MULTIMEDIA

267



Curfew Alert
Receive a notification when your car is being

driven outside of the curfew time.



Speed Alert
Receive a notification whenever your car

exceeds a speed limit you set.



Valet Alert
Receive a notification if and when your vehicle is

driven outside a quarter-mile radius of a valet

drop-off zone.

SmartWatch Integration — If Equipped

Description
SmartWatch Integration puts the Mobile App right

on your Apple® Watch or Android™ Wear. To get

started, follow these steps:
1. Download the Mobile App from the App

Store® or Google Play.

2. Log onto the app from your smartphone using

the username and password you created when

you first set up your account.

3. Make sure your watch and smartphone are

connected through Bluetooth®.

4. The Mobile App should appear on your

SmartWatch.

Once the app is downloaded on your SmartWatch,

you can enjoy these features:



Lock or unlock your vehicle by tapping the

remote lock button in the app and entering your

security PIN.



Remote start or stop your vehicle.



View important vehicle stats, such as fuel level,

vehicle location, tire pressure warning, and

more.

For help, refer to the Uconnect YouTube channel

for SmartWatch Integration.

ANAGE

IRIUS

XM G

UARDIAN

™

CCOUNT

To manage your SiriusXM Guardian™ account,

press the ASSIST button in your vehicle, or call

SiriusXM Guardian™ Customer Care.

NOTE:

It is recommended, when selling your vehicle, or

turning in your lease, to call SiriusXM Guardian™

Care to remove your personal data.

CONNECTED SERVICES FAQS

For additional information about SiriusXM

Guardian™, active subscribers can push the

ASSIST button (if equipped) and then select

SiriusXM Guardian™ Call on your in-vehicle

touchscreen to contact SiriusXM Guardian™. Your

call will be directed to a SiriusXM Guardian™ agent

or held in a queue until an agent is available. If you

do not have an active subscription, push the

ASSIST button and press the Activate button on the

touchscreen to activate services.

ONNECTED

ERVICES

SOS FAQ

—

QUIPPED

1. What happens if I accidentally push the SOS

Call button on the mirror or overhead console?

You have 10 seconds after pushing the SOS

Call button to cancel the call. To cancel the

call, either push the SOS Call button again, or

press the Cancel button on the in-vehicle

touchscreen.

2. What type of information is sent when I use the

SOS Call button from my vehicle? Certain

vehicle information, such as make and model,

is transmitted along with the last known GPS

location.

3. When could I use the SOS Call button? You can

use the SOS Call button to make a call if you or

someone else needs emergency assistance.

ONNECTED

ERVICES

EMOTE

OOR

OCK

NLOCK

FAQ

1. How long does it take to unlock or lock the

door? Depending on various conditions, it can

take up to three minutes or more for the

request to get to your vehicle.

2. Which is faster, my key fob or the Mobile App?

Your key fob will lock/unlock the door more

268

MULTIMEDIA

quickly, however its range is limited and your

Mobile App comes in handy for these and

other situations.

3. Will my vehicle be safe if I lose my device?

People sometimes lose their mobile devices,

which is why security measures have been

engineered into the Mobile App. Asking for

your username, password and SiriusXM

Guardian™ Security PIN are required for the

activation of Remote services through your

mobile device. It is your responsibility to

protect your passwords and PINs.

4. Why can’t all mobile devices use the Mobile

App? The Mobile App is compatible with most

devices with the Apple® and Android™

operating systems. The capabilities of these

devices allow us to remotely command your

vehicle. Other operating systems may be

supported in the future.

5. Why is the Mobile App running slow? The

Mobile App relies on a mobile network

connection from your device to send

commands to your vehicle which must have an

operable LTE (voice/data) or 3G, 4G (data), or

5G (data) network connection. If either your

device or your vehicle is in an area with below

average coverage, it may take longer to log in

and send commands.

ONNECTED

ERVICES

OADSIDE

SSISTANCE

FAQ

1. What is the phone number for roadside

assistance call? The phone number is:



US: 1-800-521-2779



Canada: 1-800-363-4869

2. If I am subscribed to SiriusXM Guardian™,

does it cover towing or other expenses

incurred by using roadside assistance? No,

however your new vehicle may include

Roadside Assistance Call services.

ONNECTED

ERVICES

END

& G

FAQ

— I

QUIPPED

1. How long does it take to send the route and

destination to my vehicle? Depending on

various conditions, it can take up to three

minutes for the request to get through to your

vehicle.

2. Can I cancel a route I sent to my vehicle? Yes,

once you enter your vehicle, and start the

engine, the pop-up message stating that you

have a new route will appear. There is an exit

button on the pop-up that will cancel the route

if selected.

3. Can I select a different route than the most

recent one I sent to my vehicle? Yes, once you

enter the vehicle, and start the engine, the

pop-up message offers a “Locations” option.

Once “Locations” is selected, you can choose

from a list of recently sent destinations.

ONNECTED

ERVICES

EHICLE

INDER

FAQ

1. Can someone else locate my vehicle? Your

vehicle may be located by anyone who has

your PIN and access to your account. It is your

responsibility to guard your PIN accordingly.

See the Uconnect and SiriusXM Guardian™

2. How long does it take to sound my horn and

flash the lights? Depending on various

conditions, it can take three minutes or more

for the request to get through to your vehicle.

