MULTIMEDIA

217

PHONEBOOK DOWNLOAD (AUTOMATIC

PHONEBOOK TRANSFER FROM MOBILE

PHONE) — IF EQUIPPED

If supported by your phone, Uconnect Phone has the

ability to download contact names and number entries

from the mobile phone’s phonebook. Specific Bluetooth®

Phones with Phonebook Access Profile may support this

feature. Your mobile phone may receive a pop-up asking

for permission for the Uconnect system to access your

messages and contacts. Selecting “Ok” or “Allow” will sync

your contacts with the Uconnect system.
See the Uconnect website, UconnectPhone.com, for

supported phones.



To call a name from a downloaded mobile phonebook

page 221.



Automatic download and update of a phonebook, if

supported, begins as soon as the Bluetooth® wireless

phone connection is made to the Uconnect Phone, for

example, after you start the vehicle.



A maximum of 5,000 contact names with four numbers

per contact will be downloaded and updated every time

a phone is connected to the Uconnect Phone.



Depending on the maximum number of entries down

loaded, there may be a short delay before the latest

downloaded names can be used. Until then, if avail

able, the previously downloaded phonebook is avail

able for use.



Only the phonebook of the currently connected mobile

phone is accessible.



This downloaded phonebook cannot be edited or

deleted on the Uconnect Phone. These can only be

edited on the mobile phone. The changes are trans

ferred and updated to Uconnect Phone on the next

phone connection.

MANAGING YOUR FAVORITES — IF EQUIPPED

There are two ways you can add an entry to your favorites:
1. After loading the mobile phonebook, press the

Favorites button on the touchscreen, and then press

one of the +Add Favorite Contact buttons that

appears on the list.

2. After loading the mobile phonebook, select

“Contacts” from the Phone main screen, and then

select the appropriate number. Press the Down Arrow

button or the Settings Gear button next to the

selected number to display the option’s pop-up. In the

pop-up, select “Add to Favorites”.

NOTE:

If the Favorites list is full, you will be asked to remove an

existing favorite.

TO REMOVE A FAVORITE — IF EQUIPPED

1. To remove a Favorite, select “Favorites” from the

Phone main screen.

2. Next, select the Down Arrow icon or the Settings Gear

icon next to the contact you want to remove from your

favorites. This will bring up the options for that

Favorite contact.

3. Deselect the Star icon to delete the Favorite.

Phone Call Features

The following features can be accessed through the

Uconnect Phone if the feature(s) are available and

supported by Bluetooth® on your mobile service plan. For

example, if your mobile service plan provides three-way

calling, this feature can be accessed through the

Uconnect Phone. Check with your mobile service provider

for the features that you have.
Here are the phone options with Uconnect:



Redial



Dial by pressing in the number



Voice Commands (Dial by Saying a Name, Call by

Saying a Phonebook Name, Redial or Call Back)



Favorites



Mobile Phonebook



Recent Call Log



SMS Message Viewer

218

MULTIMEDIA

CALL CONTROLS

The touchscreen allows you to control the following call

features:

Uconnect 3 With 5-inch Display

Uconnect 4 With 7-inch Display

Other phone call features include:



End Call



Hold/Unhold/Resume



Swap two active calls

KEY PAD NUMBER ENTRY

1. Press the Phone button.
2. Press the Dial/Keypad button on the touchscreen.
3. The Touch-Tone screen will be displayed.
4. Use the numbered buttons on the touchscreens to

enter the number and press “Dial/Call”.

RECENT CALLS — IF EQUIPPED

You may browse a list of the most recent of each of the

following call types:



All Calls



Incoming Calls or Calls Received



Outgoing Calls or Calls Made



Missed Calls

These can be accessed by pressing the Recent Calls

button on the phone main screen.
You can also push the VR button on your steering wheel

and perform the operation. For example, say “Show my

incoming calls”.

1 — Answer
2 — Mute/Unmute
3 — Ignore
4 — Transfer

1 — Answer
2 — End
3 — Mute/Unmute
4 — Transfer
5 — Join Calls

MULTIMEDIA

219

ANSWER OR IGNORE AN INCOMING CALL —

NO CALL CURRENTLY IN PROGRESS

When you receive a call on your mobile phone, the

Uconnect Phone will interrupt the vehicle audio system.

Push the Phone button on the steering wheel, press the

Answer button on the touchscreen.
You can also press the Caller ID box to place the current

call on hold or answer the incoming call.

Uconnect 3 With 5-inch Display

Uconnect 4 With 7-inch Display

ANSWER OR IGNORE AN INCOMING CALL —

CALL CURRENTLY IN PROGRESS

If a call is currently in progress and you have another

incoming call, you will hear the same network tones for

call waiting that you normally hear when using your mobile

phone. Push the Phone button on the steering wheel,

press the Answer button on the touchscreen, or press the

Caller ID box to place the current call on hold and answer

the incoming call.

NOTE:

Phones that are compatible with the Uconnect system in

the market today do not support rejecting an incoming call

when another call is in progress. Therefore, the user can

only answer an incoming call or ignore it.

DO NOT DISTURB

With Do Not Disturb, you can disable notifications from

incoming calls and texts, allowing you to keep your eyes on

the road and hands on the wheel. For your convenience,

there is a counter display to keep track of your missed

calls and text messages while Do Not Disturb is active.
Do Not Disturb can automatically reply with a text

message, a call, or both when declining an incoming call

and send it to voicemail.
Automatic reply messages can be:



“I am driving right now, I will get back to you shortly”.



Create a custom auto reply message up to 160 charac

ters.

NOTE:

Only the first 25 characters can be seen on the touch

screen while typing a custom message.
While in Do Not Disturb, “Conference Call” can be selected

so you can still place a second call without being

interrupted by incoming calls.

