Request For Additional Key Fobs

NOTE:

Only key fobs that are programmed to the vehicle

electronics can be used to start and operate the vehicle.

Once a key fob is programmed to a vehicle, it cannot be

programmed to any other vehicle.

WARNING!

• Always remove the key fobs from the vehicle and

lock all doors when leaving the vehicle unattended.

• Always remember to place the ignition in the OFF

mode.

Duplication of key fobs may be performed at an authorized

dealer. This procedure consists of programming a blank

key fob to the vehicle electronics. A blank key fob is one

that has never been programmed.

NOTE:
• When having the Sentry Key Immobilizer System ser-

viced, bring all vehicle keys with you to an authorized

dealer.

• Keys must be ordered to the correct key cut to match the

vehicle locks.

General Information

The following regulatory statement applies to all radio

frequency (RF) devices equipped in this vehicle:
This device complies with Part 15 of the FCC Rules and

with Industry Canada license-exempt RSS standard(s).

Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, in-

cluding interference that may cause undesired opera-

tion.

NOTE:

Changes or modifications not expressly approved

by the party responsible for compliance could void the

user’s authority to operate the equipment.

IGNITION SWITCH

Keyless Enter-N-Go — Ignition

This feature allows the driver to operate the ignition switch

with the push of a button as long as the key fob is in the

passenger compartment.
The Keyless Push Button Ignition has several operating

modes that are labeled and will illuminate when in posi-

tion. These modes are OFF, ACC, RUN, and START.

GETTING TO KNOW YOUR VEHICLE

NOTE:

In case the ignition switch does not change with the

push of a button, the key fob may have a low or dead

battery. In this situation, a back up method can be used to

operate the ignition switch. Put the nose side of the key fob

(side opposite of the Emergency Key) against the ENGINE

START/STOP button and push to operate the ignition

switch.

The push button ignition can be placed in the following

modes:

OFF
• The engine is stopped.
• Some electrical devices (e.g. Central locking, alarm, etc.)

are still available.

ACC
• Engine is not started.
• Some electrical devices are available.
RUN
• Driving position.
• All the electrical devices are available.
START
• The engine will start.

WARNING!

• When exiting the vehicle, always remove the key fob

from the vehicle and lock your vehicle.

• Never leave children alone in a vehicle, or with

access to an unlocked vehicle.

(Continued)

START/STOP Ignition Button

GETTING TO KNOW YOUR VEHICLE

WARNING! (Continued)

• Allowing children to be in a vehicle unattended is

dangerous for a number of reasons. A child or others
could be seriously or fatally injured. Children
should be warned not to touch the parking brake,
brake pedal or the gear selector.

• Do not leave the key fob in or near the vehicle, or in

a location accessible to children, and do not leave the
ignition of a vehicle equipped with Keyless Enter-
N-Go in the ON/RUN mode. A child could operate
power windows, other controls, or move the vehicle.

• Do not leave children or animals inside parked

vehicles in hot weather. Interior heat build-up may
cause serious injury or death.

CAUTION!

An unlocked vehicle is an invitation for thieves. Al-
ways remove key fob from the vehicle and lock all
doors when leaving the vehicle unattended.

NOTE:

Refer to

⬙Starting The Engine,⬙ in ⬙Starting And

Operating

⬙ for further information.

Vehicle On Message

When opening the driver’s door when the ignition is in

RUN (engine not running), a chime will sound to remind

you to place the ignition in the OFF position. In addition to

the chime, the message will display “Ignition Or Accessory

On” in the cluster.

NOTE:

The power window switches will remain active up

to ten minutes after the ignition is cycled to the OFF

position. Opening either front door will cancel this feature.

The time for this feature is programmable.

WARNING!

• Before exiting a vehicle, always come to a complete

stop, then shift the automatic transmission into
PARK, apply the parking brake, place the engine in
the OFF position, remove the key fob from the
vehicle and lock your vehicle. If equipped with
Keyless Enter-N-Go, always make sure the keyless
ignition is in “OFF” position, remove the key fob
from the vehicle and lock the vehicle.

