  If  the  engine  is  being

in  the  vehicle  and  is  fitted  with

an  air

conditioning unit the compressor must be isolated.

On  initial  engine  build,  or  if  the  distributor  has

been  disturbed  for  any  reason,  the  ignition  timing
must be set statically to within

2"-3"

of

T.D.C.

(This sequence is to

only an approximation  in

order  that  the  engine  may  be  started)  ON  NO
ACCOUNT  MUST  THE  ENGINE  BE  STARTED
BEFORE THIS OPERATION IS CARRIED OUT.
Refer to 'Engine

Tuning Data'  for  ignition  timing

specification.

Equipment required

Calibrated Tachomctcr
Stroboscopic lamp

3 .   Couple  stroboscopic  timing  lamp  and  tachometer

to engine following the

instructions.

4.

Disconnect the vacuum pipes from

distributor.

Start  engine;  with

no

load  and  not  exceeding

3,000

run  engine  until  normal

temperature is reached. (Thermostat open). Check
that  the  normal  idling  speed  falls  within  the
tolerance

in table.

6.

Idle  speed  for  timing  purposes  must  not

750

and  this  speed  should  be  achieved  by

removing  a  breather  hose,  NOT

BY  ADJUSTING

CARBURETTER IDLE SETTING SCREWS.

7 .  With  the  distributor  clamping bolt  slackened, turn

distributor  until

timing flash coincides with  t h e

timing  pointer  and  the  correct  timing  mark  on  the
rim  of

the

torsional  vibration

as shown  in

the table.

8.

Retighten  the  distributor  clamping  bolt  securely.
Rccheck  timing  in  the  event  that  retightening  has

disturbed the distributor position.

9.  Refit vacuum pipes.

10.  Disconnect

stroboscopic

timing

lamp

and

tachometer from engine.

LUCAS  CONSTANT

ENERGY

IGNITION  SYSTEM

PRELIMINARY CHECKS

Inspect  battery  cables  and  connections to  ensure  they
are clean  and tight.  Check  battery state of  charge

if

in

doubt as to its condition.
Inspect all LT connections

to ensure that they are clean

and  tight.  Check  the H T  leads arc correctly positioned
and  not  shorting  to  earth  against  any  engine

components. The wiring  harness  and  individual  cables
should be firmly

to prevent chafing.

PICK-UP MODULE AIR GAP SETTINGS

Air gap settings vary according

to vehicle application.

NOTE:  The gap is  set  initially  at  the  factory  and  will
only  require  adjusting

if

tampered  with  o r   when  the

pick-up module is replaced.

Test Notes

The ignition must be switched

on for all

Key to symbols used in charts for Tests

2.

Correct

Reading

Reading

(iii)

Use  feeler  gauges

from  a  non-

magnetic material when setting air gaps.

TEST

1:

Check HT Sparking

Remove

H T  lead from distributor cover

and  hold  approximately

(0.25 in)  from  the

engine  block.  Switch the ignition

'on'  and  operate the

starter.
If  regular  sparking  occurs,  proceed  to  Test

6.  If  no

sparking proceed to Test 2.

Test 1

Crank
engine

ELECTRONIC

IGNITION

FAULT DIAGNOSIS

TEST 2:

T e s t

Amplifier Static Checks

Switch the ignition

‘ON’

(a)  Connect voltmeter to points in

the circuit indicated

by the arrow heads and make a note of  the voltage
readings.

NOTE:  Only  move  the  voltmeter  positive  lead  during
tests 2 , 3  and 4.

(b)  Compare

obtained  with  the  specified

EXPECTED READINGS

More than

11.5 volts

1 volt max below volts at point  1

in test circuit

3  1 volt max below volts at point 1 in test circuit

0 volt

volt

(c)  If  all readings are correct proceed to Test

3.

(d)  Check  incorrect

with  chart  to  identify

area  of  possible  faults,  i.e.  faults  listed  under
heading “Suspect”.

values listed below:-

TEST 3:

SUSPECT

Discharged battery

switch

wiring

Coil o r  amplifier

Amplifier earth

Check Amplifier Switching

Disconnect  the High Tension lead between the coil and
distributor.
Connect the voltmeter between  battery positive  (+ ve)
terminal  and

HT

coil  negative  (- ve)  terminal:  the

voltmeter should register  zero volts.  Switch the ignition
‘on’ and crank the engine: the voltmeter reading should
increase  just  above  zero,  in  which  case  proceed  with

Test

5.

If  there  is  no  increase  in  voltage  during  cranking
proceed to Test 4.

T e s t

To

ign

switch

10

TEST 4:

Pick-up  Coil  Resistance.  Applications  with  Separate
Amplifier

Disconnect the pick-up leads at  the harness connector.
Connect the ohmmeter leads to the two pick-up leads

in

the plug.

