Defender (1993+). Manual - part 4





GENERAL SPECIFICATlON DATA

ELECTRICAL

EQUIPMENT

System

............................................................................................

Battery

Type:

12 volt, negative ground

Lucas

standard 9 plate

...............................................

B.B.M.S. No.371

Chloride

standard 9 plate

...........................................

B.B.M.S.

No.2911

Lucas

cold climate 13 plate

Chloride

cold climate 13 plate

....................................

B.B.M.S. No.3693

Designation
90/84/90

B.B.M.S. No.389

Designation

15/120/92

Alternator

Type

.....................................................................................

Magnetti Marelli A127-85

Rotor

winding resistance

...................................................

2.6 ohms at 2O°C  ±  5%

New brush length

.................................................................

20

mm

Renew brush at

....................................................................

10 mm

Brush spring pressure

..........................................................

1.3 - 2.7 N

Regulator controlled voltage

................................................

13.6 - 14.4 volts measured across battery

Starter motor

Brush  spring  tension

............................................................

1020

gms

Brush  minimum  length

.........................................................

9,5  mm

Distributor &  MFI system

..................................................

See

‘ENGINE  TUNING  DATA'

Wiper

motor

Armature end-float

...............................................................

0,1 - 0,20 mm

Minimum brush length

..........................................................

4,8 mm

Fuses

Type

.....................................................................................

Cartridge fuses, located

in

box below the facia

Maximum

D.C.

output at 6000 rev/min

................................

85

amps

Stator

winding resistance per phase

..................................

0.092 ohms at 20°C ± 5%

Type

.....................................................................................

Magnetti Marelli M78R pre-engaged

Type

.....................................................................................

Lucas

14W

uprated two-speed

panel, which protect the electrical components.

A complete list of circuits protected is given in

Electrical  Section.
A second fuse box located in the engine compartment
next to the brake servo contains fuses to protect the
vehicle harness. For fuse values refer to the Electrical
Section.

REVISED:

OCT

1993

GENERAL SPECIFICATION DATA

Coil

Make/type

........................................................

Distributor
Make/type

............................................................................

Lucas 35 DLM8

Application

...........................................................................

12V

Negative ground

Pick-up air gap adjustment

Bosch

0221 122 392

Firing  angles  .................................................................

0°-45°-90° (every 45°) ± 1 °

(Pick-up Iimb/reluctor

tooth)

.................................................

0.20 mm to

0.35

mm

Pick-up winding resistance

..................................................

2k

to

5k ohms

Horns
Make/type

............................................................................

Klamix

(Mixo)

TR99

Ignition

module

Spark plugs
Make/type

............................................................................

Champion RN9YC

REPLACEMENT BULBS AND UNITS

Headlamps

...........................................................................

60/55

halogen sealed beam

Front side lamps

..................................................................

12V 5W

Side marker lamps

...............................................................

12V

3W

High mounted stop light

.......................................................

12V/5W

Flasher lamps

......................................................................

12V 21W

Reverse lamp

.......................................................................

12V

21W

Interior lamp

.........................................................................

12V

21 W

Warning lights

......................................................................

12V

1.2W

Instrument illumination

.........................................................

12V 2W

Hazard  switch  warning  light

.................................................

12V 1.2W

(red)

Heated  rear  Screen  switch  illumination

................................

12V

1.2W

(green)

Heated  front  screen  switch  illumination

...............................

12V 1.2W

(green)

Heated  front  Screen  warning  light

........................................

12V

1.2W

(amber)

Cigar  light  illumination

..........................................................

12V 1.2W

Make/type

............................................................................

Lucas 9EM amplifier module, distributor mounted

Stop/tail lamps

.....................................................................

12V 21/5W

Number plate lamp

...............................................................

12V

4W

RE-ISSUED: FEB 1993

GENERAL SPECIFICATION DATA

VEHICLE DIMENSIONS

110

Overall length

...............................................................

Overall width

........................................................................

1790mm

..................................................................

2035mm

Wheelbase

..........................................................................

2794mm

Track: front and rear

............................................................

1485,90mm

Ground clearance: under differential

....................................

215mm

Rear opening height (interior)

..............................................

1205mm

VEHICLE

DIMENSIONS

90

Overall length

.......................................................................

4072mm

Overall width

........................................................................

1790mm

Overall height

.......................................................................

2035mm

Wheelbase

...........................................................................

2360mm

Track: front and rear

............................................................

1485,90mm

Ground clearance: under differential

....................................

229mm

Tailgate aperture width

........................................................

864mm

Tailgate height

.....................................................................

1300mm

Interior width

........................................................................

1450mm

Width between wheelboxes

.................................................

925mm

VEHICLE WEIGHTS AND  PAYLOAD

When  loading  a  vehicle  to  its  maximum (Gross  Vehicle  Weight),  consideration must  be  taken

of

the

vehicle

kerb  weight  and  the  distribution

of

the  payload  to  ensure  that  axle  loadings  do  not  exceed  the  permitted

maximum values.  It

is

the customer's responsibility

to

limit the vehicle's  payload in an appropriate manner  such

that neither maximum axle loads nor

Gross



Vehicle Weight are exceeded.

NOTE:

CURB WEIGHT

equals the minimum unladen vehicle weight  plus full fuel tank.

GROSS  VEHICLE  WEIGHT

equals  the  maximum  all  up  weight,  with  the  driver,  passengers.

payload equipment and towing attachment load (where applicable)

GROSS VEHICLE WEIGHT CONDITION

the

maximum

axle weights shown are

individual

axle

loadings which  allow  for  the  fitting  of  optional  equipment. The  loading of

both

axles

up

to

their

respective maximums

MUST BE  AVOIDED,

as  the overall maximum vehicle  weight

would

then

be exceeded.

REVISED: OCT

1993

GENERAL SPECIFICATION DATA

WHEELS

AND TIRES

DEFENDER

90

Wheels

Alloy

Tires

Steel

7.0

16

7J

16

33

Type and size

BF

Goodrich LJ265/R16 Mud Terrain

Radial

Ply

DEFENDER

110

Wheels
Steel

139,70mm x

406,40mm

Tires
Type and size

750X 12,8m (tubed) USE RADIAL PLY TIRES ONLY

TIRE

PRESSURES

WARNING:  Tire pressures must

be

checked with the tires cold,  as the pressure is about 0,21  bar higher

at  running temperature.

If

the vehicle has been parked In the sun

or high ambient temperatures, Do not

reduce the tire pressures, move the vehicle into the shade and wait for the tires to cool before checking

the pressures.

General Notes

Emergency  soft  pressures  should  only  be

used

in  extreme conditions  where  extra  flotation  is  required

Max

speed

40

km/h (25 mph). Return pressures to normal immediately firm ground is regained.

Towing  When  vehicle is used  for  towing the  reduced  rear tire  pressures for  extra  ride  comfort are  not
applicable

WARNING:

D o  not  replace  the  road  wheels  with  any  type  other  than  genuine  Land  Rover wheels,

as

they  are designed for  multi-purpose on and

off  road use and have very important  relationships with the

proper  operation

of

the  suspension system  and  vehicle  handling.  Replacement  tires  should

be

of  the

size  recommended

in

this  manual  and  all  be  the  same  make,  ply  rating  and  tread  pattern.  If  in  any

doubt,

consult

Land

Rover Service department for advice.

REVISED:

OCT

1993