NOTE:



Reply with text message is not compatible with

iPhone® devices.



Auto reply with text message is only available on

phones that support Bluetooth® Message Access

Profile (MAP).

PLACE/RETRIEVE A CALL FROM HOLD

During an active call, press the Hold or Call On Hold button

on the Phone main screen.

1 — Answer Button
2 — Caller ID Box

220

MULTIMEDIA

MAKING A SECOND CALL WHILE CURRENT

CALL IS IN PROGRESS

You can place a call on hold by pressing the Hold button

on the Phone main screen, then dial a number from the

keypad (if supported by your mobile phone), recent calls,

SMS Inbox or from the phonebooks.

TOGGLING BETWEEN CALLS

Uconnect 3 With 5-inch Display

Uconnect 4 With 7-inch Display

If two calls are in progress (one active and one on hold),

press the Swap Calls button on the phone main screen.

Only one call can be placed on hold at a time.
You can also push the Phone button to toggle between the

active and held phone call.

JOIN CALLS

When two calls are in progress (one active and one on

hold), press the Join/Merge Calls button on the Phone

main screen to combine all calls into a conference call.

CALL TERMINATION

To end a call in progress, momentarily press the End Call

button on the touchscreen or the Phone End button on the

steering wheel. Only the active call(s) will be terminated

and if there is a call on hold, it will become the new active

call.

REDIAL

Push the VR button and after the “Listening”

prompt and the following beep, say “Redial.”

The Uconnect Phone will call the last number that was

dialed from your mobile phone.

CALL CONTINUATION

Call continuation is the progression of a phone call on the

Uconnect Phone after the vehicle ignition has been

switched to OFF.

NOTE:

The call will remain within the vehicle audio system until

the phone becomes out of range for the Bluetooth®

connection. It is recommended to press the Transfer

button on the touchscreen when leaving the vehicle.

Advanced Phone Connectivity

TRANSFER CALL TO AND FROM MOBILE

PHONE

The Uconnect Phone allows ongoing calls to be

transferred from your mobile phone without terminating

the call. To transfer an ongoing call from your connected

mobile phone to the Uconnect Phone or vice versa, press

the Transfer button on the Phone main screen.

Things You Should Know About Uconnect

Phone

VOICE COMMAND

For the best performance:



Always wait for the beep before speaking



Speak normally, without pausing, just as you would

speak to a person sitting a few feet/meters away from

you



Ensure that no one other than you is speaking during a

voice command period



Low-To-Medium Blower Setting



Low-To-Medium Vehicle Speed



Low Road Noise



Smooth Road Surface



Fully Closed Windows



Dry Weather Conditions

MULTIMEDIA

221

Even though the system is designed for many languages

and accents, the system may not always work for some.

NOTE:

It is recommended that you do not store names in your

Favorites phonebook while the vehicle is in motion.
Number and name recognition rate is optimized when the

entries are not similar. You can say “O” (letter “O”) for “0”

(zero).
Even though international dialing for most number

combinations is supported, some shortcut dialing number

combinations may not be supported.
Audio Performance
Audio quality is maximized under:



Low-To-Medium Blower Setting



Low-To-Medium Vehicle Speed



Low Road Noise



Smooth Road Surface



Fully Closed Windows



Dry Weather Conditions



Operation From The Driver's Seat

Performance such as audio clarity, echo, and loudness to

a large degree rely on the phone and network, and not the

Uconnect Phone.
Echo at the far end can sometimes be reduced by lowering

the in-vehicle audio volume.

PHONE VOICE COMMANDS

Making and answering hands-free phone calls is easy with

Uconnect. When the Phonebook button is illuminated on

your touchscreen, your system is ready. Check

UconnectPhone.com for mobile phone compatibility and

pairing instructions.
Push the Phone button

and wait for the beep to say a

command. Here are some examples:



“Call John Smith”



“Dial 123 456 7890”



“Redial” (call previous outgoing phone number)



“Call back” (call previously answered incoming phone

number)

Did You Know: When providing a Voice Command, push

the Phone button

and say “Call”, then pronounce the

name exactly as it appears in your phonebook. When a

contact has multiple phone numbers, you can say “Call

John Smith work”.

VOICE TEXT REPLY — IF EQUIPPED

Uconnect can announce incoming text messages. Push

the VR button

or Phone button

and say:

1. “Listen” to have the system read an incoming text

message. (Must have compatible mobile phone

paired to Uconnect system.)

2. “Reply” after an incoming text message has been

read.
Listen to the Uconnect prompts. After the beep, re

peat one of the predefined messages and follow the

system prompts.

NOTE:

Only use the numbering listed in the provided table.

Otherwise, the system will not transpose the message.
Did You Know: Your mobile phone must have the full

implementation of the Message Access Profile (MAP) to

take advantage of this feature. For details about MAP, visit

UconnectPhone.com.
Apple® iPhone® iOS 5 or later supports reading incoming

text messages only. For further information on how to

enable this feature on your Apple® iPhone®, refer to your

iPhone® “User Manual”.

WARNING!

ALWAYS drive safely with your hands on the wheel. You

have full responsibility and assume all risks related to

the use of the Uconnect features and applications in

this vehicle. Only use Uconnect when it is safe to do so.

Failure to do so may result in an accident involving

serious injury or death.

PRE-DEFINED VOICE TEXT REPLY RESPONSES

Yes.

Stuck in traffic.

See you later.

No.

Start without

me.

I’ll be late.

Okay.

Where are you?

I will be 5 <or

10, 15, 20, 25,

30, 45, 60>

minutes late.

Call me.

Are you there

yet?

I’ll call you later.

I need

directions.

See you in 5 <or

10, 15, 20, 25,

30, 45, 60>

minutes.

I’m on my way.

Can’t talk right

now.