• Never leave children alone in a vehicle, or with

access to an unlocked vehicle.

(Continued)

GETTING TO KNOW YOUR VEHICLE

WARNING! (Continued)

• Allowing children to be in a vehicle unattended is

dangerous for a number of reasons. A child or others
could be seriously or fatally injured. Children
should be warned not to touch the parking brake,
brake pedal or the gear selector.

• Do not leave the key fob in or near the vehicle, or in

• Do not leave children or animals inside parked

vehicles in hot weather. Interior heat build-up may
cause serious injury or death.

CAUTION!

An unlocked vehicle is an invitation for thieves. Al-
ways remove key fob from the vehicle and lock all
doors when leaving the vehicle unattended.

REMOTE STARTING SYSTEM — IF EQUIPPED

This system uses the key fob to start the engine

conveniently from outside the vehicle while still

maintaining security. The system has a range of

328 ft (100 m).

The Remote Starting System also activates the Climate

Control, vented seats (if equipped) in temperatures above

80° F (26.7° C), and the optional heated seats, and optional

heated steering wheel in temperatures below 40° F (4.4° C).

Refer to “Heated Seats” in “Seats” in this section for further

information.

NOTE:
• The vehicle must be equipped with an automatic trans-

mission to be equipped with Remote Start.

• Obstructions between the vehicle and key fob may

reduce this range.

How To Use Remote Start

• Push Remote Start button on the key fob twice within

five seconds. Pushing the Remote Start button a third

time shuts the engine off.

GETTING TO KNOW YOUR VEHICLE

• To drive the vehicle, push unlock button, and place the

ignition in the ON/RUN position.

• With remote start, the engine will only run for 15

minutes (timeout) unless the ignition key is placed in the

ON/RUN position.

• The vehicle must be started with the key after two

consecutive timeouts.

All of the following conditions must be met before the

engine will remote start:
• Gear Selector in PARK
• Doors closed
• Hood closed
• Swing Gate closed
• Hazard switch off
• Brake switch inactive (brake pedal not pushed)
• Battery at an acceptable charge level
• PANIC button not pushed
• System not disabled from previous remote start event
• Vehicle alarm system indicator flashing
• Ignition in STOP/OFF position

• Fuel level meets minimum requirement
• All removable doors must not be removed
• Malfunction indicator light not illuminated

WARNING!

• Do not start or run an engine in a closed garage or

confined area. Exhaust gas contains Carbon Monox-
ide (CO) which is odorless and colorless. Carbon
Monoxide is poisonous and can cause serious injury
or death when inhaled.

• Keep key fobs away from children. Operation of the

Remote Start System, windows, door locks or other
controls could cause serious injury or death.

Remote Start Cancel Message — If Equipped

The following messages will display in the instrument

cluster if the vehicle fails to remote start or exits remote

start prematurely:
• Remote Start Cancelled — Door Open
• Remote Start Cancelled — Hood Open
• Remote Start Cancelled — Fuel Low
• Remote Start Cancelled — Swing Gate Open

GETTING TO KNOW YOUR VEHICLE

• Remote Start Cancelled — Time Expired
• Remote Start Disabled — Start Vehicle To Reset
The message will stay active until the ignition is placed in

the ON/RUN position.

To Enter Remote Start Mode

Push and release the Remote Start button on the key fob

twice within five seconds. The vehicle doors will lock, the

turn signals will flash twice, and the horn will chirp twice.

Then the engine will start, and the vehicle will remain in

the Remote Start mode for a 15-minute cycle.

NOTE:
• If an engine fault is present or fuel level is low, the

vehicle will start and then shut down in 10 seconds.

• The park lamps will turn on and remain on during

Remote Start mode.

• For security, power window operation is disabled when

the vehicle is in the Remote Start mode.

