Defender Electric Diagrams. Manual - part 273
417-01 - EXTERIOR LIGHTING
Head/Side lamps
DEFENDER (LHD) - VIN: 751063 > -
(01 / 03)
62
Head/Side lamps
R,1.5D
NU,3.0D
UW,2.0D
UO,1.5D
UB,1.5D
UK,1.5D
RB,1.0D
UR,1.5D
WG,0.5D
NP,1.5D
US,1.5D
W,4.0D
RO,1.0D
NW,4.0D
W,4.0D
NW,4.0D
N,10.0D
B,40.0D
US,0.5D
UO,1.5D
US,1.5D
US,1.5D
WG,0.5D
UB,1.5D
UK,1.5D
RO,1.0D
RB,0.5D
RB,0.5D
RB,0.5D
B,0.5D
U,2.0D
RO,1.0D
U,2.0D
U,2.5D
WG,0.5D
FUSE 19
10.0 Amps
Junction box-Central (P101)
FUSE 25
10.0 Amps
FUSE 15
5.0 Amps
FUSE 24
10.0 Amps
FUSE 23
10.0 Amps
FUSE 18
10.0 Amps
FUSE 22
10.0 Amps
Switch-Ignition (S176)
12.0 Volts
Battery (P100)
Junction box-Battery (P147)
LINK 5
60.0 Amps
LINK 6
30.0 Amps
LINK 1
100.0 Amps
FUSE 3
20.0 Amps
Header (K109)
C1264-1 C1265-1
C1266-1 C1267-1
L
Sheet2
K
Sheet2
J
Sheet2
switch (S100)
Lighting control
C1264-2 C1265-2
C1266-2 C1267-2
Header (K109)
Relay-Headlamp (R123)
Switch-Column (S123)
flash (S108)
Switch-Headlamp-
Dip (S101)
Switch-
F
Sheet2
H
Sheet3
G
Sheet2
E
Sheet2
D
Sheet2
C
Sheet3
A
Sheet2
B
Sheet2
C1661-1
C0571-3
C0570-2
C0572-1
C0581L-13
C0580L-9
C0581L-16
C0581L-14
C0580L-16
C0581L-9
C0581L-1
C0581L-12
C0581L-2
C0581L-4
C0581L-10
IGN 2A
IN1
2B
C0028L-1
CRANK
IN2
1
AUX
C0094L-1
C0632-1
C0045-1
C0192-1
C0285-8
C0285-3
A721
C0285-4
C0285-2
C1739-5
C1739-1
C1082-4
SJ3
A700
C0288-2
C0288-3
C0288-4
C0282L-86
C0282L-30
C0282L-85
C0288-1
C0282L-87
A462
C1082-2
C1739-7
C1739-6
C1082-1
A305