I’m lost.

Thanks.

222

MULTIMEDIA

Did You Know: Voice Text Reply is not compatible with

iPhone®, but if your vehicle is equipped with Siri® Eyes

Free, you can use your voice to send a text message.

SIRI® EYES FREE — IF EQUIPPED

When used with your Apple® iPhone® connected to your

vehicle via Bluetooth®, Siri lets you use your voice to send

text messages, select media, place phone calls and much

more. Siri uses your natural language to understand what

you mean and responds back to confirm your requests.

The system is designed to keep your eyes on the road and

your hands on the wheel by letting Siri help you perform

useful tasks.
To enable Siri, push and hold, then release the Uconnect

Voice Recognition (VR) button on the steering wheel. After

you hear a double beep, you can ask Siri to play podcasts

and music, get directions, read text messages, and many

other useful requests.

BLUETOOTH® COMMUNICATION LINK

Mobile phones may lose connection to the Uconnect

Phone. When this happens, the connection can generally

be re-established by restarting the mobile phone. Your

mobile phone is recommended to remain in Bluetooth®

ON Mode.

POWER-UP

After switching the ignition key from OFF to either the ON/

RUN or ACC position, or after a language change, you must

wait at least 15 seconds prior to using the system

page 381.

ANDROID AUTO™ & APPLE CARPLAY® —

IF EQUIPPED

NDROID

UTO

™

Use this QR code to access your digital

experience.
Android Auto™ is a feature of your

Uconnect system, and your Android™

6.0 or higher powered smartphone

with a data plan, that allows you to

project your smartphone and a number

of its apps onto the touchscreen radio

display. Android Auto™ brings you useful information, and

organizes it into simple cards that appear just when they

are needed. Android Auto™ can be used with speech

technology, the steering wheel controls, the knobs and

buttons on your radio faceplate, and the radio display’s

touchscreen to control many of your apps. To use Android

Auto™, perform the following procedure:

NOTE:

Feature availability depends on your carrier and mobile

phone manufacturer. Some Android Auto™ features may

or may not be available in every region and/or language.
1. Download the Android Auto™ app from the Google

Play store on your Android™-powered smartphone.

2. Connect your Android™-powered smartphone to one

of the media USB ports in your vehicle. If the Android

Auto™ app was not downloaded, the first time you

plug your device in the app begins to download. Your

vehicle should be in PARK the first time you use the

app.

NOTE:

Be sure to use the factory-provided USB cable that came

with your phone, as aftermarket cables may not work.

Android Auto™ And LTE Data Coverage

NOTE:

To use Android Auto™, make sure you are in an area with

cellular coverage. Android Auto™ may use cellular data

and your cellular coverage is shown in the upper right

corner of the radio screen. Data plan rates apply.
3. Once the device is connected and recognized, the

Phone icon on the drag & drop menu bar changes to

the Android Auto™ icon.

MULTIMEDIA

223

NOTE:

Android Auto™ is set to launch immediately once a

compatible device is connected. You can also launch it by

pressing the Android Auto™ icon on the touchscreen.
Once Android Auto™ is up and running on your Uconnect

system, the following features can be utilized using your

smartphone’s data plan:



Google Maps™ for navigation



YouTube Music, Spotify, iHeart Radio, etc. for music



Hands-free calling and texting for communication



Various compatible apps

Maps

Push and hold the Voice Recognition (VR)

button on the steering wheel until the beep or

tap the Microphone icon to ask Google to take

you to a desired destination by voice. You can

also touch the Navigation icon in Android Auto™ to access

other navigation apps.
While using Android Auto™, Google Maps™ provides

voice-guided:



Navigation



Live traffic information



Lane guidance

For further information, refer to www.android.com/auto/

(US) or https://www.android.com/intl/en_ca/auto/

(Canada).
For further information on the navigation function, please

refer to https://support.google.com/android or https://

support.google.com/androidauto/.

Music

Android Auto™ allows you to access and

stream your favorite music with apps like

YouTube Music, iHeartRadio, and Spotify.

Using your smartphone’s data plan, you can

stream endless music on the road.

NOTE:

Music apps, playlists, and stations must be set up on your

smartphone prior to using Android Auto™ for them to work

with Android Auto™.

NOTE:

To see the track details for the music playing through

Android Auto™, select the Uconnect system’s media

screen.
For further information, refer to https://

support.google.com/androidauto.

Communication

With Android Auto™ connected, push and hold

the VR button on the steering wheel to activate

voice recognition specific to Android Auto™.

This allows you to send and reply to text

messages, have incoming text messages read out loud,

and place and receive hands-free calls.

Apps

The Android Auto™ App displays all the compatible apps

that are available to use with Android Auto™, every time it

is launched. You must have the compatible app

downloaded, and you must be signed in to the app through

your mobile device for it to work with Android Auto™.
Refer to https://play.google.com/store/apps/ to see the

latest list of available apps for Android Auto™.

Android Auto™ Voice Command

NOTE:

Feature availability depends on your carrier and mobile

phone manufacturer. Some Android Auto™ features may

or may not be available in every region and/or language.
Android Auto™ allows you to use your voice to interact with

its best-in-class speech technology through your vehicle’s

voice recognition system, and use your smartphone’s data

plan to project your Android™-powered smartphone and a

number of its apps onto your Uconnect touchscreen.

Connect your Android™ 6.0 or higher to one of the media

USB ports, using the factory-provided USB cable, and

press the new Android Auto™ icon that replaces your

Phone icon on the main menu bar to begin Android Auto™.

Push and hold the VR button on the steering wheel, or

press and hold the Microphone icon within Android Auto™,

to activate its VR, which recognizes natural voice

commands, to use a list of your smartphone’s features:



Maps



Music



Phone



Text Messages



Additional Apps

NOTE:



To use Android Auto™ on your car display, you’ll need

an Android™ phone running Android™ 6.0 or higher, an

active data plan, and the Android Auto™ app.



