C1200

CONNECTOR

DEFENDER 1999 MY

Illumination - Heater control
- RH

Female
TIN-PLATE

Behind instrument pack

P5761

C1294

C1061 C1054

C1052

C1200

Cav

Col

CCT

1

RO

ALL

CONNECTOR

C1210

DEFENDER 1999 MY

Earth

Female
BLACK

Front of headlining in the
centre

P5602

C0355

C1210

Cav

Col

CCT

1

B

ALL

C1211

CONNECTOR

DEFENDER 1999 MY

Main harness to interior
lamp harness

Male
NATURAL

Headlining - front RH side

P5776

C1211

C0488

C0727

Cav

Col

CCT

1

B

ALL

2

PW

ALL

3

P

ALL

4

PU

ALL

CONNECTOR

C1260

DEFENDER 1999 MY

Trailer pick-up

Male
DARK GREY

Below RH rear wheelarch

P5582

C0929

C1260

C1305

C1306

C1095

C0942

C0350

Cav

Col

CCT

1

GR

ALL

2

RB

ALL

3

GW

ALL

4

RO

ALL

5

GP

ALL

6

P

ALL

7

GN

ALL

8

RY

ALL

9

B

ALL
