Jeep Grand Cherokee (2023 year). Manual in english - page 25





396

TECHNICAL SPECIFICATIONS

VEHICLE IDENTIFICATION NUMBER (VIN)

The VIN is found on a label located on the left front

corner of the instrument panel pad, visible from

outside of the vehicle through the windshield.

Windshield VIN Label Location

NOTE:

It is illegal to remove or alter the VIN.

BRAKE SYSTEM

Your vehicle is equipped with dual hydraulic brake

systems. If either of the two hydraulic systems lose

normal capability, the remaining system will still

function. However, there will be some loss of

overall braking effectiveness. You may notice

increased pedal travel during application, greater

pedal force required to slow or stop, and potential

activation of the Brake Warning Light.
In the event power assist is lost for any reason the

brakes will still function. However, the effort

required to brake the vehicle will be much greater

than that required with the power system

operating.

WHEEL AND TIRE TORQUE SPECIFICATIONS

Proper lug nut/bolt torque is very important to

ensure that the wheel is properly mounted to the

vehicle. Any time a wheel has been removed and

reinstalled on the vehicle, the lug nuts/bolts

should be torqued using a properly calibrated

torque wrench using a six-sided (hex) deep wall

socket.

T

ORQUE

 S

PECIFICATIONS

**Use only authorized dealer recommended lug

nuts/bolts and clean or remove any dirt or oil

before tightening.
Inspect the wheel mounting surface prior to

mounting the tire and remove any corrosion or

loose particles.

Wheel Mounting Surface

Lug Nut/Bolt

Torque

**Lug Nut/

Bolt Size

Lug Nut/Bolt

Socket Size

130 ft-lb

(176 N·m)

M14 x 1.50

22 mm

TECHNICAL SPECIFICATIONS

397

Tighten the lug nuts/bolts in a star pattern until

each nut/bolt has been tightened twice. Ensure

that the socket is fully engaged on the lug nut/bolt

(do not insert it half way).

NOTE:

If in doubt about the correct tightness, have them

checked with a torque wrench by an authorized

dealer or service station.
After 25 miles (40 km), check the lug nut/bolt

torque to be sure that all the lug nuts/bolts are

properly tightened.

Torque Pattern

FUEL REQUIREMENTS

While operating on gasoline with the required

octane number, hearing a light knocking sound

from the engine is not a cause for concern.

However, if the engine is heard making a heavy

knocking sound, see a dealer immediately. Use of

gasoline with an octane number lower than

recommended can cause engine failure and may

void the New Vehicle Limited Warranty.
Poor quality gasoline can cause problems such as

hard starting, stalling, and hesitations. If you

experience these symptoms, try another brand of

gasoline before considering service for the vehicle.

2.0L E

NGINE

This engine is designed to meet all

emissions requirements, and provide

satisfactory fuel economy and

performance, when using high-quality

unleaded regular gasoline having an octane rating

of 87, as specified by the (R+M)/2 method. The

use of 91 or higher octane premium gasoline will

allow these engines to operate to optimal

performance. This increase in performance is most

noticeable in hot weather or under heavy load

conditions, such as while towing.

3.6L E

NGINE



Do not use E-85 flex fuel or ethanol blends greater

than 15% in this engine.

This engine is designed to meet all

emissions regulations and provide

optimum fuel economy and performance

when using high quality unleaded regular

gasoline having a posted octane number of 87 as

specified by the (R+M)/2 method. The use of

higher octane premium gasoline is not required, as

it will not provide any benefit over regular gasoline

in these engines.

5.7L E

NGINE

Do not use E-85 flex fuel or ethanol blends greater

than 15% in this engine.

This engine is designed to meet all

emission regulations and provide

satisfactory fuel economy and

performance when using high-quality

unleaded gasoline having an octane range of 87 to

89 as specified by the (R+M)/2 method. The use of

89 octane plus gasoline is recommended for

optimum performance and fuel economy.

WARNING!

To avoid the risk of forcing the vehicle off the

jack, do not tighten the lug nuts/bolts fully until

the vehicle has been lowered. Failure to follow

this warning may result in personal injury.

9

398

TECHNICAL SPECIFICATIONS



R

EFORMULATED

 G

ASOLINE



Many areas of the country require the use of

cleaner burning gasoline referred to as

“reformulated gasoline”. Reformulated gasoline

contains oxygenates and are specifically blended

to reduce vehicle emissions and improve air

quality.
The use of reformulated gasoline is recommended.