To wirelessly use Android Auto™ on your car display,

you need a compatible Android™ smartphone with an

active data plan. You can check which smartphones

are compatible at g.co/androidauto/requirements.

Android™ is a trademark of Google Inc.

224

MULTIMEDIA

PPLE

LAY

Use this QR code to access your digital

experience.
Uconnect works seamlessly with Apple

CarPlay®, the smarter, more secure

way to use your iPhone® in the car, and

stay focused on the road. Use your

Uconnect Touchscreen display, the

vehicle's knobs and controls, and your

voice with Siri to get access to Apple Music®, Maps,

Messages, and more.

NOTE:

Feature availability depends on your carrier and mobile

phone manufacturer. Some Apple CarPlay® features may

or may not be available in every region and/or language.
To use Apple CarPlay®, make sure you are using iPhone®

5 or later, have Siri enabled in Settings, ensure your

iPhone® is unlocked for the very first connection only, and

then use the following procedure:
1. Connect your iPhone® to one of the media USB

ports in your vehicle.

NOTE:

Be sure to use the factory-provided Lightning cable that

came with your phone, as aftermarket cables may not

work.
2. Once the device is connected and recognized, the

Phone icon on the drag & drop menu bar changes to

the Apple CarPlay® Icon.

NOTE:

Apple CarPlay® is set to launch immediately. You can also

launch it by pressing the Apple CarPlay® icon on the

touchscreen.

Apple CarPlay® And LTE Data Coverage

NOTE:

To use Apple CarPlay®, make sure that cellular data is

turned on, and that you are in an area with cellular

coverage. Your data and cellular coverage is shown on the

left side of the radio screen. Data plan rates apply.

Once Apple CarPlay® is up and running on your Uconnect

system, the following features can be utilized using your

iPhone® data plan:



Phone



Music



Messages



Maps

Phone

With Apple CarPlay®, push and hold the VR

button on the steering wheel to activate a Siri

voice recognition session. You can also press

and hold the Home button within Apple

CarPlay® to start talking to Siri. This allows you to make

calls or listen to voicemail as you normally would using Siri

on your iPhone®.

NOTE:

Only temporarily pushing the VR button on the steering

wheel launches a built-in Uconnect VR session, not a Siri

session, and it will not function with Apple CarPlay®.

Music

Apple CarPlay® allows you to access all your

artists, playlists, and music from iTunes® or

any third party application installed on your

device. Using your iPhone® data plan, you can

also use select third party audio apps including music,

news, sports, podcasts, and more.

Messages

Push and hold the VR button on the steering

wheel to activate a Siri voice recognition

session. Apple CarPlay® allows you to use Siri

to send or reply to text messages. Siri can also

1 — LTE Data Coverage
2 — Apple CarPlay® Icon

MULTIMEDIA

225

read incoming text messages, but drivers will not be able

to read messages, as everything is done via voice.

Maps

Push and hold the VR button on the steering

wheel until the beep or tap the Microphone

icon to ask Apple® Siri to take you to a desired

destination by voice. You can also touch the

Navigation icon in Apple CarPlay® to access Apple®

Maps.

Apps

The Apple CarPlay® App plays all compatible apps that are

available to use, every time it is launched. You must have

the compatible app downloaded, and you must be signed

in to the app through your mobile device for it to work with

Apple CarPlay®.
Refer to http://www.apple.com/ios/carplay/ (US) or

https://www.apple.com/ca/ios/carplay/ (Canada) to see

the latest list of available apps for Apple CarPlay®.

Apple CarPlay® Voice Command

NOTE:

Feature availability depends on your carrier and mobile

phone maker. Some Apple CarPlay® features may not be

available in every region and/or language.
Apple CarPlay® allows you to use your voice to interact

with Siri through your vehicle’s voice recognition system,

and use your smartphone’s data plan to project your

iPhone® and a number of its apps onto your Uconnect

touchscreen. Connect your iPhone® 5 or higher to one of

the media USB ports, using the factory-provided Lightning

cable, and press the new Apple CarPlay® icon that

replaces your Phone icon on the main menu bar to begin

Apple CarPlay®. Push and hold the VR button on the

steering wheel, or press and hold the Home button within

Apple CarPlay®, to activate Siri, which recognizes natural

voice commands to use a list of your iPhone® features:



Phone



Music



Messages



Maps — If Equipped



Additional Apps — If Equipped

NOTE:

Apple CarPlay® is a trademark of Apple® Inc. iPhone® is

a trademark of Apple® Inc., registered in the US and other

countries. Apple® terms of use and privacy statements

apply.

NDROID

UTO

™ A

PPLE

LAY

® T

IPS

RICKS

Android Auto™ And Apple CarPlay® Automatic Bluetooth®

Pairing
After connecting to Android Auto™ or Apple CarPlay® for

the first time and undergoing the setup procedure, the

smartphone pairs to the Uconnect system via Bluetooth®

without any setup required every time it is within range, if

Bluetooth® is turned on.

NOTE:

Apple CarPlay® uses a USB connection while Android

Auto™ uses both USB and Bluetooth® connections to

function. The connected device is unavailable to other

devices when connected using Android Auto™ or Apple

CarPlay®.

Multiple Devices Connecting To The Uconnect System — If

Equipped
It is possible to have multiple devices connected to the

Uconnect system. For example, if using Android Auto™/

Apple CarPlay®, the connected device will be used to

place hands-free phone calls or send hands-free text

messages. However, another device can also be paired to

the Uconnect system, via Bluetooth®, as an audio source,

so the passenger can stream music.