• The engine can be started two consecutive times (two

15-minute cycles) with the key fob. However, the igni-

tion must be placed in the ON/RUN position before you

can repeat the start sequence for a third cycle.

To Exit Remote Start Mode Without Driving The
Vehicle

Push and release the Remote Start button one time or allow

the remote start cycle to complete the entire 15-minute

cycle.

NOTE:

To avoid unintentional shutdowns, the system will

disable the one time push of the Remote Start button for

two seconds after receiving a valid Remote Start request.

To Exit Remote Start Mode And Drive The Vehicle

Before the end of 15-minute cycle, push and release the

unlock button on the key fob to unlock the doors, or unlock

the vehicle using Keyless Enter-N-Go — Passive Entry via

the door handles, and disarm the vehicle security alarm (if

equipped). Then, prior to the end of the 15-minute cycle,

push and release the START/STOP button.

NOTE:

For vehicles equipped with the Keyless Enter-

N-Go — Passive Entry feature, the message “Remote Start

Active — Push Start Button” will display in the instrument

cluster display until you push the ignition START button.

Remote Start Comfort Systems — If Equipped

When Remote Start is activated, the Climate Controls,

optional heated seats, and optional heated steering wheel

GETTING TO KNOW YOUR VEHICLE

in temperatures below 40° F (4.4° C). These features will

stay on through the duration of Remote Start or until the

ignition switch is cycled to the ON/RUN position.

General Information

The following regulatory statement applies to all Radio

Frequency (RF) devices equipped in this vehicle:
This device complies with Part 15 of the FCC Rules and

with Industry Canada license-exempt RSS standard(s).

Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, in-

cluding interference that may cause undesired opera-

tion.

NOTE:

Changes or modifications not expressly approved

by the party responsible for compliance could void the

user’s authority to operate the equipment.

SENTRY KEY

The Sentry Key Immobilizer system prevents unauthorized

operation by disabling the vehicle. The system does not

need to be armed or activated. Operation is automatic,

regardless of whether the vehicle is locked or unlocked.

The system uses the key fob to prevent unauthorized

vehicle operation. Therefore, only key fobs that are pro-

grammed to the vehicle can be used to start and operate the

vehicle. The system will shut the engine off in two seconds

if an invalid key fob is used to start the engine.
After turning the ignition switch to the ON/RUN position,

the vehicle security light will turn on for three seconds for

a bulb check. If the light remains on after the bulb check, it

indicates that there is a problem with the electronics. In

addition, if the light begins to flash after the bulb check, it

indicates that someone used an invalid key fob to start the

engine. Either of these conditions will result in the engine

being shut off after two seconds.
If the vehicle security light turns on during normal vehicle

operation (vehicle running for longer than 10 seconds), it

indicates that there is a fault in the electronics. Should this

occur, have the vehicle serviced as soon as possible by an

authorized dealer.

CAUTION!

The Sentry Key Immobilizer system is not compatible
with some aftermarket remote starting systems. Use of
these systems may result in vehicle starting problems
and loss of security protection.

GETTING TO KNOW YOUR VEHICLE

All of the key fobs provided with your new vehicle have

been programmed to the vehicle electronics.

Replacement Keys

NOTE:

Only key fobs that are programmed to the vehicle

electronics can be used to start and operate the vehicle.

Once a key fob is programmed to a vehicle, it cannot be

programmed to any other vehicle.

CAUTION!

• Always remove the key fobs from the vehicle and

lock all doors when leaving the vehicle unattended.

• For vehicles equipped with Keyless Enter-N-Go —

Ignition, always remember to place the ignition in
the OFF position.

NOTE:

Duplication of key fobs may be performed at an

authorized dealer. This procedure consists of programming

a blank key fob to the vehicle electronics. A blank key fob

is one that has never been programmed.
When having the Sentry Key Immobilizer System serviced,

bring all vehicle keys with you to an authorized dealer.

General Information

The following regulatory statement applies to all radio

frequency (RF) devices equipped in this vehicle:
This device complies with Part 15 of the FCC Rules and

with Industry Canada license-exempt RSS standard(s).