The ohmmeter should register between

2k and

5k

ohms

if

pick-up  is  satisfactory.  Change  the  amplifier  if

ohmmeter reading is correct. If  the engine still does not
start carry out Test

5.

Change the pick-up if ohmmeter reading is incorrect.

If

the engine still does not start proceed to Test

5 .

Test

ELECTRONIC IGNITION

FAULT DIAGNOSIS

TEST 7:

....

Check

HT

Sparking

Visual and HT Cable Checks

...

.,.

.  .

, ,

..

....

Remove  existing

lead  and  fit  test

H T  lead

to  coil  chimney.  Hold  free  end  about

(0.25

in) from the engine block and crank the engine.

H T  sparking good, repeat  test  with original

HT

lead,

if

then  no sparking, change

HT lead.  If  sparking  is good

but engine will not start, proceed to Test

6.

If  no sparking, replace coil.
If engine will not start carry out Test

6.

Test

Crank

TEST

6:

Check Rotor Arm

Remove  distributor  cover.  Disconnect  coil  H T   lead
from cover and  hold  about

(0.13 in) above rotor

arm  electrode  and  crank  the  engine. There  should  be
no

HT  sparking  between  rotor  and

HT

lead.

If

satisfactory carry

out Test 7.

HT sparking, replace rotor arm.
If  engine will not start carry out Test

Test

Crank
engine

Examine:

Should be:

1.  Distributor Cover

Clean, dry, no tracking marks

2.

Clean, dry, no tracking marks

3.  H T  Cable Insulation  Must not  be cracked chafed or

perished

4.

HT Cable Continuity Must not be open circuit

5 .

Sparking Plugs

Clean, dry,  and  set

to  correct

NOTE:

1.

Reluctor

Must

not foul pick-up

or leads

2.

Must  not  be  cracked

or show

Shield

signs of tracking marks.

11

ELECTRONIC IGNITION

V8 ENGINE

OVERHAUL DISTRIBUTOR

LUCAS

Distributor Cap

1.  Unclip and remove cap.

2.  Renew cap if known to be faulty.
3 .   Clean with a nap-free cloth.

Rotor Arm

4.  Pull rotor arm from keyed shaft.

5 .

Renew rotor arm if known to be faulty.

Insulation Cover (Flash shield)

6.  Remove cover, secured by 3 screws.
7.

Renew cover if known to be faulty.

Vacuum Unit

8.  Remove  2  screws  from  vacuum  unit  securing

bracket,

vacuum  unit  connecting  rod

from  pick-up  base  plate  connecting  peg,  and
withdraw vacuum unit from distributor body.

bly

14.  This  is  mainly  a  reversal  of

the  dismantling

procedure, noting the following points:

Lubrication

Apply clean engine oil:
(a)

3 drops to felt pad reservoir in rotor shaft.

Apply Chevron

(or equivalent) grease.

(b)  Auto advance mechanism
(c)  Pick-up plate

bearing

(d)  Pre tilt spring and its rubbing area (pick-up and

(e)

Vacuum unit connecting peg (pick-up and base

(f)

the  connecting  peg  hole

in

vacuum

unit

Apply Rocal MHT (or equivalent) grease.

Vacuum  unit  connecting  rod

(located  in

base plate assy)

assy) and

connecting rod.

vacuum unit where connecting rod protrudes)

NOTE:  Applicable  only  to  double  acting
vacuum units.

Pick-up and Base Plate Assembly

9.  Use circlip pliers to remove the circlip retaining

reluctor on rotor shaft.

10.  Remove  the  flat  washer  and  then  the

ring

recessed  in the top of

t h e

reluctor.

11.

Insert the blade of  a  small screwdriver

the

reluctor  and  prise

it

partially  along  the  shaft,

sufficient

to enable it to be gripped between  fingers

and withdrawn from

t h e

shaft.

NOTE: Coupling ring fitted beneath reluctor.

12.  Remove pick-up  and base plate  assembly, secured

by support pillars.

NOTE: Do not disturb the 2 barrel nuts securing the
pick-up  module,  otherwise  the  air  gap  will  need

Fitting Pick-up and Base Plate Assembly

15.  Pick  up  leads  must  be  prevented  from  fouling the

rotating  reluctor.  Both  leads  should

be

located

in

plastic  carrier  as  illustrated.  Check  during
assembly.

13.

Renew pick-up  and  base  plate assembly  if  module

is  known  to  be  faulty,  otherwise  check  pick-up
winding resistance

ohms).

TECHNICAL DATA

Firing angles

.....................................................

etc.

.......................................................

(Pick

up

tooth)  .................................

0.20

0.35

(0.008 in

0.014 in)

Pick up air gap adjustment

Pick up winding resistance

....................................

2k

5k ohms