3. How do I turn off the horn and lights after I turn

them on? If you are close enough to the

vehicle, you can use the key fob to turn off the

horn and lights by pushing the red Panic

button.

MULTIMEDIA

269

ONNECTED

ERVICES

TOLEN

EHICLE

SSISTANCE

FAQ

— I

QUIPPED

1. Can someone locate my vehicle? To enhance

your privacy, and the privacy of others using

your vehicle, a stolen vehicle police report is

required for you to activate this service. You

must involve local law enforcement to have

SiriusXM Guardian™ locate your vehicle. We

may also locate the vehicle for other law

enforcement or government agencies,

subject to a valid court order telling SiriusXM

Guardian™ to do so. We will also provide the

service for FCA entities to locate a vehicle that

you have purchased through them.

2. How will I know if my vehicle is recovered?

After you provide the SiriusXM Guardian™

Customer Care agent with the stolen vehicle

report, the agent will work together with law

enforcement to try to locate your vehicle. If

your vehicle is recovered, you will be contacted

by law enforcement.

3. Can SiriusXM Guardian™ lower my insurance

rates? Some insurance providers offer lower

rates on vehicles equipped with systems that

can deter auto theft. When shopping for

insurance, be sure to inform the insurance

provider of your SiriusXM Guardian™ connected

services subscription to find out if the insurance

provider can offer you a lower rate.

NOTE:

Neither FCA nor SiriusXM® are insurance

companies, and SiriusXM Guardian™ is not an

insurance product. You are responsible for

obtaining insurance coverage for your vehicle and

yourself.

ONNECTED

ERVICES

EMOTE

EHICLE

TART

FAQ

1. How long does it take to remotely start my

vehicle? Depending on various conditions, it

can take three minutes or more for the

request to get through to your vehicle.

2. Which is faster, my key fob or the Mobile App?

Your key fob will remote start your vehicle

more quickly. However its range is limited. For

example, when you are leaving the stadium

after the game, you can use the Mobile App to

remote start your vehicle and have the inside

of your vehicle comfortable by the time you get

to it.

3. Will my vehicle be safe if I lose my wireless

device? People sometimes lose their wireless

devices, which is why security measures have

been engineered into the Mobile App. Asking

for your username, password and SiriusXM

Guardian™ Security PIN help to ensure that

nobody can start your vehicle if they happen to

find your device.

4. Can someone drive off with my vehicle using

the App? No. Driving your vehicle still requires

the keys to be in the vehicle. The Remote Start

feature simply starts the engine to warm up or

cool down the interior before you arrive.

5. Can I stop a vehicle that is being driven with

the cancel Remote Vehicle Start command?

No. If the vehicle is in motion, the cancel

Remote Vehicle Start button will not stop the

vehicle.

6. Why can’t all mobile devices use the Mobile

App? The Mobile App has been designed to

work on most devices with the Apple® and

Android™ operating systems. The capabilities

of these devices allow us to remotely

command your vehicle. Other operating

systems may be supported in the future.

ONNECTED

ERVICES

EMOTE

ORN

& L

IGHTS

FAQ

1. How long does it take to sound my horn and

flash the lights? Depending on various

conditions, it can take three minutes or more

for the request to get through to your vehicle.

2. Which is faster, my key fob or the Mobile App?

Your key fob will sound the horn and flash the

lights quicker; however, its range is limited.

3. How do I turn off the horn and lights after I turn

them on? If you are close enough to the

270

MULTIMEDIA

vehicle, you can use the key fob to turn off the

horn and lights by pressing the red Panic

button. Otherwise, Remote Horn & Lights will

continue for a maximum of three minutes.

4. Why can’t all mobile devices use the Mobile

App? The Mobile App has been designed to

work on most devices with the Apple® and

Android™ operating systems. The capabilities

of these devices allow us to remotely

command your vehicle. Other operating

systems may be supported in the future.

ONNECTED

ERVICES

CCOUNT

FAQ

—

QUIPPED

1. How do I register for my SiriusXM Guardian™

account? There are three ways that you can



Push the ASSIST button. A call will be placed

to an agent who can assist in registering

your new account.



Press the Activate Services icon in the Apps

menu. Select the button to speak with an

agent, who can assist in registering your

new account.



Press the Activate Services icon in the Apps

menu. Enter your email on the touchscreen

and then follow the prompts from the

provided email. You will receive an email

with an activation link that will be good for

72 hours. Once you click the activation link,

you will be prompted to fill out your informa

tion and accept Terms and Conditions.

Then, you will be directed to the SiriusXM

Guardian™ home page to complete your

profile and demo the remote services.

2. Why do I need an email address? Without an

email address, customers cannot register for

SiriusXM Guardian™. Customers need to

additional services and create a SiriusXM

Guardian™ Security PIN for remote command

requests.

3. How do I create a SiriusXM Guardian™ security

PIN? Set up your SiriusXM Guardian™ Security

PIN during the registration process. The

SiriusXM Guardian™ Security PIN will be

required to authenticate you when accessing

your account via SiriusXM Guardian™ Call or

performing any remote services, such as

Remote Door Lock/Unlock, Remote Horn &

Lights, or Remote Vehicle Start.