Properly blended reformulated gasoline will

provide improved performance and durability of

engine and fuel system components.

M

ATERIALS

 A

DDED

 T

O

 F

UEL



Besides using unleaded gasoline with the proper

octane rating, gasolines that contain detergents,

corrosion and stability additives are

recommended. Using gasolines that have these

additives will help improve fuel economy, reduce

emissions, and maintain vehicle performance.

Designated TOP TIER Detergent Gasoline

contains a higher level of detergents to

further aide in minimizing engine and

fuel system deposits. When available,

the usage of TOP TIER Detergent Gasoline is

recommended. Visit

www.toptiergas.com

 for a list

of TOP TIER Detergent Gasoline retailers.

Indiscriminate use of fuel system cleaning agents

should be avoided. Many of these materials

intended for gum and varnish removal may contain

active solvents or similar ingredients. These can

harm fuel system gasket and diaphragm materials.

G

ASOLINE

/O

XYGENATE

 B

LENDS



Some fuel suppliers blend unleaded gasoline with

oxygenates such as ethanol.

Problems that result from using gasoline

containing more than 15% ethanol (E-15) or

gasoline containing methanol are not the

responsibility of the manufacturer and may void or

not be covered under New Vehicle Limited

Warranty.

D

O

 N

OT

 U

SE

 E-85 I

N

 N

ON

-F

LEX

 F

UEL



V

EHICLES

Non-Flex Fuel Vehicles (FFV) are compatible with

gasoline containing up to 15% ethanol (E-15). Use

of gasoline with higher ethanol content may void

the New Vehicle Limited Warranty.
If a Non-FFV vehicle is inadvertently fueled with

E-85 fuel, the engine will have some or all of these

symptoms:

Operate in a lean mode.

OBD II Malfunction Indicator Light on.

Poor engine performance.

Poor cold start and cold drivability.

Increased risk for fuel system component corro

-

sion.

CNG A

ND

 LP F

UEL

 S

YSTEM



M

ODIFICATIONS

Modifications that allow the engine to run on

Compressed Natural Gas (CNG) or Liquid Propane

(LP) may result in damage to the engine,

emissions, and fuel system components. Problems

that result from running CNG or LP are not the

responsibility of the manufacturer and may void or

not be covered under the New Vehicle Limited

Warranty.

CAUTION!

DO NOT use E-85, gasoline containing methanol,

or gasoline containing more than 15% ethanol

(E-15). Use of these blends may result in starting

and drivability problems, damage critical fuel

system components, cause emissions to exceed

the applicable standard, and/or cause the

Malfunction Indicator Light to illuminate. Please

observe pump labels as they should clearly

communicate if a fuel contains greater than

15% ethanol (E-15).

TECHNICAL SPECIFICATIONS

399

(Continued)

M

ETHYLCYCLOPENTADIENYL



M

ANGANESE

 T

RICARBONYL

 (MMT) I

N



G

ASOLINE

MMT is a manganese-containing metallic additive

that is blended into some gasolines to increase

octane. Gasoline blended with MMT provides no

performance advantage beyond gasoline of the

same octane number without MMT. Gasoline

blended with MMT reduces spark plug life and

reduces emissions system performance in some

vehicles. The manufacturer recommends that

gasoline without MMT be used in your vehicle. The

MMT content of gasoline may not be indicated on

the gasoline pump; therefore, you should ask your

gasoline retailer whether the gasoline contains

MMT. MMT is prohibited in Federal and California

reformulated gasoline.

F

UEL

 S

YSTEM

 C

AUTIONS

NOTE:

Intentional tampering with the emissions control

system can result in civil penalties being assessed

against you.

CAUTION!

Follow these guidelines to maintain your

vehicle’s performance:

The use of leaded gasoline is prohibited by

Federal law. Using leaded gasoline can impair

engine performance and damage the emis

-

sions control system.

An out-of-tune engine or certain fuel or ignition

malfunctions can cause the catalytic

converter to overheat. If you notice a pungent

burning odor or some light smoke, your engine

may be out of tune or malfunctioning and may

require immediate service. Contact an autho

-

rized dealer for service assistance.

The use of fuel additives, which are now being

sold as octane enhancers, is not recom

-

mended. Most of these products contain high

concentrations of methanol. Fuel system

damage or vehicle performance problems

resulting from the use of such fuels or addi

-

tives is not the responsibility of the manufac

-

turer and may void or not be covered under

the New Vehicle Limited Warranty.

