GENERAL FITTING INSTRUCTIONS

6.

Grease outside diameter of  seal, place square
to  housing  recess  and  press  into  position,
using  great  care  and

if

possible a  'bell  piece'

1.

Before removing any  brake or  power  steering

to  ensure  that  seal  is  not  tilted.  (In  some

hose, clean  end  fittings  and  area  surrounding

cases

it

may  be  preferable  to  fit  seal  to

them as thoroughly as possible.

housing  before  fitting  to  shaft.)  Never  let

2.  Obtain

appropriate  blanking  caps  before

weight of  unsupported shaft rest in seal.

detaching  hose end  fittings,

so  that  ports  can

be immediately covered to exclude dirt.

3.

Clean  hose  externally  and  blow  through

with

airline,

Examine

carefully

for

cracks,

separation of  plies,  security of  end fittings  and
external  damage.

Reject

any  hose  found

faulty.

4.

When

refitting

hose,

ensure

that

no

unnecessary  bends  are  introduced, and  that
hose is not  twisted  before

or

during  tightening

of  union nuts.

5.

Containers

for

hydraulic  fluid  must  be  kept

absolutely clean.

6.

Do  not  store  hydraulic  fluid  in  an  unsealed
container.

It

will  absorb water, and fluid  in this

condition would  be dangerous

to

use due to  a

lowering

of  its boiling point.

7.

Do

not

allow

hydraulic

fluid

to

be

7.

If

correct  service  tool  is  not  available,  use  a

contaminated

with

mineral  oil,  or  use  a

suitable  drift  approximately

0,4

mm  smaller

container  which  has  previously  contained

than  outside  diameter  of  seal.  Use a  hammer

mineral oil.

VERY  GENTLY  on  drift

if

a  press  is  not

8.

Do not re-use fluid bled from system.

suitable.

9.

Always  use  clean  brake  fluid  to  clean

8.

Press  or  drift  seal  in

to

depth  of  housing

if

hydraulic components.

housing

is

shouldered,

or  flush  with  face  of

10.

Fit  a  blanking cap  to  a  hydraulic  union and  a

housing  where  no  shoulder  is  provided.

plug

to

its  socket  after  removal

to

prevent

Ensure  that  the  seal  does  not  enter  the

ingress of  dirt.

housing

in a tilted position.

11.

Absolute  cleanliness  must  be  observed

with

hydraulic components at  all times.

NOTE:  Most  cases of  failure  or  leakage of

12.

After  any  work  on  hydraulic  systems,  inspect

oil  seals  are  due  to  careless  fitting,  and

carefully  for  leaks  underneath  the  vehicle

resulting damage to both seals and sealing

while  a  second  operator  applies  maximum

surfaces.  Care in fitting is essential if  good

pressure

to

the  brakes  (engine  running)  and

results are to be obtained.

operates the steering.

FLEXIBLE HYDRAULIC

PIPES, HOSES

JOINTS AND

JOINT FACES

1.

Always  use  correct  gaskets  where  they  are
specified.

2.  Use

jointing

compound

only

when

recommended. Otherwise fit joints dry.

3.

When  jointing  compound  is  used,  apply  in  a
thin  uniform film  to  metal surfaces;  take  great
care to  prevent

it

from  entering oilways, pipes

or  blind tapped holes.

4.

Remove  all  traces  of  old  jointing  materials
prior  to  reassembly.

Do

not  use  a  tool  which

could damage joint  faces.

5.

Inspect joint  faces  for  scratches or  burrs  and
remove  with  a  fine  file

or  oil  stone;  do  not

allow  swarf  or  dirt  to  enter  tapped  holes  or
enclosed parts.

6.

Blow  out  any  pipes, channels or  crevices with

compressed  air,  renewing  any  O-rings  or
seals displaced by air  blast.

REISSUED: FEB

1993

GENERAL FITTING INSTRUCTIONS

METRIC

       BOLT          IDENTIFICATION HYDRAULIC                           FlTTlNGS - Metrication

1.

An  IS0  metric  bolt  or  screw,  made  of  steel

WARNING: Metric and Unified threaded hydraulic

and  larger  than

mm  in  diameter  can  be

parts.  Although  pipe  connections  t o   brake

identified by  either of the symbols IS0 M or

system units incorporate threads of metric form,

embossed or  indented on top of  the head.

those for  power assisted  steering  are of  UNF

2.  In  addition  to  marks

to  identify  the

type. I t  is vitally important that these two thread

manufacture,  the  head  is  also  marked  with

forms are not confused, and careful study should

symbols

to

indicate  the  strength  grade  e.g.

be made of the following notes.