4. What if I forgot my SiriusXM Guardian™

security PIN? If you’ve already activated

services and forgot your SiriusXM Guardian™

Security PIN, you can reset the PIN by selecting

Edit Profile on your Owner’s Site.

5. How do I update my SiriusXM Guardian™

payment account address? Your SiriusXM

Guardian™ Payment Account address can be

updated online, or by calling SiriusXM

Guardian™ Customer Care from ASSIST in your

vehicle. To update online: login to your Owner’s

Site, and select Edit Profile > SiriusXM

Guardian™ Payment Account.

6. How do I update my SiriusXM Guardian™

profile? Your name, home address, phone

number, email address and SiriusXM

Guardian™ Security PIN can be updated online

on your Owner’s Site. Log in to your Owner’s

Site then select Edit Profile to edit your

personal information. Make your edits and

click Save.

7. Can I try features or packages before I buy

them? Your new vehicle purchase may have

come with an included trial period for certain

Apps and services.

8. Can I access every App and service while

driving? No, some applications and services

are not available while driving. For your own

safety, it is not possible to use some of the

touchscreen features while the vehicle is in

motion (e.g. key pad).

9. What happens when my subscription comes

up for renewal? If you have added a credit card

to your account information, your subscription

will be automatically renewed for a term length

in accordance with the service plan that you

have selected at the then current subscription

rate and on every renewal date thereafter,

MULTIMEDIA

271

unless you cancel your subscription by calling

SiriusXM Guardian™ Care. If you have not

added a credit card to your account, SiriusXM

Guardian™ will send you an email or letter in

advance of your expiration date to remind you

that your subscription is ending soon.

10. How do I manage my SiriusXM Guardian™

notification preferences? Contact SiriusXM

Guardian™ Customer Care, or go to your

Owner’s Site and then update your

preferences on the SiriusXM Guardian™

customer web portal.

11. How do I purchase a subscription? Contact

SiriusXM Guardian™ Customer Care by

pushing the ASSIST button on your rearview

mirror or overhead console.

12. How do I update my credit card information?

Profile, then select SiriusXM Guardian™

Payment Account.

13. How do I find out how much longer I have on

my subscription? Contact SiriusXM Guardian™

Customer Care.
You also can visit your Owner’s Site and

choose a subscription to view its expiration

date. When your subscription is about to ex

pire, you will receive an email or letter of notifi

cation.

14. Can I get a refund if I have not used the entire

subscription? Prorated refunds are provided

from the date of cancellation for annual plans

or longer. Please see the Uconnect and

SiriusXM Guardian™ Terms & Conditions for

refunds related to billing plans of other lengths

and other circumstances.

15. Can I cancel a subscription before it expires?

Yes. If you have an annual subscription, your

subscription will be canceled the day you

cancel. If you have a monthly subscription,

your subscription will be canceled on the last

day of the month in which you choose to

cancel.

16. What should I do if I want to sell my vehicle?

Before your vehicle is sold to a new owner,

you’ll want to remove your account

information. This process removes all personal

information, returns the Uconnect system to

its original factory settings, removes all

SiriusXM Guardian™ connected services and

account information. To remove your account

information from the Uconnect system,

contact SiriusXM Guardian™ Customer Care.

17. What if I forgot to remove my account

information before I returned my lease vehicle

or sold it? Contact SiriusXM Guardian™

Customer Care.

18. What will happen if an operable LTE (voice/

data), 4G (data), or 5G (data) network

connection compatible with my device is

temporarily unavailable? The SOS Call and

ASSIST buttons will NOT function if you are not

connected to an operable LTE (voice/data) or

3G, 4G (data), 5G (data) network. Services that

required your smartphone only direct calls to

Roadside Assistance Call may be functioning if

you have an operable network.

ATA

OLLECTION

& P

RIVACY

The Uconnect system collects and transmits data

which may include information about your vehicle,

your vehicle’s health and performance, your

vehicle’s location, your utilization of the features in

your vehicle, and other data. The collection, use

and sharing of this information is required to

provide the SiriusXM Guardian™ connected

services and is further described by the Uconnect

www.driveuconnect.com/connectedservices/

privacy.html (US Residents) or

www.driveuconnect.ca (Canadian Residents). This

information may be collected by SiriusXM®

Connected Vehicle Services Inc. and shared with

FCA US LLC for the purposes stated in the

Uconnect Privacy Policy. Vehicle health and

272

MULTIMEDIA

diagnostic information including location data may

be used by Uconnect to provide a Vehicle Health

Report to you.
Even if you cancel your SiriusXM Guardian™

subscription, this vehicle diagnostic health

information, including location data, may still be

transmitted from your vehicle and you may still

have a Vehicle Health Report sent to you.
Use of any of the connected services including

SiriusXM Guardian™ is deemed to be your consent

to the collection, use and disclosure of this

information in accordance with the Uconnect

be collected, used, or shared, you must cancel your

Uconnect services in their entirety by contacting us

as referenced in the Uconnect Privacy Policy.

RADIO OPERATION AND MOBILE PHONES

Under certain conditions, the mobile phone being

on in your vehicle can cause erratic or noisy

performance from your radio. This condition may

be lessened or eliminated by repositioning the

mobile phone within the vehicle. This condition is

not harmful to the radio. If your radio performance

does not satisfactorily improve from repositioning

the mobile phone, it is recommended that the

volume be turned down or off during mobile phone

operation when not using the Uconnect system.

