Defender Electric Diagrams. Manual - part 159

C0685

CONNECTOR

DEFENDER 1999 MY

Switch - Transmision -
High-Low

Female
LIGHT GREY

LH side of transfer box

P5590

C0685

C0556
C0557

Cav

Col

CCT

1

WB

ALL

3

B

ALL

CONNECTOR

C0704

DEFENDER 1999 MY

Chassis harness to tail door
harness

Female
NATURAL

RH side of taildoor, behind
trim panel

P5601

C0512

C0455

C0704

C1102

Cav

Col

CCT

1

WG

ALL

2

NLG

ALL

3

RLG

ALL

C0719

CONNECTOR

DEFENDER 1999 MY

Sensor - Volumetric

Female
BLACK

Behind headlining top of RH
’B’ post

P5604

C0719

Cav

Col

CCT

1

BN

ALL

2

B

15

3

WB

ALL

CONNECTOR

C0727

DEFENDER 1999 MY

Main harness to interior
lamp harness

Female
NATURAL

Headlining - front RH side

P5776

C1211

C0488

C0727

Cav

Col

CCT

1

B

15

2

PW

17

2

PW

16

3

PN

17

3

PN

16

4

PU

17

4

PU

16