8.8,  10.9,

12.9

or  14.9,  where  the  first  figure

gives  the minimum tensile  strength of  the  bolt

Metric threads and metric sizes are being introduced

material in tns of  kg/sq  mm.

into motor vehicle manufacture and some duplication

Zinc plated IS0  metric  bolts  and  nuts  are

of  parts must  be expected.  Although  standardisation

chromate passivated,  a  greenish-khaki  to

must in the long run be good,  it would  be wrong  not

to  give warning  cf  the  dangers that  exist  while  UNF
and  metric  threaded  hydraulic  parts  continue
together in service.  Fitting  UNF pipe nuts into metric
ports  and  vice-versa  should  not  happen,  but
experience of the change from BSF to UNF indicated
that  there  is  no  certainty  in  relying  upon  the
difference in thread size when safety is involved.

To  provide permanent identification of  metric  parts is
not  easy  but  recognition has  been  assisted  by  the
following means.  (Illustration A  Metric,

Unified.)

1.  All  metric  pipe  nuts,  hose  ends,  unions  and

bleed screws are coloured black.

2.  The  hexagon  area

of  pipe  nuts  is  indented

with the letter

’M’.

3.

Metric  and

UNF pipe nuts are slightly  different

in shape.

gold-bronze colour.

ST1035M

METRIC NUT IDENTIFlCATlON

1.

A  nut with an IS0 metric thread  is marked on
one face or  on one of  the flats  of the hexagon

with

the  strength  grade  symbol

8,  12  or  14.

Some  nuts  with  a  strength 4,

or

6  are  also

marked  and  some  have the  metric  symbol

on  the  flat  opposite  the  strength  grade
marking.

2.

A  clock  face  system  is used as  an alternative
method  of  indicating the  strength  grade.  The
external  chamfers  or  a  face

of

the  nut  is

marked  in  a  position  relative  to  the
appropriate  hour  mark  on  a  clock  face  to
indicate the strength grade.

3.  A  dot  is used to  locate the  12 o’clock  position

and  a  dash

to

indicate  the  strength  grade.

If

the grade is above 12,

two

dots identify the

12

o’clock position.

ST1034M

The  metric female nut  is always used

with

a trumpet

flared  pipe  and  the  metric  male  nut  is  always

used

with a convex flared pipe.

STt036M

REISSUED: FEB 1993

ST1033M

ST1031M

GENERAL FITTING  INSTRUCTIONS

ST1032M

4.  All metric ports in Cylinders and calipers have

no  counterbores,  but  unfortunately  a  few

cylinders  with  UNF  threads  also  have  no
counterbore.  The  situation  is,  all  ports  with
counterbores  are  UNF,

but  ports  not

counterbored are most likely to be metric.

5.  The coulour of the protective  plugs  in hydraulic

ports  indicate  the  size  and  the  type  of  the
threads  but  the  function  of  the  plugs  is
protective  and  not  designed

as

positive

identification. In production it is  difficult  to  use

The  greatest  danger  lies  with  the  confusion  of  10

the wrong plug but human error  must  be

mm  and  3/8  in  UNF  pipe  nuts  used  for  3/16  in  (or

taken into account. The  Plug  colours  and

4,751  mm) pipe. The 3/8 in UNF pipe nut or hose can

be  screwed  into a  10  mm  port but  is very slack  and
easily  stripped.  The thread engagement is  very weak
and cannot provide an adequate seal.
The opposite condition, a 10 mm  nut in a 3/8 in port,
is difficult and  unlikely to  cause trouble.  The  10  mm

nut will screw in 1  1/2 or  2 turns and seize.  It has a
crossed thread  'feel'  and it is impossible to force the
nut  far  enough  to  seal  the  pipe.  With  female  pipe
nuts the position is of course reversed.

The  other  combinations  are  so  different  that  there  is

no danger of confusion.

KEYS AND KEYWAYS

thread sizes are:

RED
GREEN
YELLOW
PINK

BLACK

10 x 1 mm

GREY

12 x 1 mm

BROWN

14

1,5  mm

6.

Hose  ends  differ  slightly  between  metric  and

UNF. Gaskets are not used with metric hoses.