NOTE:

Apple CarPlay® and Android Auto™ can only be launched

from the front and center console USB ports.

CONNECTED VEHICLE SERVICES —

IF EQUIPPED

EHICLE

ONNECTED

If equipped, vehicles with an ASSIST and an SOS button

are connected vehicles. These buttons will be located on

either the rearview mirror or overhead console, depending

on the vehicle. If these buttons are present in your vehicle,

you have a connected radio and can take advantage of the

many connected vehicle features.
For further information about the ASSIST and SOS buttons

page 291.

226

MULTIMEDIA

NTRODUCTION

ONNECTED

EHICLE

ERVICES

One of the many benefits of your vehicle’s Uconnect

system is that you can now take advantage of SiriusXM

Guardian™ connected services. To unlock the full

potential of SiriusXM Guardian™ in your vehicle, you first

need to activate SiriusXM Guardian™ connected services.

NOTE:

SiriusXM Guardian™ involves the collection, transmission

and use of data from your vehicle

page 240.

SiriusXM Guardian™ Contact Information

SiriusXM Guardian™/Care



US residents visit: https://www.driveuconnect.com/

sirius-xm-guardian.html or call 1-844-796-4827



Canadian residents visit: https://www.driveucon

nect.ca/en/sirius-xm-guardian or call 1-877-324-9091

What Is SiriusXM Guardian™?

SiriusXM Guardian™ uses an embedded device in the

Uconnect system installed in your vehicle, which receives

GPS signals and communicates with the SiriusXM

Guardian™ Customer Care center via wireless and

landline communications networks. Depending on the

type of device in your vehicle, some SiriusXM Guardian™

connected services require an operable LTE (voice/data)

or 4G (data) network compatible with your device.

SiriusXM Guardian™ is available only on equipped

vehicles purchased within the continental United States,

Alaska, Hawaii, Puerto Rico and Canada.

NOTE:



Certain SiriusXM Guardian™ connected services are

dependent upon an operative telematics device, a

cellular connection, navigation map data, and GPS

satellite signal reception, which can limit the ability to

reach the response center or reach emergency

support.



Not all features of SiriusXM Guardian™ are available

everywhere at all times, particularly in remote or

enclosed areas.



Other factors outside the control of SiriusXM

Guardian™ that may limit or prevent service delivery

are hills, structures, buildings, tunnels, weather,

damage to the electrical system or other important

parts of your vehicle, network congestion, civil distur

bances, actions of third parties or the government,

Internet failure, and/or the physical location of your

vehicle, such as in an underground parking structure or

under a bridge.

Not all SiriusXM Guardian™ features are available for all

models.
SiriusXM Guardian™ provides:



The ability to remotely lock/unlock and remote start

your vehicle from virtually anywhere by using the

Vehicle Branded App or your computer.



If equipped — Send & Go capability with the Vehicle

Branded App. Use the Vehicle Branded App to easily

search, map and send your locations directly to your

Uconnect Navigation.



The ability to locate your vehicle, when you forget

where you parked, using the Vehicle Finder function of

the Vehicle Branded App.

Before you drive, familiarize yourself with the easy-to-use

Uconnect system and SiriusXM Guardian™ connected

services.
The ASSIST and SOS Call Buttons On Your Rearview Mirror

Or Overhead Console
If equipped, the ASSIST Button is used for contacting

Roadside Assistance, Vehicle Care, Uconnect Care, and

SiriusXM Guardian™ Customer Care. The SOS Call button

connects you directly to SiriusXM Guardian™ Customer

Care for assistance in an emergency.

Activation — If Equipped

To unlock the full potential of SiriusXM Guardian™ in your

vehicle, you must activate your SiriusXM Guardian™

connected services.
1. Press the Apps icon on the bottom of your in-vehicle

touchscreen.

2. Select the Activate Services icon from your list of

apps.

3. For customers in the United States, select “Customer

Care” to speak with a SiriusXM Guardian™ Customer

Care agent who will activate services in your vehicle,

or select “Enter Email” to activate on the web.
For customers in Canada, enter your email address to

activate services in your vehicle.

WARNING!

ALWAYS obey traffic laws and pay attention to the road.

Your complete attention is always required while driving

to maintain safe control of your vehicle. Only use and

interact with the features and applications when it is

safe to do so. Failure to follow these warnings can

result in a collision and death or serious personal

injury.

MULTIMEDIA

227

Included Trial Period For New Vehicles

Your new vehicle may come with an included trial* period

for use of SiriusXM Guardian™ connected services

starting on the date of vehicle purchase. To get started

with your trial, enrollment in SiriusXM Guardian™ is

required.
* Included trial applies to new vehicles only.

Features And Packages

After the trial period, you must purchase a subscription to

continue your services by calling a SiriusXM Guardian™

Customer Care agent.

ETTING

TARTED

ITH

ONNECTED

EHICLE

ERVICES

Download The Vehicle Branded App

Once you have activated your services, you’re only a few

steps away from using connected services.



Download the Vehicle Branded App to your mobile

device.



Use your Owner Account login and password to open

the app and then set up a PIN.



For customers in the United States, if your vehicle is not

registered at the dealership, you will have to call the

Customer Care call center from inside your vehicle or

press the in-vehicle registration button. From there,

you will be able to register your vehicle and add your

vehicle’s VIN to your account.



For customers in Canada, register your account via

your vehicle.

a. Press the Apps button in the bottom menu bar.
b. Press the Activate Services button from the apps

list.

c. Enter your email and press “OK”. A confirmation

email will be sent to the provided email address.

d. Press “Continue Activation” from the confirmation

email. It may take a short time before remote

services will be available, but you will be able to

log into the Vehicle Branded App and the Owner’s

Site.



Once on the Remote screen and you have set up your

four-digit PIN, you can begin using Remote Door Lock/

Unlock, Remote Vehicle Start, and activate your horn

and lights remotely, if equipped.