CAUTION!

9

400

TECHNICAL SPECIFICATIONS



FLUID CAPACITIES

US

Metric

Fuel (Approximate)
All Engines

23 gal

87 L

Engine Oil With Filter
2.0L Engine

5 qt

4.7 L

3.6L Engine

5 qt

4.7 L

5.7L Engine

7 qt

6.6 L

Cooling System *
2.0L Engine

10.4 qt

9.8 L

2.0L Engine Intercooler

4.4 qt

4.2 L

3.6L Engine – Without Trailer Tow Package

11 qt

10.4 L

3.6L Engine – With Trailer Tow Package

11.5 qt

10.9 L

5.7L Engine

15 qt

14.2 L

* Includes heater and coolant recovery bottle filled to MAX level.

TECHNICAL SPECIFICATIONS

401

ENGINE FLUIDS AND LUBRICANTS

Component

Fluid, Lubricant, or Genuine Part

Engine Coolant

We recommend using Mopar® Antifreeze/Coolant 10 year/150,000 mile

(240,000 km) Formula OAT (Organic Additive Technology) meeting the

requirements of the manufacturer Material Standard MS.90032.

Intercooler

We recommend using Mopar® Antifreeze/Coolant 10 year/150,000 mile

(240,000 km) Formula OAT (Organic Additive Technology) or equivalent

meeting the requirements of the manufacturer Material Standard MS.90032.

Engine Oil — 2.0L Engine

We recommend using Mopar® API SP/GF-6A Certified SAE 5W-30 Full

Synthetic Engine Oil which meets the requirements of the manufacturer

Material Standard MS-13340. Equivalent full synthetic SAE 5W-30 API SP

engine oil can be used but must have the API Donut trademark

Ú

page 339.

CAUTION!

Failure to use the recommended API SP/GF-6A or equivalent oil can cause

engine damage not covered by the vehicle warranty.

Engine Oil – 3.6L & 5.7L Engine

We recommend using Mopar® SAE 0W-20 Full Synthetic Engine Oil which

meets the requirements of the manufacturer Material Standard MS-6395.

Equivalent full synthetic SAE 0W-20 engine oil can be used but must have the

API Starburst trademark

Ú

page 339.

Fuel Selection — 2.0L Engine

87 Octane (R+M)/2 Method, 0-15% Ethanol.

Fuel Selection – 3.6L Engine

87 Octane (R+M)/2 Method, 0-15% Ethanol (Do not use E-85).

Fuel Selection – 5.7L Engine

89 Octane Recommended - 87 Octane Acceptable (R+M)/2 Method, 0-15%

Ethanol (Do not use E-85).

9

402

TECHNICAL SPECIFICATIONS



CHASSIS FLUIDS AND LUBRICANTS

Component

Fluid, Lubricant, or Genuine Part

Automatic Transmission

Use only Mopar® ZF 8 & 9 Speed ATF Automatic Transmission Fluid or

equivalent. Failure to use the correct fluid may affect the function or

performance of your transmission.

Transfer Case – 1-Speed or 2-Speed Transfer Case

We recommend using Mopar® ATF+4 Automatic Transmission Fluid.

Axle Differential (Front-Rear) - Without Electronic Limited Slip Differential

(ELSD)

We recommend using Mopar® GL-5 Synthetic Axle Lubricant, SAE 75W-85.

Axle Differential (Rear) - With Electronic Limited Slip Differential (ELSD)

We recommend using Mopar® GL-5 Synthetic Axle Lubricant, SAE 75W-85

with friction modifier additive.

Brake Master Cylinder

We recommend using Mopar® DOT 3 Brake Fluid, SAE J1703.

403

CUSTOMER ASSISTANCE

SUGGESTIONS FOR OBTAINING SERVICE

FOR YOUR VEHICLE

P

REPARE

 F

OR

 T

HE

 A

PPOINTMENT

All work to be performed may not be covered by the

warranty. Discuss additional charges with the

service manager. Keep a maintenance log of your

vehicle's service history. This can often provide a

clue to the current problem.

P

REPARE

 A L

IST

Make a written list of your vehicle's problems or the

specific work you want done. If you've had an

accident or work done that is not on your

maintenance log, let the service advisor know.

B

E

 R

EASONABLE

 W

ITH

 R

EQUESTS

If you list a number of items and you must have

your vehicle by the end of the day, discuss the

situation with the service advisor and list the items

in order of priority. At many authorized dealers, you

may obtain a rental vehicle (additional charges

may apply). If you need a rental, it is advisable to

make these arrangements when you call for an

appointment.