The  UNF  hose  is  sealed  on  the  cylinder  or
caliper face  by  a  copper  gasket  by the  metric

1.

Remove  burrs  from  edges

of

keyways  with  a

hose seals  against the  bottom of  the port and

fine

file

and

clean'  thoroughly  before

there is a gap  between faces

of the hose and

attempting to refit key.

cylinder.

2.  Clean  and  inspect  key  closely;  keys  are

Pipe  sizes  for  UNF  are  3/16

in,  1/4 in  and  5/16  in

suitable  for  refitting  only

if

indistinguishable

outside diameter.

from  new, as  any  indentation may  indicate the

Metric  pipe  sizes  are

4,75

mm,  6  mm  and  8  mm.

onset of  wear.

4,75  mm pipe is exactly the same as  3/16 in pipe.

mm  pipe  is  0.014  in  smaller  than  1/4 in pipe. 8  mm

pipe is

0.002 in

larger than 5/16

in

pipe.

Convex  pipe  flares  are  shaped  differently  for  metric
sizes  and  when  making  pipes for  metric  equipment,
metric pipe flaring tools must

be used.

UNF
3/8 in

24  UNF

7/16 in

20 UNF

1/2 in

x  20  UNF

7/8 in

18 UNF

METRIC

TAB WASHERS

1.

Fit  new  washers  in all  places where  they  are
used. Always renew a used tab washer.

2.  Ensure  that  the  new  tab  washer  is

of  the

same design as that replaced.

SPLIT

PINS

1.

Fit  new  split  pins  throughout  when  replacing

any  unit.

2.  Always  fit  split  pins  where  split  pins  were

originally  used.

Do  not  substitute  spring

washers:  there  is  always  a  good  reason  for
the use of a split pin.

3.

All

split  pins should be fitted as  shown  unless

otherwise stated.

REISSUED:

FEB 1993

GENERAL FlTTlNG INSTRUCTIONS

ST1039M

NUTS

UNIFIED THREAD IDENTIFICATION

1.

When  tightening

slotted  or  castellated  nut

1.

Bolts

never  slacken  it  back  to  insert  split  pin  or

circular  recess  is  stamped  in  the  upper

locking  wire  except  in  those  recommended

surface of  the bolt head.

cases  where  this forms  part of  an  adjustment.

2.  Nuts

If

difficulty

is

experienced, alternative washers

A  continuous line of  circles is indented

on

one

or  nuts  should

be  selected,  or  washer

of  the flats  of  the  hexagon, parallel to the axis

thickness reduced.

of the nut.

is advisable to  replace them with  new ones of

The  component  is  reduced

to

the  core

the same type.

NOTE: Where bearing pre-load i s  involved
nuts should be tightened i n  accordance
with special instructions.

2.  Where  self-locking nuts have been removed

it

3.

Studs, Brake

Rods.

etc.

diameter for  a short  length at  its extremity.

LOCKING WIRE

1.

Fit new  locking wire  of  the  correct  type  for  all

assemblies incorporating

it.

2.

Arrange  wire

so

that  its  tension  tends  to

tighten  the  bolt  heads,  or  nuts,  to  which  it  is
fitted.

SCREW THREADS

1.

Both  UNF  and  Metric  threads  to  ISO

standards  are  used.  See  below  for  thread
identification.

2.

Damaged threads  must  always

be  discarded.

Cleaning up threads  with  a  die

or  tap impairs

the  strength  and  closeness  of  fit  of  the
threads and is not recommended.

3.

Always  ensure  that  replacement bolts  are  at

least equal in strength

to

those replaced.

4.

Do not  allow  oil,  grease or  jointing  compound

to

enter  blind  threaded  holes.

The  hydraulic

action  on  screwing

in  the  bolt  or  stud  could

split the housing.

5.  Always  tighten  a  nut  or  bolt

to  the

recommended  torque  figure.  Damaged

or

corroded  threads  can  affect  the  torque
reading.

6.

To

check  or  re-tighten a  bolt

or

screw  to  a

specified torque figure,  first  slacken

quarter

of  a turn, then re-tighten to the correct figure.

7.  Always  oil  thread  lightly  before  tightening  to

ensure  a  free  running  thread,  except  in  the
case of self-locking nuts.

REISSUED: FEB

1993















Content   ..  5  6  7  8   ..