Press the Location button on the bottom menu bar of

the app to bring up a map to locate your vehicle or send

a location to your Mobile Navigation, if equipped.



Press the Settings side menu in the upper left corner of

the app to bring up app settings and access the Assist

Call Centers.

Using Your Owner’s Site

Your Owner’s Site website https://www.mopar.com/

en-us.html (US Residents), or www.mopar.ca (Canadian

Residents) provides you with all the information you need,

all in one place. You can track your service history, find

recommended accessories for your vehicle, watch videos

about your vehicle's features, and easily access your

manuals. It is also where you can manage your SiriusXM

Guardian™ account. This section will familiarize you with

the key elements of the website that will help you get the

most of your SiriusXM Guardian™ connected services.
For customers in the United States, press the Sign In/

password.

228

MULTIMEDIA

For customers in Canada, press the My Vehicle button.

Select from “Dashboard”, “Vehicle Health Report”, and

“Recalls”. The website will then prompt you to log in using

your email address and password.



Edit/Edit Profile:
To manage the details of your SiriusXM Guardian™

account, such as your contact information, password

and SiriusXM Guardian™ PIN, click on the Edit/Edit

Profile button to access the details of your account.



Connected Services Status:
This statement will indicate your SiriusXM

Guardian™-equipped vehicle.



Remote Commands:
For vehicles with an active SiriusXM Guardian™

subscription, press one of these icons and enter your

four-digit SiriusXM Guardian™ Security PIN to remotely

start (if equipped), lock/unlock doors or sound the horn

and flash the lights.

Editing Your Notifications
Notifications are an important element of your SiriusXM

Guardian™ account. For example, any time you use your

remote services (such as Remote Door Unlock), you can

elect to receive a text message, push notification, and/or

E-mail to notify you of the event. To set up the

notifications, please follow these instructions.
1. Log on to your Owner’s Account at https://

www.mopar.com/en-us.html (US Residents) and

select “Dashboard”, or www.mopar.ca (Canadian

Residents), select “My Vehicle” and then

“Dashboard”.

2. Click the Edit/Edit Profile button.

3. Once there, select “SiriusXM Guardian™” where you

can edit Notification Preferences.

4. You can enter a mobile phone and/or email address

to notify you, and you can customize the types of

messages.

SING

IRIUS

XM G

UARDIAN

™

SOS Call — If Equipped

Access To Emergency Services At The Push Of A Button

SiriusXM Guardian™ In-Vehicle Assistance Features
With SiriusXM Guardian™, your vehicle has onboard

assistance features located on the rearview mirror or

overhead console designed to enhance your driving

experience if you should ever need assistance or support.

Description
SOS Call offers a convenient way to get in contact with a

SiriusXM Guardian™ Customer Care agent in the event of

an emergency. When the connection between the vehicle

and the live agent is made, your vehicle will automatically

transmit location information. In the event of a minor

collision, medical or any other emergency, press the SOS

button to be connected to a call center agent who can

send emergency assistance to your vehicle’s location.

NOTE:

Certain SiriusXM Guardian™ connected services are

dependent on an operational Uconnect system, cellular

network availability that is compatible with the device in

your vehicle, and GPS network availability. Not all features

of SiriusXM Guardian™ are available everywhere at all

times, particularly in remote or enclosed areas.
How It Works
1. Push the SOS Call button; the indicator light will turn

green indicating a call has been placed.

NOTE:



In case the SOS Call button is accidentally pushed,

there is a 10-second delay before the SOS call is

placed. The system will verbally alert you that a call

is about to be made. To cancel the SOS Call connec

tion, push the SOS Call button on the rearview

mirror or overhead console or press the Cancel

button on the touchscreen within 10 seconds.



During an SOS Call, the Bluetooth®-paired phone

is disconnected so incoming or outgoing calls will

go through your mobile device versus the

hands-free system which is not available due to

the SOS Call.

WARNING!

Some SiriusXM Guardian™ connected services,

including SOS Call and Roadside Assistance Call, will

NOT work without a network connection compatible

with your device.

Center Light Status

Description

Off

No call activated

Green

Active call in progress

Red

System error

MULTIMEDIA

229

(Continued)

2. Once a connection between the vehicle and a

SiriusXM Guardian™ Customer Care agent is made,

the agent will stay on the line with you.

NOTE:

Calls between the vehicle occupants and the SiriusXM

Guardian™ Customer Care center may be recorded or

monitored for quality assurance purposes. Through your

enrollment in and use of the SiriusXM Guardian™

connected services, you consent to being recorded.

SOS Call System Limitations
Vehicles that have been purchased in the US and that

travel into Mexico and Canada may have limited services.

In particular, responses to SOS calls or other emergency

services may be unavailable or very limited. Vehicles

purchased outside the United States and Canada are

unable to receive SiriusXM Guardian™ connected

services.
If the SOS Call system detects a malfunction, any of the

following may occur at the time the malfunction is

detected:



The light will continuously be illuminated red.



The screen will display the following message “Vehicle

phone requires service. Please contact your dealer.”



An in-vehicle audio message will state “Vehicle phone

requires service. Please contact your dealer.”

Even if the SOS Call system is fully functional, factors

beyond FCA US LLC’s control may prevent or stop SOS Call

system operation. These include, but are not limited to,

the following factors:



The ignition key is in OFF position.



The vehicle’s electrical systems are not intact.



The vehicle battery loses power or becomes discon

nected during a vehicle crash.



The SOS Call system software and/or hardware is

damaged during a vehicle crash.



LTE (voice/data) or 4G (data) coverage and/or GPS

signals are unavailable or obstructed.



Network congestion.



Weather conditions.



Buildings, structures, geographic terrain, or tunnels.