EGULATORY

AFETY

NFORMATION

US/CANADA
Exposure to Radio Frequency Radiation
The radiated output power of the internal wireless

radio is far below the FCC and IC radio frequency

exposure limits. Nevertheless, the wireless radio

will be used in such a manner that the radio is 8 in

(20 cm) or further from the human body.
The internal wireless radio operates within

guidelines found in radio frequency safety

standards and recommendations, which reflect

the consensus of the scientific community.
The radio manufacturer believes the internal

wireless radio is safe for use by consumers. The

level of energy emitted is far less than the

electromagnetic energy emitted by wireless

devices such as mobile phones. However, the use

of wireless radios may be restricted in some

situations or environments, such as aboard

airplanes. If you are unsure of restrictions, you are

encouraged to ask for authorization before turning

on the wireless radio

page 431.

OFF-ROAD PAGES — IF EQUIPPED

If your vehicle is equipped with Off-Road Pages, it

will provide you vehicle status information while

operating on off-road conditions. It supplies

information relating to the status of the drivetrain,

transfer case, coolant/oil gauges, pitch and roll of

the vehicle and access to the trailcam system.
To access Off-Road Pages, press the Apps button

on the touchscreen, and then select “Off-Road

Pages”.

Main Menu

1 — Mobile Apps Button
2 — Off-Road Pages App

MULTIMEDIA

273

-R

OAD

AGES

TATUS

The Off-Road Pages Status Bar is located along the

bottom of Off-Road Pages and is present in each of

the three selectable page options. It provides

continually updating information for the following

items:



Current Transfer Case Status



Current Latitude/Longitude



Current Altitude of the vehicle



Status of Hill Descent/Selec-Speed Control and

Selected Speed in MPH (km/h)



Status of Off-Road+ Mode

Status Bar 2WD/4WD

RIVETRAIN

The Drivetrain page displays information

concerning the vehicle’s drivetrain.
The following information is displayed:



Steering angle in degrees



Status of Transfer Case



Status of the Rear Axles — If Equipped

Drivetrain Menu 2WD/4WD

1 — Transfer Case Status
2 — Current Latitude/Longitude
3 — Current Altitude
4 — Hill Descent Control

1 — Steering Angle
2 — Sway Bar
3 — Front Axle Locker Status
4 — Rear Axle Locker Status

274

MULTIMEDIA

CCESSORY

AUGE

The Accessory Gauge page displays the current

status of the vehicle’s Coolant Temperature, Oil

Temperature, Oil Pressure (Gas Vehicles Only),

Transmission Temperature, and Battery Voltage.

Accessory Gauges Menu 2WD/4WD

ITCH

& R

OLL

The Pitch & Roll page displays the vehicle’s current

pitch (angle up and down) and roll (angle side to

side) in degrees. The Pitch & Roll gauges provide a

visualization of the current vehicle angle.

Pitch & Roll Menu 2WD/4WD

RAIL

— I

QUIPPED

Your vehicle may be equipped with a TrailCam that

allows you to see an on-screen image of the front

view of your vehicle. The image will be displayed on

the touchscreen along with a caution note “Check

Entire Surroundings” across the top of the screen.
To activate, press the TrailCam button on the

touchscreen.

TrailCam Activation

1 — Coolant Temperature
2 — Oil Temperature
3 — Oil Pressure (Gas Vehicles Only)
4 — Transmission Temperature

(Automatic Transmissions Only)
5 — Battery Voltage

1 — Current Pitch
2 — Current Roll

275

(Continued)

SAFETY

SAFETY FEATURES

NTI

-L

OCK

RAKE

YSTEM

(ABS)

The ABS provides increased vehicle stability and

brake performance under most braking conditions.

The system automatically prevents wheel lock and

enhances vehicle control during braking.
The ABS performs a self-check cycle to ensure that

the ABS is working properly each time the vehicle

is started and driven. During this self-check, you

may hear a slight clicking sound as well as some

related motor noises.
The ABS is activated during braking when the

system detects one or more wheels are beginning

to lock. Road conditions such as ice, snow, gravel,

bumps, railroad tracks, loose debris, or panic stops

may increase the likelihood of ABS activation(s).
You also may experience the following normal

characteristics when the ABS activates:



ABS motor noise or clicking sounds (you may

continue to hear for a short time after the stop)



Brake pedal pulsations



A slight drop of the brake pedal at the end of the

stop

The ABS is designed to function with the Original

Equipment Manufacturer (OEM) tires. Modification

may result in degraded ABS performance.

Anti-Lock Brake System (ABS) Warning

Light

The yellow ABS Warning Light will turn on when the

ignition is placed in the ON/RUN mode and may

stay on for as long as four seconds.
If the ABS Warning Light remains on or comes on

while driving, it indicates that the anti-lock portion

of the brake system is not functioning and that

service is required. However, the conventional

brake system will continue to operate normally if

the ABS Warning Light is on.

WARNING!



The ABS contains sophisticated electronic

equipment that may be susceptible to interfer

ence caused by improperly installed or high

output radio transmitting equipment. This

interference can cause possible loss of

anti-lock braking capability. Installation of

such equipment should be performed by qual

ified professionals.