Operation is subject to the following two conditions:
1. This device may not cause harmful interference, and
2. This device must accept any interference received, includ-

ing interference that may cause undesired operation.

NOTE:

Changes or modifications not expressly approved

by the party responsible for compliance could void the

user’s authority to operate the equipment.

VEHICLE SECURITY ALARM — IF EQUIPPED

The vehicle security alarm monitors the vehicle doors for

unauthorized entry and the ignition switch for unauthorized

operation. When the alarm is activated, the interior switches

for door locks are disabled. The vehicle security alarm

provides both audible and visible signals. If something

triggers the alarm, the vehicle security alarm will provide the

following audible and visible signals: the horn will pulse, the

park lamps and/or turn signals will flash, and the vehicle

security light in the instrument cluster will flash.

GETTING TO KNOW YOUR VEHICLE

Rearming Of The System

If something triggers the alarm, and no action is taken to

disarm it, the vehicle security alarm will turn the horn off

after 29 seconds, 5 seconds between cycles, up to 8 cycles if

the trigger remains active and then the vehicle security

alarm will rearm itself.

To Arm The System

Follow these steps to arm the vehicle security alarm:
1. Make sure the vehicles ignition is cycled to the “OFF”

position (refer to

⬙Starting The Engine⬙ in ⬙Starting And

Operating

⬙ for further information).

2. Perform one of the following methods to lock the

vehicle:

• Push lock on the interior power door lock switch with

the driver and/or passenger door open.

• Push the lock button on the exterior Passive Entry

Door Handle with a valid key fob available in the same

exterior zone (refer to

⬙Keyless Enter-N-Go — Passive

Entry

⬙ in ⬙Getting To Know Your Vehicle⬙ for further

information).

• Push the lock button on the key fob.

3. If any doors are open, close them.

To Disarm The System

The vehicle security alarm can be disarmed using any of

the following methods:
• Push the unlock button on the key fob.
• Grasp the Passive Entry Unlock Door Handle (if

equipped, refer to

⬙Keyless Enter-N-Go — Passive En-

try

⬙ in ⬙Getting To Know Your Vehicle⬙ for further

information).

• Cycle the vehicle ignition system out of the OFF posi-

tion.

NOTE:
• The driver’s door key cylinder cannot arm or disarm the

vehicle security alarm.

• When the vehicle security alarm is armed, the interior

power door lock switches will not unlock the doors.

GETTING TO KNOW YOUR VEHICLE

The vehicle security alarm is designed to protect your

vehicle. However, you can create conditions where the

system will give you a false alarm. If one of the previously

described arming sequences has occurred, the vehicle

security alarm will arm regardless of whether you are in

the vehicle or not. If you remain in the vehicle and open a

door, the alarm will sound. If this occurs, disarm the

vehicle security alarm.
If the vehicle security alarm is armed and the battery

becomes disconnected, the vehicle security alarm will

remain armed when the battery is reconnected; the exterior

lights will flash, and the horn will sound. If this occurs,

disarm the vehicle security alarm.

DOORS

CAUTION!

Careless handling and storage of the removable door
panels may damage the seals, causing water to leak
into the vehicle’s interior.

Manual Door Locks

All doors are equipped with an interior rocker-type door

lock lever. To lock a door when leaving your vehicle, push

the rocker lever forward to the lock position and close the

door. To unlock the door, push the rocker lever rearward.

NOTE:

The mechanical flip key can be used to lock or

unlock the doors, swing gate, glove compartment, and

console storage.

Manual Door Lock

GETTING TO KNOW YOUR VEHICLE

WARNING!

• For personal security reasons and safety in a colli-

sion, lock the vehicle doors when you drive, as well
as when you park and exit the vehicle.

• When exiting the vehicle, always switch off the

ignition and remove the key from the vehicle. Unsu-
pervised use of vehicle equipment may cause severe
personal injuries and death.