If your vehicle loses battery power for any reason

(including during or after an accident), the SOS Call

system, among other vehicle systems, will not operate.
Requirements



This feature is available only on vehicles sold in the US

or Canada.



Vehicle must be properly equipped with the SiriusXM

Guardian™ connected services. Vehicle must be regis

tered with SiriusXM Guardian™ and have an active

subscription that includes the applicable feature.



Vehicle must have an operable LTE (voice/data) or 4G

(data) network connection compatible with your device.



Vehicle must be powered in the ON/RUN or ACC (Acces

sory) position with a properly functioning electrical

system.

WARNING!



Never place anything on or near the vehicle’s LTE

(voice/data) or 4G (data) and GPS antennas. You

could prevent LTE (voice/data) or 4G (data) and GPS

signal reception, which can prevent your vehicle from

placing an emergency call.



Do not add any aftermarket electrical equipment to

the vehicle’s electrical system. This may prevent your

vehicle from sending a signal to initiate an emer

gency call. To avoid interference that can cause the

SOS Call system to fail, never add aftermarket equip

ment (e.g., two-way mobile radio, CB radio, data

recorder, etc.) to your vehicle’s electrical system or

modify the antennas on your vehicle. IF YOUR

VEHICLE LOSES POWER FOR ANY REASON

(INCLUDING DURING OR AFTER AN ACCIDENT),

NEITHER THE VEHICLE BRANDED APPS NOR THE

SIRIUSXM GUARDIAN™ CONNECTED SERVICES WILL

OPERATE.



The Occupant Restraint Controller (ORC) turns on the

Air Bag Warning Light on the instrument panel if a

malfunction in any part of the air bag system is

detected. If the Air Bag Warning Light is illuminated,

the air bag system may not be working properly and

the SOS Call system may not be able to send a signal

to the SiriusXM Guardian™ Customer Care center. If

the Air Bag Warning Light is illuminated, have an

authorized dealer service your vehicle immediately.



Ignoring the Rearview Mirror Light could mean you

will not have SOS Call services if needed. If the Rear

view Mirror Light is illuminated, have an authorized

dealer service the SOS Call system immediately.

WARNING!

230

MULTIMEDIA

Automatic SOS — If Equipped

Automatic SOS is a hands-free safety service that can

immediately connect you with help in the event that your

vehicle’s airbags deploy. After an accident, a live agent will

contact you through the Uconnect system and alert

emergency services.

NOTE:

An active SiriusXM Guardian™ subscription is required for

this feature to function.
After a crash where the airbags deploy:
1. Automatic SOS will initiate a call with an agent.
2. An agent will receive the call and confirm the location

of the emergency.

3. If needed, the agent will request the assistance of

emergency services.

4. First responders will arrive on scene. The agent will

remain on the call until emergency services arrive.

NOTE:



Agents are available 24/7 to assist you in the case of

an emergency.



On your behalf, agents are able to notify family

members about the collision.



Agents can brief first responders of the situation before

they arrive on scene.



In the event vehicle occupants are unable to speak,

emergency services will be dispatched based on the

last known GPS coordinates.



SiriusXM Guardian™ connected services are depen

dent upon an operative telematics device, a cellular

connection, navigation map data, and GPS satellite

reception, which can limit the ability to reach the

response center or reach emergency support.



Guardian™ subscriber agreement apply. See terms of

services for complete service limitation.

Remote Commands

On the Remote Commands screen, you have access to

several vehicle features that can be controlled remotely

from your mobile device. These features include locking/

unlocking, remote starting, and activating the horn and

lights of the vehicle.

Remote Commands lets you send a request to your

vehicle in one of three ways:



Anywhere using your mobile device and Vehicle

Branded App



From your computer on the Owner’s Site (not available

on all functions)



Contacting SiriusXM Guardian™ Customer Care (not

available on all functions)

Using A Remote Command Through Your Mobile Device

And The Vehicle Branded App
1. Press the desired Remote Command icon on your

mobile device.

2. A pop-up screen will appear asking for your SiriusXM

Guardian™ Security PIN (this is the same four-digit

code established when you activated your SiriusXM

Guardian™ connected services). Enter the SiriusXM

Guardian™ Security PIN on the keypad.

3. It may take 30 seconds or more for the command to

go through to your vehicle.

4. A message will let you know if the command was

received by your vehicle.



If anyone in the vehicle could be in danger (e.g., fire

or smoke is visible, dangerous road conditions or

location), do not wait for voice contact from a

SiriusXM Guardian™ Customer Care agent. All occu

pants should exit the vehicle immediately and move

to a safe location.



Failure to perform scheduled maintenance and

regular inspection of your vehicle may result in

vehicle damage, accident or injury.

WARNING!

Lock

Press this button to lock

your vehicle.

Vehicle Start

Press this button to start

your vehicle.

Horn & Lights

Press this button to sound

the horn and activate your

lights.

Unlock

Press this button to unlock

your vehicle.

Cancel Vehicle Start

Press this button to cancel

remote start.

MULTIMEDIA

231

Using A Remote Command Through Your Owner’s Site
1. Log on to your Owner’s Site using the username and

password you used when activating your SiriusXM

Guardian™ connected services in your vehicle.

NOTE:

If you forgot your username or password, links are

provided on the website to help you retrieve them.
2. If you have more than one vehicle registered into your

Owner’s Site, select the vehicle you want to send the

command to by clicking on its image along the top.

3. On your dashboard, you will see remote commands.

Press the desired icon to activate that feature.

4. You will then be asked to enter your SiriusXM

Guardian™ Security PIN (this is the same four-digit

code established when you activated your SiriusXM

Guardian™ connected services). Please enter your

SiriusXM Guardian™ Security PIN.