Pumping of the Anti-Lock Brakes will diminish

their effectiveness and may lead to a collision.

Pumping makes the stopping distance longer.

Just press firmly on your brake pedal when you

need to slow down or stop.



The ABS cannot prevent the natural laws of

physics from acting on the vehicle, nor can it

increase braking or steering efficiency beyond

that afforded by the condition of the vehicle

brakes and tires or the traction afforded.



The ABS cannot prevent collisions, including

those resulting from excessive speed in turns,

following another vehicle too closely, or hydro

planing.



The capabilities of an ABS equipped vehicle

must never be exploited in a reckless or

dangerous manner that could jeopardize the

user’s safety or the safety of others.

WARNING!

276

SAFETY

If the ABS Warning Light is on, the brake system

should be serviced as soon as possible to restore

the benefits of Anti-Lock Brakes. If the ABS

Warning Light does not come on when the ignition

is placed in the ON/RUN mode, have the light

repaired as soon as possible.

LECTRONIC

RAKE

ONTROL

(EBC)

YSTEM

If applicable, refer to the “Hybrid Supplement” for

additional information.
Your vehicle is equipped with an advanced

Electronic Brake Control (EBC) system. This system

includes Anti-Lock Brake System (ABS), Brake

Assist System (BAS), Electronic Brake Force

Distribution (EBD), Electronic Roll Mitigation

(ERM), Electronic Stability Control (ESC), Hill Start

Assist (HSA), and Traction Control System (TCS).

These systems work together to enhance both

vehicle stability and control in various driving

conditions.
Your vehicle may also be equipped with Hill

Descent Control (HDC), Rain Brake Support (RBS),

Ready Alert Braking (RAB), and Trailer Sway

Control (TSC).

Brake System Warning Light

The red Brake System Warning Light will turn on

when the ignition is placed in the ON/RUN mode

and may stay on for as long as four seconds.
If the Brake System Warning Light remains on or

comes on while driving, it indicates that the brake

system is not functioning properly and that

immediate service is required. If the Brake System

Warning Light does not come on when the ignition

is placed in the ON/RUN mode, have the light

repaired as soon as possible.

Brake Assist System (BAS)

The BAS is designed to optimize the vehicle’s

braking capability during emergency braking

maneuvers. The system detects an emergency

braking situation by sensing the rate and amount

of brake application and then applies optimum

pressure to the brakes. This can help reduce

braking distances. The BAS complements the

Anti-Lock Brake System (ABS). Applying the brakes

very quickly results in the best BAS assistance. To

receive the benefit of the system, you must apply

continuous braking pressure during the stopping

sequence (do not “pump” the brakes). Do not

reduce brake pedal pressure unless braking is no

longer desired. Once the brake pedal is released,

the BAS is deactivated.

Electronic Brake Force Distribution (EBD)

EBD manages the distribution of the braking

torque between the front and rear axles by limiting

braking pressure to the rear axle. This is done to

prevent overslip of the rear wheels to avoid vehicle

instability, and to prevent the rear axle from

entering ABS before the front axle.

Electronic Roll Mitigation (ERM)

ERM anticipates the potential for wheel lift by

monitoring the driver’s steering wheel input and

the speed of the vehicle. When ERM determines

that the rate of change of the steering wheel angle

and vehicle’s speed are sufficient to potentially

cause wheel lift, it then applies the appropriate

brake and may also reduce engine power to lessen

WARNING!

The Brake Assist System (BAS) cannot prevent

the natural laws of physics from acting on the

vehicle, nor can it increase the traction afforded

by prevailing road conditions. BAS cannot

prevent collisions, including those resulting from

excessive speed in turns, driving on very slippery

surfaces, or hydroplaning. The capabilities of a

BAS-equipped vehicle must never be exploited in

a reckless or dangerous manner, which could

jeopardize the user's safety or the safety of

others.

SAFETY

277

the chance that wheel lift will occur. ERM can only

reduce the chance of wheel lift occurring during

severe or evasive driving maneuvers; it cannot

prevent wheel lift due to other factors, such as

road conditions, leaving the roadway, or striking

objects or other vehicles.

NOTE:

ERM is disabled any time the ESC is in “Full Off”

mode (if equipped)

page 277.

Electronic Stability Control (ESC)

ESC enhances directional control and stability of

the vehicle under various driving conditions. ESC

corrects for oversteering or understeering of the

vehicle by applying the brake of the appropriate

wheel(s) to counteract the above conditions.

Engine power may also be reduced to help the

vehicle maintain the desired path.



Oversteer — when the vehicle is turning more

than appropriate for the steering wheel position.



Understeer — when the vehicle is turning less

than appropriate for the steering wheel position.

ESC uses sensors in the vehicle to determine the

vehicle path intended by the driver and compares

it to the actual path of the vehicle. When the actual

path does not match the intended path, ESC

applies the brake of the appropriate wheel to

assist in counteracting the oversteer or understeer

condition.
The ESC Activation/Malfunction Indicator Light

located in the instrument cluster will start to flash

as soon as the ESC system becomes active. The

ESC Activation/Malfunction Indicator Light also

flashes when the TCS is active. If the ESC

Activation/Malfunction Indicator Light begins to

flash during acceleration, ease up on the

accelerator and apply as little throttle as possible.