IF YOU NEED ASSISTANCE

FCA US LLC and its authorized dealers are vitally

interested in your satisfaction. We want you to be

happy with our products and services.
Warranty service must be done by an authorized

dealer. We strongly recommend that you take the

vehicle to an authorized dealer. They know your

vehicle the best, and are most concerned that you

get prompt and high quality service. FCA US LLC's

authorized dealers have the facilities,

factory-trained technicians, special tools, and the

latest information to ensure the vehicle is fixed

correctly and in a timely manner.

This is why you should always talk to an authorized

dealer’s service manager first. If for some reason

you are still not satisfied, talk to the general

manager or owner of the authorized dealer. They

want to know if you need assistance. If an

authorized dealer is unable to resolve the concern,

you may contact FCA US LLC's Customer

Assistance center.
Any communication to FCA US LLC's customer

center should include the following information:

Owner's name and address

Owner's telephone number (home, mobile, and

office)

Authorized dealer name

Vehicle Identification Number (VIN)

Vehicle delivery date and mileage

10

404

CUSTOMER ASSISTANCE



R

OADSIDE

 A

SSISTANCE

Available 24 hours, 7 days a week.
Call 1-800-521-2779 or visit

chrysler.rsahelp.com

(USA)

Call 1-800-363-4869 or visit

fca.roadsideaid.com



(Canada)
Who is Covered
You are covered by Roadside Assistance services if

you are a purchaser for use of the vehicle.

Roadside Assistance services last for five years or

60,000 miles on the odometer, whichever occurs

first, calculated from the start date of the Basic

Limited Warranty, as set forth in your Warranty
Information book.

1

1. Towing services provided through Cross Country Motor Club,
Inc. Medford, MA 02155, except in AK,CA, HI, OR, WI, and WY,
where services are provided by Cross Country Motor Club of
California, Inc., Thousand Oaks, CA 91360.

What to Do
If your vehicle requires jump start assistance, out

of gas/fuel delivery, tire service, lockout service or

towing as a result of a mechanical breakdown, dial

toll-free: USA: 1-800-521-2779/Canada:

1-800-363-4869. Provide your name, Vehicle

Identification Number (VIN) required for covered

services, license plate number, and your location,

including the telephone number from which you

are calling. Briefly describe the nature of the

problem and answer a few simple questions. You

will be given the name of the service provider and

an estimated time of arrival. If you feel you are in

an unsafe situation, please let us know. With your

consent, we will contact local police or safety

authorities.
If Unable to Contact Roadside Assistance
If you are unable to contact Roadside Assistance or

unable to provide a valid Vehicle Identification

Number (VIN), and you obtain towing services on

your own, you may submit your original receipts

from the licensed towing or service facility, for

services rendered within30 days of the

occurrence. Be sure to include your VIN, odometer

mileage at the time of service, and current mailing

address. We will process the claim based on

vehicle and service eligibility. If eligible, we will

reimburse you for the reasonable amount actually

paid, based on the usual and customary charges

for that service in the area where they were

provided. FCA US LLC’s determination relating to

reimbursement is final. Correspondence should be

mailed to:
FCA US LLC Customer Assistance
P.O. Box 9145
Medford, MA 02155
Attention Claims Department

FCA US LLC reserves the right to modify the terms

or discontinue the Roadside Assistance Program

at any time. The Roadside Assistance program is

subject to restrictions and conditions of use, which

are determined solely by FCA US LLC.
Flat Tire Service
If you are inconvenienced by a flat tire, we will

dispatch a service provider to use your vehicle’s

temporary spare tire (if equipped) as

recommended in your Owner’s Manual. This is not

a permanent flat tire repair.
Out of Gas/Fuel Delivery
Drivers cannot always count on a gas station being

nearby, especially when traveling away from home.

We will dispatch a service provider to deliver a

small amount of fuel (maximum two gallons) to get

you to a nearby station. This service is limited to

two occurrences in a 12-month period.
Battery Jump Assistance
No time is a good time for a depleted battery. With

Roadside Assistance, you do not have to worry

about being stranded. We will dispatch a service

provider to provide you with a battery jump

anytime, day or night.

