Connector: C0149

Description: Sensor-Mass air-flow (MAF)

Location: RH side of engine compartment





Part No.:

YPH900370



Colour:

Cavities:

Harness:

ENGINE DIESEL PUMA HARNESS



Wire Chart

CAV  TERMINAL  CSA  COL  CCT  DESTN

2

YPL500360

0.5

PS

254

C2518

3

YPL500360

0.5

SP

254

C0162

4

YPL500360

0.5

U

254

C2518

5

YPL500360

0.5

YP

254

C2518

Service Repair Kits

Connector: C0151

Description: Relay-Starter

Location: Beneath RH Front seat





Part No.:

AFU3271



Colour: YELLOW

Cavities: 5WY

Harness:

MAIN LH + RH HARNESS



Wire Chart

CAV  TERMINAL  CSA  COL  CCT  DESTN

30

YPL10081

4.0D NS

499

C1217

85

AFU3120

1.0D BO

499

C0872

86

YPL10081

4.0D WR

200R C0090R

86

YPL10081

4.0D WR

139L C0090L

87

YPL10045

2.5D NR

499

C0448

Service Repair Kits

Connector: C0162

Description: Engine harness to main harness

Location: LH side of engine compartment





Part No.:

YPC911100



Colour: BLACK

Cavities: 14WY

Harness:

ENGINE DIESEL PUMA HARNESS



Wire Chart

CAV  TERMINAL  CSA  COL  CCT  DESTN

G

YPJ901130

1.0

BG

254

C0127

A

YPJ901130

0.75 BY

254

C0411

B

YPJ901130

0.75 BY

254

C2518

D

YPJ901130

0.75 B

254

C0195

M

YPJ901030

2.5

NG

254

C0179

C

YPJ901030

1.5

UW

254

C0411

J

YPJ901030

1.5

UW

254

C2518

H

YPJ901120

0.5

SP

254

C0149

K

YPJ901120

0.5

UO

254

C0195

F

YPJ901130

0.75 R

254

C0163

L

YPJ901130

1.0

UN

254

C0127

N

YPJ901130

0.75 G

254

S/JOINT 1

E

YPJ901130

0.75 OS

254

C0163

Service Repair Kits

Connector: C0163

Description: Switch-Reverse-lamp

Location: LH side of gearbox





Part No.:

YPC500750



Colour:

Cavities:

Harness:

ENGINE DIESEL PUMA HARNESS



Wire Chart

CAV  TERMINAL  CSA  COL  CCT  DESTN

1

YPL500410

0.75 OS

254

C0162

2

YPL500410

0.75 R

254

C0162

Service Repair Kits