Be sure to adapt your speed and driving to the

prevailing road conditions.

WARNING!

Many factors, such as vehicle loading, road

conditions and driving conditions, influence the

chance that wheel lift or rollover may occur. ERM

cannot prevent all wheel lift or rollovers,

especially those that involve leaving the roadway

or striking objects or other vehicles. The

capabilities of an ERM-equipped vehicle must

never be exploited in a reckless or dangerous

manner which could jeopardize the user's safety

or the safety of others.

WARNING!



Electronic Stability Control (ESC) cannot

prevent the natural laws of physics from acting

on the vehicle, nor can it increase the traction

afforded by prevailing road conditions. ESC

cannot prevent accidents, including those

resulting from excessive speed in turns, driving

on very slippery surfaces, or hydroplaning. ESC

also cannot prevent accidents resulting from

loss of vehicle control due to inappropriate

driver input for the conditions. Only a safe,

attentive, and skillful driver can prevent acci

dents. The capabilities of an ESC equipped

vehicle must never be exploited in a reckless or

dangerous manner which could jeopardize the

user’s safety or the safety of others.



Vehicle modifications, or failure to properly

maintain your vehicle, may change the handling

characteristics of your vehicle, and may nega

tively affect the performance of the ESC system.

Changes to the steering system, suspension,

braking system, tire type and size or wheel size

may adversely affect ESC performance. Improp

erly inflated and unevenly worn tires may also

degrade ESC performance. Any vehicle modifi

cation or poor vehicle maintenance that

reduces the effectiveness of the ESC system

can increase the risk of loss of vehicle control,

vehicle rollover, personal injury and death.

278

SAFETY

ESC Operating Modes

Depending upon model and mode of operation, the

ESC system may have multiple operating modes.
ESC On
“ESC On” is the normal operating mode for the

ESC. Whenever the vehicle is started, the ESC

system will be in this mode. This mode should be

used for most driving conditions. Alternate ESC

modes should only be used for specific reasons as

noted in the following paragraphs.
Partial Off
This mode may be useful if the vehicle becomes

stuck. This mode may modify TCS and ESC

thresholds for activation, which allows for more

wheel spin than normally allowed.
To enter the “Partial Off” mode, momentarily push

the ESC OFF button and the ESC OFF Indicator

Light will illuminate. To turn the ESC on again,

momentarily push the ESC OFF button and the ESC

OFF Indicator Light will turn off.

NOTE:

For vehicles with multiple partial ESC modes, the

push and release of the button will toggle the ESC

modes. Multiple attempts may be required to

return to “ESC On”.

Full Off — If Equipped
The “Full Off” mode is intended for off-highway or

off-road use only and should not be used on any

public roadways. In this mode, TCS and ESC

features are turned off. To enter the “Full Off”

mode, push and hold the ESC OFF button for five

seconds while the vehicle is stopped with the

engine running. After five seconds, a chime will

sound, the ESC OFF Indicator Light will illuminate,

and the “ESC Off” message will display in the

instrument cluster. To turn ESC on again,

momentarily push the ESC OFF button.

NOTE:

System may switch from ESC “Full Off” to “Partial

Off” mode when vehicle exceeds a predetermined

speed. When the vehicle speed slows below the

predetermined speed the system will return to ESC

“Full Off”.
If equipped with Off Road+ and if Off Road+ is

active when "Full Off" mode is enabled by the

driver, ESC will not switch to "Partial Off" mode at

any speed and will remain in "Full Off" mode until

Off Road+ is exited or ESC is re-enabled by the

driver.

WARNING!



When in “Partial Off” mode, the TCS function

ality of ESC, except for the limited slip feature

described in the TCS section, has been

disabled and the ESC OFF Indicator Light will

be illuminated. When in “Partial Off” mode,

the engine power reduction feature of TCS is

disabled, and the enhanced vehicle stability

offered by the ESC system is reduced.



Trailer Sway Control (TSC) is disabled when

the ESC system is in the “Partial Off” mode.

WARNING!



In the ESC “Full Off” mode, the engine torque

reduction and stability features are disabled.

Therefore, enhanced vehicle stability offered

by the ESC system is unavailable. In an emer

gency evasive maneuver, the ESC system will

not engage to assist in maintaining stability.

ESC “Full Off” mode is intended for

off-highway or off-road use only.



The Electronic Stability Control (ESC) cannot

prevent the natural laws of physics from

acting on the vehicle, nor can it increase the

traction afforded by prevailing road condi

tions. ESC cannot prevent all accidents,

including those resulting from excessive

speed in turns, driving on very slippery

surfaces, or hydroplaning. ESC also cannot

prevent collisions.