CUSTOMER ASSISTANCE

405

Lockout Service
Whether the keys are locked in your vehicle or

frozen locks are keeping you from getting on your

way, help is just a phone call away. This service is

limited to providing access to the vehicle’s seating

area. It does not cover the cost of replacement

keys.
Towing Service
Our towing service gives you peace of mind and

confidence. If your vehicle becomes disabled as a

result of a mechanical breakdown, Roadside

Assistance will dispatch a towing service to

transport your vehicle to the closest authorized

Chrysler, Dodge, Jeep®, or Ram dealer. If you

choose to go to another dealer, you will be

responsible for the cost if the extra distance

exceeds 10 miles.

FCA US LLC C

USTOMER

 C

ENTER

P.O. Box 21–8004
Auburn Hills, MI 48321–8004
Phone: (877) 426-5337

FCA C

ANADA

 I

NC

. C

USTOMER

 C

ENTER

P.O. Box 1621
Windsor, Ontario N9A 4H6
Phone: (800) 465-2001 English/(800) 387-9983

French

M

EXICO

Av. Prolongacion Paseo de la Reforma, 1240
Sante Fe C.P. 05109
Mexico, D.F.
In Mexico City: (800) 505-1300
Outside Mexico City: +(52) 55 50817568

P

UERTO

 R

ICO

 A

ND

 US V

IRGIN

 I

SLANDS

FCA Caribbean LLC
P.O. Box 191857
San Juan 00919-1857
Phone: (877) 426-5337
Fax: (787) 782-3345

C

USTOMER

 A

SSISTANCE

 F

OR

 T

HE



H

EARING

 O

R

 S

PEECH

 I

MPAIRED



(TDD/TTY)

To assist customers who have hearing difficulties,

FCA US LLC has installed special Telecommu

-

nication Devices for the Deaf (TDD) equipment at

its customer center. Any hearing or speech

impaired customer, who has access to a TDD or a

conventional teletypewriter (TTY) in the United

States, can communicate with FCA US LLC by

dialing 1-800-380-2479.

Canadian residents with hearing difficulties that

require assistance can use the special needs relay

service offered by Bell Canada. For TTY

teletypewriter users, dial 711 and for Voice callers,

dial 1-800-855-0511 to connect with a Bell Relay

Service operator.

S

ERVICE

 C

ONTRACT



You may have purchased a service contract for a

vehicle to help protect you from the high cost of

unexpected repairs after FCA US LLC's New

Vehicle Limited Warranty expires. The Mopar®

Vehicle Protection plans are the ONLY vehicle

extended protection plans authorized, endorsed

and backed by FCA US LLC to provide additional

protection beyond your vehicle’s warranty. If you

purchased a Mopar® Vehicle Protection Plan, you

will receive Plan Provisions and an Owner

Identification Card in the mail within three weeks

of the vehicle delivery date. If you have any

questions about the service contract, call FCA US

LLC’s Service Contract National Customer Hotline

at 1-800-521-9922 (Canadian residents, call

(800) 465-2001 English / (800) 387-9983

French).
FCA US LLC is not responsible for any service

contract you may have purchased from another

manufacturer. If you require service after the FCA

US LLC New Vehicle Limited Warranty expires,

please refer to the contract documents, and

contact the person listed in those documents.

10

406

CUSTOMER ASSISTANCE



We appreciate that you have made a major

investment when you purchased the vehicle. An

authorized dealer has also made a major

investment in facilities, tools, and training to

ensure that you are absolutely delighted with the

ownership experience.

WARRANTY INFORMATION

See the Warranty Information for the terms and

provisions of FCA US LLC warranties applicable to

this vehicle and market. Refer to

www.mopar.com/om

 for further information.

See the Warranty Information for the terms and

provisions of FCA Canada Inc. warranties

applicable to this vehicle and market. Refer to

www.owners.mopar.ca/en/

 for further

information.
For French, refer t

www.owners.mopar.ca/fr

 for

further information.
Use this QR code to access your

digital experience.

MOPAR® PARTS

Mopar® original equipment parts & accessories

and factory filled fluids are available from an

authorized dealer. They are recommended for your

vehicle to keep it operating at its best and maintain

its original condition.

REPORTING SAFETY DEFECTS

I

N

 T

HE

 50 U

NITED

 S

TATES

 A

ND



W

ASHINGTON

, D.C.

If you believe that your vehicle has a

defect that could cause a crash or cause

injury or death, you should immediately

inform the National Highway Traffic

Safety Administration (NHTSA) in

addition to notifying FCA US LLC.
If NHTSA receives similar complaints, it

may open an investigation, and if it finds

that a safety defect exists in a group of

vehicles, it may order a recall and

remedy campaign. However, NHTSA

cannot become involved in individual

problems between you, an authorized

dealer or FCA US LLC.