• Never leave children alone in a vehicle, or with

access to an unlocked vehicle.

• Allowing children to be in a vehicle unattended is

dangerous for a number of reasons. A child or others
could be seriously or fatally injured. Children
should be warned not to touch the parking brake,
brake pedal or the gear selector.

• Do not leave the key fob in or near the vehicle or in

a location accessible to children. A child could oper-
ate power windows, other controls, or move the
vehicle.

Power Door Locks — If Equipped

The power door lock switch is located on each front door

panel. Push the switch forward to lock the doors, and

rearward to unlock the doors.

Power Door Lock Switch

1 — Lock Button
2 — Unlock Button

GETTING TO KNOW YOUR VEHICLE

WARNING!

• For personal security reasons and safety in a colli-

sion, lock the vehicle doors when you drive, as well
as when you park and exit the vehicle.

• When exiting the vehicle, always switch off the

ignition and remove the key from the vehicle. Unsu-
pervised use of vehicle equipment may cause severe
personal injuries and death.

• Never leave children alone in a vehicle, or with

access to an unlocked vehicle.

• Allowing children to be in a vehicle unattended is

dangerous for a number of reasons. A child or others
could be seriously or fatally injured. Children
should be warned not to touch the parking brake,
brake pedal or the gear selector.

• Do not leave the key fob in or near the vehicle or in

a location accessible to children. A child could oper-
ate power windows, other controls, or move the
vehicle.

Keyless Enter-N-Go — Passive Entry (If Equipped)

The Passive Entry system is a feature that allows you to

lock and unlock the vehicle’s door(s) and swing gate

without having to push the key fob lock or unlock buttons.

NOTE:
• Passive Entry may be programmed ON/OFF; refer to

“Uconnect Settings” in “Multimedia” for further infor-

mation.

• The key fob may not be detected by the vehicle passive

entry system if it is located next to a mobile phone,

laptop, or other electronic device; these devices may

interfere with the key fob’s wireless signal and prevent

the passive entry system from locking/unlocking the

vehicle.

• Passive Entry Unlock initiates illuminated approach

(Low Beams, License Plate Lamp, Position Lamps) for

whichever time duration is set between 0, 30 (default),

60 or 90 seconds. Passive Entry Unlock also initiates two

flashes of the turn signal lamps.

• If wearing gloves on your hands, or if it has been

raining/snowing on the Passive Entry door handle, the

unlock sensitivity can be affected, resulting in a slower

response time.

• If the vehicle is unlocked by Passive Entry and no door

is opened within 60 seconds, the vehicle will re-lock and

if equipped will arm the security alarm.

GETTING TO KNOW YOUR VEHICLE

To Unlock From The Driver Side

With a valid Passive Entry key fob within 5 ft (1.5 m) of the

driver’s door handle, grab the front driver door handle to

unlock the driver’s door automatically.

NOTE:

If “1st Press Of Key Fob Unlock” is programmed all

doors will unlock when you grab hold of the front driver’s

door handle. To select between “Unlock Driver Door 1st

Press” and “Unlock All Doors 1st Press,” refer to

“Uconnect Settings” in “Multimedia” for further informa-

tion.

To Unlock From The Passenger Side

With a valid Passive Entry key fob within 5 ft (1.5 m) of the

passenger door handle, grab the front passenger door

handle to unlock all doors and the swing gate automati-

cally.

NOTE:

All doors will unlock when the front passenger

door handle is grabbed regardless of the driver’s door

unlock preference setting (“Unlock Driver Door 1st Press”

or “Unlock All Doors 1st Press”).

Preventing Inadvertent Locking Of Passive Entry Key
Fob In Vehicle (FOBIK-Safe)

To minimize the possibility of unintentionally locking a

Passive Entry key fob inside your vehicle, the Passive Entry

system is equipped with an automatic door unlock feature

which will function only if the ignition switch is in the OFF

position.
FOBIK-Safe only executes in vehicles with passive entry.