SAFETY

279

ESC Activation/Malfunction Indicator Light

And ESC OFF Indicator Light

The ESC Activation/Malfunction Indicator

Light in the instrument cluster will come

on when the ignition is turned to the “ESC

On” mode. It should go out with the

engine running. If the ESC Activation/Malfunction

Indicator Light comes on continuously with the

engine running, a malfunction has been detected

in the ESC system. If this light remains on after

several ignition cycles, and the vehicle has been

driven several miles (km) at speeds greater than

30 mph (48 km/h), see an authorized dealer as

soon as possible to have the problem diagnosed

and corrected.
The ESC Activation/Malfunction Indicator Light

starts to flash as soon as the tires lose traction and

the ESC system becomes active. The ESC

Activation/Malfunction Indicator Light also flashes

when TCS is active. If the ESC Activation/

Malfunction Indicator Light begins to flash during

acceleration, ease up on the accelerator and apply

as little throttle as possible. Be sure to adapt your

speed and driving to the prevailing road conditions.

The ESC OFF Indicator Light indicates the

customer has elected to have the

Electronic Stability Control (ESC) in a

reduced mode.

NOTE:



The ESC Activation/Malfunction Indicator Light

and the ESC OFF Indicator Light come on

momentarily each time the ignition is placed in

the ON position.



Each time the ignition is place in the ON posi

tion, the ESC system will be on even if it was

turned off previously.



The ESC system will make buzzing or clicking

sounds when it is active. This is normal; the

sounds will stop when ESC becomes inactive

following the maneuver that caused the ESC

activation.

Hill Descent Control (HDC) — If Equipped

HDC is intended for low speed off-road driving

while in 4WD Low. HDC maintains vehicle speed

while descending hills during various driving

situations. HDC controls vehicle speed by actively

controlling the brakes.
HDC has three states:
1. Off (feature is not enabled and will not

activate).

2. Enabled (feature is enabled and ready but

activation conditions are not met, or driver is

actively overriding with brake or throttle

application).

3. Active (feature is enabled and actively

controlling vehicle speed).

Enabling HDC
HDC is enabled by pushing the HDC switch, but the

following conditions must also be met to enable

HDC:



The driveline is in 4WD Low.



The vehicle speed is below 5 mph (8 km/h).



The parking brake is released.



The driver door is closed. (If doors are attached,

then door must be closed. If doors are

detached, then driver seat belt must be

buckled.)

Activating HDC
Once HDC is enabled it will activate automatically

if driven down a grade of sufficient magnitude. The

set speed for HDC is selectable by the driver, and

can be adjusted by using the gear shift +/-. The

following summarizes the HDC set speeds:
HDC Target Set Speeds



P = No set speed. HDC may be enabled but will

not activate



R = 0.6 mph (1 km/h)



N = 1.2 mph (2 km/h)



D = 0.6 mph (1 km/h)



1st = 0.6 mph (1 km/h)



2nd = 1.2 mph (2 km/h)



3rd = 1.8 mph (3 km/h)

280

SAFETY



4th = 2.5 mph (4 km/h)



5th = 3.1 mph (5 km/h)



6th = 3.7 mph (6 km/h)



7th = 4.3 mph (7 km/h)



8th = 5.0 mph (8 km/h)



9th = 5.6 mph (9 km/h) – If Equipped

NOTE:

During HDC the +/- shifter input is used for HDC

target speed selection, but will not affect the gear

chosen by the transmission. When actively

controlling HDC the transmission will shift appro

priately for the driver-selected set speed and corre

sponding driving conditions.
Driver Override
The driver may override HDC activation with

throttle or brake application at any time.
Deactivating HDC
HDC will be deactivated but remain available if any

of the following conditions occur:



Driver overrides HDC set speed with throttle or

brake application.



Vehicle speed exceeds 20 mph (32 km/h) but

remains below 40 mph (64 km/h).



Vehicle is on a downhill grade of insufficient

magnitude, is on level ground, or is on an uphill

grade.



Vehicle is shifted to PARK.

Disabling HDC
HDC will be deactivated and disabled if any of the

following conditions occur:



The driver pushes the HDC switch.



The driveline is shifted out of 4WD Low.



The parking brake is applied.



The driver door opens. (Driver door opens if

doors are attached or driver seat belt is

unbuckled if doors are detached.)



The vehicle is driven greater than 20 mph

(32 km/h) for greater than 70 seconds.



The vehicle is driven greater than 40 mph

(64 km/h) (HDC exits immediately).



HDC detects excessive brake temperature.

Feedback To The Driver
The instrument cluster has an HDC icon and the

HDC switch has an indicator light, which offers

feedback to the driver about the state HDC is in.



The cluster icon and switch indicator light will

illuminate and remain on solid when HDC is

enabled or activated. This is the normal oper

ating condition for HDC.



The cluster icon and switch indicator light will

flash for several seconds then extinguish when

the driver pushes the HDC switch but enable

conditions are not met.



The cluster icon and switch indicator light will

flash for several seconds then extinguish when

HDC disables due to excess speed.



The cluster icon and switch indicator light will

flash when HDC deactivates due to overheated

brakes. The flashing will stop and HDC will acti

vate again once the brakes have cooled suffi

ciently.

Hill Start Assist (HSA)

The HSA system is designed to mitigate roll back

from a complete stop while on an incline. If the

driver releases the brake while stopped on an

incline, HSA will continue to hold the brake

pressure for a short period. If the driver does not

apply the throttle before this time expires, the

system will release brake pressure and the vehicle

will roll down the hill as normal.

WARNING!

HDC is only intended to assist the driver in

controlling vehicle speed when descending hills.

The driver must remain attentive to the driving

conditions and is responsible for maintaining a

safe vehicle speed.