5. A message will appear on the screen to let you know

if the command was received by your vehicle.

Contacting SiriusXM Guardian™ Customer Care (for

example, in case of an accidental lock-out):
1. Contact SiriusXM Guardian™ Customer Care if you

are unable to lock your vehicle through the Vehicle

Branded App or your key fob.

2. For security purposes, the SiriusXM Guardian™

Customer Care agent will verify your identity by asking

for your four-digit SiriusXM Guardian™ Security PIN.

3. After providing your SiriusXM Guardian™ Security

PIN, you can ask them to perform a remote

command.

NOTE:

Anyone with access to your PIN may request Remote Door

Lock/Unlock. It is your responsibility to protect your PIN

appropriately.

Remote Door Lock/Unlock

Description
The Remote Door Lock/Unlock feature provides you the

ability to lock or unlock the door on your vehicle without

the keys and from virtually any distance.
Working Vehicle Conditions



The vehicle must in PARK or at a standstill.



The vehicle must be in an open area with cell tower

reception.



Your mobile device must have a cellular or Wi-Fi

connection.

Requirements



Vehicle must be properly equipped with SiriusXM

Guardian™.



Vehicle must have an operable LTE (voice/data) or 4G

(data) network connection. If using the Vehicle

Branded App to command your vehicle, your device

must be compatible and be connected to an operable

LTE (voice/data) or 4G (data) network connection.



Vehicle must be registered with SiriusXM Guardian™

and have an active subscription that includes the appli

cable feature.



An ignition cycle is required for some remote

commands, such as Remote Vehicle Start and Remote

Door Lock/Unlock if following a Remote Horn & Lights

activation.



Your Remote Door Lock/Unlock request will not be

processed if the vehicle is in motion, the ignition key is

on or during an emergency call.

NOTE:

All other remote services should be performed via your

Owner’s Site or through the Vehicle Branded App on your

compatible device.

Remote Vehicle Start

Description
The Remote Vehicle Start feature provides you with the

ability to start the engine on your vehicle without the keys

and from virtually any distance. Once started, the preset

climate controls in your vehicle can warm up or cool down

the interior.
You can also send a command to turn off an engine that

has been started using Remote Vehicle Start. After

15 minutes, if you have not entered your vehicle with the

key, the engine will shut off automatically.
This remote function requires your vehicle to be equipped

with a factory-installed Remote Start system.
You can set up push notifications every time a command

is sent to activate or cancel Remote Start.

232

MULTIMEDIA

Working Vehicle Conditions



The vehicle must be off or in ACC mode.



The vehicle has been started with the key fob within the

last 14 days.



The vehicle must be in PARK or at a standstill.



The vehicle’s security system has been armed and not

triggered since the last vehicle start.



The doors, hood, and trunk/liftgate are closed.



The vehicle’s check engine light must be off.



The vehicle must have at least a quarter tank of fuel,

along with oil and battery power.



The vehicle’s hazard lights must be off.



If equipped, the vehicle must have an automatic trans

mission.



The vehicle must be in an open area with cell tower

reception.



Your mobile device must have a cellular or Wi-Fi

connection.



If the Panic button has been pressed, the vehicle must

be started at least once after alarming the system.

NOTE:

The SiriusXM Guardian™ Customer Care agents are not

authorized for Remote Vehicle Start services. Contact the

Uconnect Care Team for assistance.

Remote Horn & Lights

Description
It is easy to locate a vehicle in a dark, crowded or noisy

parking area by activating the horn and lights. It may also

help if you need to draw attention to your vehicle for any

reason.

If you want, you can set up push notifications every time a

command is sent to turn on the horn and lights.
Working Vehicle Conditions



The vehicle must in PARK or at a standstill.



The vehicle must be in an open area with cell tower

reception.



Your mobile device must have a cellular or Wi-Fi

connection.

NOTE:

The Remote Horn & Lights feature is designed to be loud

and get noticed. Please keep in mind the surroundings

when using this feature. You are responsible for

compliance with local laws, rules and ordinances in the

location of your vehicle when using Remote Horn & Lights.

Assist — If Equipped

Description
Vehicles equipped with the SiriusXM Guardian™

connected services feature may contain an ASSIST button

in the vehicle. Once your SiriusXM Guardian™ connected

services have been activated, the ASSIST button can

connect you directly to the Customer Care call center (if

equipped). You will be directed to one of the following four

services:



Roadside Assistance — If you get a flat tire or need a

tow, you’ll be connected to someone who can help

anytime.



Connected Services — Contact the SiriusXM

Guardian™ Customer Care call center to activate your

services, renew after your trial has expired, for

in-vehicle support for your SiriusXM Guardian™

connected services, or help answering any general

questions surrounding your connected services.



Uconnect Care — In-vehicle support for all

non-connected Uconnect system features, such as

radio and Bluetooth® connections.



Vehicle Care — Total support for your vehicle.

SiriusXM Guardian™ In-Vehicle Assistance Features —

If Equipped
With SiriusXM Guardian™, your vehicle has onboard

assistance features located on the rearview mirror or

overhead console designed to enhance your driving

experience if you should ever need assistance or support.
How It Works
Simply push the ASSIST button in the vehicle and you will

be presented with your ASSIST options on the

touchscreen. Make your selection by pressing the

touchscreen.
Requirements



This feature is available only on vehicles sold in the US

and Canada.



Vehicle must be properly equipped with the SiriusXM

Guardian™ connected services.



Vehicle must have an operable LTE (voice/data) or 4G

(data) network connection.



Vehicle must be registered with SiriusXM Guardian™

and have an active subscription that includes the appli

cable feature.



Vehicle must be powered in the ON/RUN or ACC (Acces

sory) position with a properly functioning electrical

system.

Jeep Wrangler (2023 year). Manual in english - page 14