There are three situations that trigger a FOBIK-Safe search

in any passive entry vehicle:
• A lock request is made by a valid Passive Entry key fob

while a door is open.

• A lock request is made by the Passive Entry door handle

while a door is open.

Grab The Door Handle To Unlock

GETTING TO KNOW YOUR VEHICLE

• A lock request is made by the door panel switch while

the door is open.

When any of these situations occur, after all open doors are

shut, the FOBIK-Safe search will be executed. If it finds a

Passive Entry key fob inside the car, the car will unlock and

alert the customer. If Passive Entry is disabled using

Uconnect System, the key protection described in

⬙Prevent-

ing Inadvertent Locking of Passive Entry Key Fob in

Vehicle

⬙ remains active/functional.

NOTE:

The vehicle will only unlock the doors during a

FOBIK-Safe operation when a valid Passive Entry key fob

is detected inside the vehicle. The vehicle will not unlock

the doors when any of the following conditions are true:
• A valid Passive Entry key fob is also detected outside of

the vehicle.

• The doors are manually locked using the door lock

knobs.

• Three attempts are made to lock the doors using the

door panel switch and then close the doors.

• There is a valid Passive Entry key fob outside the vehicle

within 5 ft. (1.5 m) of a Passive Entry door handle.

To Lock The Vehicle’s Doors And Swing Gate

With one of the vehicle’s Passive Entry key fob within 5 ft

(1.5 m) of the driver or passenger front door handles,

pushing the passive entry lock button will lock the vehicle

doors and the swing gate.

NOTE:

DO NOT grab the door handle, when pushing the

door handle lock button. This could unlock the door(s).

Push The Door Handle Button To Lock

GETTING TO KNOW YOUR VEHICLE

The vehicle doors can also be locked by using the lock

button located on the vehicle’s interior door panel.

To Unlock/Enter The Swing Gate

The Swing Gate passive entry unlock feature is built into

handle of the Swing Gate. With a valid Passive Entry key

fob within 5 ft (1.5 m) of the Swing Gate, grab the Swing

Gate handle to unlock the Swing Gate automatically, and

pull the Swing Gate to open.

NOTE:

If “Unlock All Doors 1st Press” is programmed all

doors & the swing gate will unlock when you grab hold of

the swing gate handle. To select between “Unlock Driver

Door 1st Press” and “Unlock All Doors 1st Press,” refer to

“Uconnect Settings” in “Multimedia” for further informa-

tion.

To Lock The Swing Gate

With a valid Passive Entry key fob within 5 ft (1.5 m) of the

swing gate, pushing the passive entry lock button will lock

the vehicle doors and the swing gate.

DO NOT Grab The Door Handle When Locking

Swing Gate Passive Entry Location

GETTING TO KNOW YOUR VEHICLE

NOTE:
• After pushing the door handle button, you must wait

two seconds before you can lock or unlock the doors,

using any Passive Entry door handle. This is done to

allow you to check if the vehicle is locked by pulling the

door handle without the vehicle reacting and unlocking.

• If Passive Entry is disabled using Uconnect System, the

key protection described in

⬙Preventing Inadvertent

Locking of Passive Entry Key Fob in Vehicle

⬙ remains

active/functional.

• The Passive Entry system will not operate if the key fob

battery is dead.

Child-Protection Door Lock System — Rear Doors

To provide a safer environment for small children riding in

the rear seats, the rear doors are equipped with Child-

Protection Door Lock system.

To Engage Or Disengage The Child-Protection Door Lock
System

1. Open the rear door.
2. Insert the tip of the ignition key into the lock and rotate

to the lock or unlock position.

3. Repeat steps one and two for the opposite rear door.

WARNING!

Avoid trapping anyone in a vehicle in a collision.
Remember that the rear doors can only be opened from
the outside when the Child-Protection locks are en-
gaged (locked).

Child Protection Door Lock Function

GETTING TO KNOW YOUR VEHICLE

Jeep Wrangler (2018 year). Instruction - part 2