SAFETY

281

The following conditions must be met in order for

HSA to activate:



The feature must be enabled.



The vehicle must be stopped.



The parking brake must be off.



The driver door must be closed. (If the doors are

attached, then the door must be closed. If the

doors are detached then the driver's seat belt

must be buckled.)



The vehicle must be on a sufficient grade.



The gear selection must match vehicle uphill

direction (i.e., vehicle facing uphill is in forward

gear; vehicle backing uphill is in REVERSE gear).



HSA will work in REVERSE gear and all forward

gears. The system will not activate if the trans

mission is in PARK or NEUTRAL. For vehicles

equipped with a manual transmission, if the

clutch is pressed, HSA will remain active.

Disabling And Enabling HSA

This feature can be turned on or turned off. To

change the current setting, refer to

page 207 for

further information.

Towing With HSA

HSA will also provide assistance to mitigate roll

back while towing a trailer.

Rain Brake Support (RBS)

RBS may improve braking performance in wet

conditions. It will periodically apply a small amount

of brake pressure to remove any water buildup on

the front brake rotors. It functions when the

windshield wipers are in LO or HI speed. When RBS

is active, there is no notification to the driver and

no driver interaction is required.

WARNING!

There may be situations where the Hill Start

Assist (HSA) will not activate and slight rolling

may occur, such as on minor hills or with a

loaded vehicle, or while pulling a trailer. HSA is

not a substitute for active driving involvement. It

is always the driver’s responsibility to be

attentive to distance to other vehicles, people,

and objects, and most importantly brake

operation to ensure safe operation of the vehicle

under all road conditions. Your complete

attention is always required while driving to

maintain safe control of your vehicle. Failure to

follow these warnings can result in a collision or

serious personal injury.

WARNING!



If you use a trailer brake controller with your

trailer, the trailer brakes may be activated and

deactivated with the brake switch. If so, there

may not be enough brake pressure to hold

both the vehicle and the trailer on a hill when

the brake pedal is released. In order to avoid

rolling down an incline while resuming accel

eration, manually activate the trailer brake or

apply more vehicle brake pressure prior to

releasing the brake pedal.



HSA is not a parking brake. Always apply the

parking brake fully when exiting your vehicle.

Also, be certain to place the transmission in

PARK (P).



Failure to follow these warnings can result in a

collision or serious personal injury.

282

SAFETY

Ready Alert Braking (RAB)

RAB may reduce the time required to reach full

braking during emergency braking situations. It

anticipates when an emergency braking situation

may occur by monitoring how fast the throttle is

released by the driver. The Electronic Brake

Controller (EBC) will prepare the brake system for

a panic stop.

Rear Seat Reminder Alert (RSRA) —

If Equipped

RSRA will consider the presence of an object in the

rear seat when a rear entry/exit door is opened at

the beginning of each key cycle. To activate, the

rear door must be open for more than one second

and the vehicle must be placed in the RUN position

within 10 minutes. When the potential presence of

an object is determined and/or otherwise inferred,

a message will appear in the cluster display

reminding driver to check the rear seat(s)

immediately after key off, accompanied by an alert

upon exiting the vehicle.

Selec-Speed Control (SSC) — If Equipped

SSC is intended for off-road driving in

4WD Low only. SSC maintains vehicle

speed by actively controlling engine

torque and brakes.

SSC has three states:
1. Off (feature is not enabled and will not

activate)

2. Enabled (feature is enabled and ready but

activation conditions are not met, or driver is

actively overriding with brake or throttle

application)

3. Active (feature is enabled and actively

controlling vehicle speed)

Enabling SSC
SSC is enabled by pushing the SSC switch, but the

following conditions must also be met to enable

SSC:



The driveline is in 4WD Low.



The vehicle speed is below 5 mph (8 km/h).



The parking brake is released.



The driver door is closed (If doors are attached,

the door must be closed. If doors are detached,

the driver seat belt must be buckled).



The driver is not applying throttle.

Activating SSC
Once SSC is enabled it will activate automatically

once the following conditions are met:



The driver releases the throttle.



The driver releases the brake.



The driver seat belt is buckled.



The transmission is in any selection other than

PARK.



Your vehicle speed is below 20 mph (32 km/h).



The driver door is closed. (If doors are attached,

the door must be closed. If doors are detached,

the driver seat belt must be buckled).

The set speed for SSC is selectable by the driver,

and can be adjusted by using the gear shift +/-.

Additionally, the SSC set speed may be reduced

when climbing a grade and the level of set speed

reduction depends on the magnitude of grade. The

following summarizes the SSC set speeds:
SSC Target Set Speeds



1st = 0.6 mph (1 km/h)



2nd = 1.2 mph (2 km/h)



3rd = 1.8 mph (3 km/h)



4th = 2.5 mph (4 km/h)



5th = 3.1 mph (5 km/h)



6th = 3.7 mph (6 km/h)



7th = 4.3 mph (7 km/h)



8th = 5 mph (8 km/h)



9th = 5.6 mph (9 km/h) — if equipped



REVERSE = 0.6 mph (1 km/h)



NEUTRAL = 1.2 mph (2 km/h)



PARK = SSC remains enabled but not active

Jeep Wrangler (2022 year). Manual in english - page 17