WARNING!

Engine exhaust (internal combustion engines

only), some of its constituents, and certain

vehicle components contain, or emit, chemicals

known to the State of California to cause cancer

and birth defects, or other reproductive harm. In

addition, certain fluids contained in vehicles and

certain products of component wear contain, or

emit, chemicals known to the State of California

to cause cancer and birth defects, or other

reproductive harm.

CUSTOMER ASSISTANCE

407

To contact NHTSA, you may call the

Vehicle Safety Hotline toll free at

1-888-327-4236 (TTY:

1-800-424-9153); or go to http://

www.safercar.gov; or write to:

Administrator, NHTSA, 1200 New Jersey

Avenue, SE., West Building, Washington,

D.C. 20590. You can also obtain other

information about motor vehicle safety

from http://www.safercar.gov.

I

N

 C

ANADA

If you believe that your vehicle has a

safety defect, you should contact the

Customer Service Department

immediately. Canadian customers who

wish to report a safety defect to the

Canadian government should contact

Transport Canada, Motor Vehicle Defect

Investigations and Recalls at

1-800-333-0510 or go to

wwwapps.tc.gc.ca/Saf-Sec-Sur/7/

PCDB-BDPP.

PUBLICATION ORDER FORMS

To order the following manuals, you may use either

the website or the phone numbers listed below.
Service Manuals
These comprehensive Service Manuals provide a

complete working knowledge of the vehicle,

system, and/or components and is written in

straightforward language with illustrations,

diagrams, and charts.
Diagnostic Procedure Manuals
Diagnostic Procedure Manuals are filled with

diagrams, charts and detailed illustrations. These

manuals make it easy to find and fix problems on

computer-controlled vehicle systems and features.

They show exactly how to find and correct

problems, using step-by-step troubleshooting and

drivability procedures, proven diagnostic tests and

a complete list of all tools and equipment.

To order a hard copy of your Service or Diagnostic

Procedure manuals, visit:

www.techauthority.com

 (US and Canada).

Owner's Manuals
These Owner's Manuals have been prepared with

the assistance of service and engineering

specialists to acquaint you with specific FCA

vehicles.
To access your Owner's Information online, visit

www.mopar.com/om

 (US) or

www.owners.mopar.ca

 (Canada).

Or
Call Tech Authority toll free at:

1-800-890-4038 (US)

Owner's Manuals, Radio Manuals and Warranty

Information Books can be ordered through

Archway at:

1-800-387-1143 (Canada)

10

408

CUSTOMER ASSISTANCE



CHANGE OF OWNERSHIP OR ADDRESS

*If you have purchased this vehicle used or have

changed your address, please provide the

following information and mail to:
FCA US LLC
P.O. Box 21–8008
Auburn Hills, MI 48321–8004
Make sure to include the following:

Date of Sale (mm/dd/yy)

Vehicle Indentification Number (17 Character ID

located on top left of the instrument panel)

Exact Odometer Reading

First and Last Name

Phone Number

Street Address, City, State and Zip Code

Email Address

*Applies to US residents only.

GENERAL INFORMATION

The following regulatory statement applies to all

Radio Frequency (RF) devices equipped in this

vehicle:
This device complies with Part 15 of the FCC Rules

and with Innovation, Science and Economic

Development Canada license-exempt RSS

standard(s). Operation is subject to the following

two conditions:
1. This device may not cause harmful

interference, and

2. This device must accept any interference

received, including interference that may

cause undesired operation.

Le présent appareil est conforme aux CNR

d`Innovation, Science and Economic Development

applicables aux appareils radio exempts de

licence. L'exploitation est autorisée aux deux

conditions suivantes:
1. l'appareil ne doit pas produire de brouillage,

et

2. l'utilisateur de l'appareil doit accepter tout

brouillage radioélectrique subi, même si le

brouillage est susceptible d'en compromettre

le fonctionnement.

La operación de este equipo está sujeta a las

siguientes dos condiciones:
1. es posible que este equipo o dispositivo no

cause interferencia perjudicial y

2. este equipo o dispositivo debe aceptar

cualquier interferencia, incluyendo la que

pueda causar su operación no deseada.

NOTE:

Changes or modifications not expressly approved

by the party responsible for compliance could void

the user’s authority to operate the equipment.















Content      ..     23      24      25
