Jeep Grand Cherokee (2019 year). Instruction

Units
After pressing the “Units” button on the touchscreen, the following settings will be available:

Setting Name

Selectable Options

Units

Metric

Custom

NOTE:
The “Custom” option allows you to set the “Speed” (MPH, or km/h), “Distance” (mi, or km), “Fuel Consumption”
[MPG (US), MPG (UK), L/100 km, or km/L], “Pressure” (psi, kPa, or bar), and “Temperature” (°C, or °F) units of
measure independently.

Voice
After pressing the “Voice” button on the touchscreen, the following settings will be available:

Setting Name

Selectable Options

Voice Response Length

Brief

Detailed

Show Command List

Never

With Help

Always

516

MULTIMEDIA

Clock & Date
After pressing the “Clock & Date” button on the touchscreen, the following settings will be available:

Setting Name

Selectable Options

Set Time and Format

12 hour

24 hour

NOTE:
Within the “Set Time and Format” setting, press the corresponding arrow buttons on the touchscreen to adjust to the
correct time.

Set Date — If Equipped

Up Arrow

Down Arrow

NOTE:
Within the “Set Date” setting, press the corresponding arrow buttons on the touchscreen to adjust to the correct date.

MULTIMEDIA

517

Safety/Assistance
After pressing the “Safety/Assistance” button on the touchscreen, the following settings will be available:

Setting Name

Selectable Options

ParkView Backup Camera

Delay — If Equipped

Off

NOTE:
The “ParkView Backup Camera Delay” setting determines whether or not the screen displays the rear view image
with dynamic grid lines for up to ten seconds after the vehicle is shifted out of REVERSE. This delay cancels if the
vehicle’s speed exceeds 8 mph (13 km/h), the transmission is shifted into PARK, or the ignition is switched to the
OFF position.

ParkView Backup Camera

Active Guide Lines — If

Equipped

Off

NOTE:
The “ParkView Backup Camera Active Guide Lines” feature overlays the Rear Backup Camera image with active, or
dynamic, grid lines to help illustrate the width of the vehicle and its project back up path, based on the steering
wheel position when the option is checked. A dashed center line overlay indicates the center of the vehicle to assist
with parking or aligning to a hitch/receiver.

518

MULTIMEDIA

Setting Name

Selectable Options

Forward Collision

Warning — If Equipped

Off

Warning Only

Warning & Braking

NOTE:
Changing the FCW status to “Off” prevents the system from warning you of a possible collision with the vehicle in
front of you.
The FCW system state is kept in memory from one ignition cycle to the next. If the system is turned OFF, it will re-
main off when the vehicle is restarted.
Forward Collision Warning includes Advanced Brake Assist (ABA). The ABA applies additional brake pressure when
the driver requests insufficient brake pressure to avoid a potential frontal collision. When the “Sound Only” option is
selected a chime sounds alerting you of a possible collision with the vehicle in front of you and more brake pressure
is needed. When the “Sound and Brake” option is selected, it applies the brakes to slow your vehicle in case of poten-
tial forward collision and sound an audible chime to alert you.

Forward Collision

Warning Sensitivity — If

Equipped

Far

Med

Near

NOTE:
The “Forward Collision Warning Sensitivity” setting determines at what relative distance the vehicle directly in front
of you needs to be at, before the system warns you of a possible collision with the vehicle directly in front of you,
based on the option is selected. “Far” gives you the most amount of reaction time, whereas “Near” will give you the
least amount of reaction time, based on the distance between the two vehicles.

MULTIMEDIA

519

Setting Name

Selectable Options

ParkSense — If Equipped

Sound Only

Sound & Display

NOTE:
The “ParkSense” system setting scans for objects behind the vehicle when the transmission gear selector is in RE-
VERSE and the vehicle speed is less than 7 mph (11 km/h), when enabled. It provides an alert (audible and/or vi-
sual) to indicate the proximity to other objects. The system can be enabled with “Sound Only,” or “Sound & Display.”

Front ParkSense Volume

Low

Medium

High

Rear ParkSense Volume

Low

Medium

High

Rear ParkSense Braking

Assist — If Equipped

Off

NOTE:
When the “Rear ParkSense Braking Assist” feature is selected, the park assist system detects objects located behind
the vehicle and utilize autonomous braking to stop the vehicle.

LaneSense Warning— If

Equipped

Early

Medium

Late

NOTE:
The “LaneSense Warning” setting determines at what distance the LaneSense system warns you, through steering
wheel feedback, of a possible lane departure.

520

MULTIMEDIA

Setting Name

Selectable Options

LaneSense Strength

(LDW) — If Equipped

Low

Medium

High

Blind Spot Alert — If

Equipped

Off

Lights

Lights & Chime

NOTE:
When the “Blind Spot Alert” feature is selected, the Blind Spot Monitor (BSM) system is activated and shows a visual
alert in the outside mirrors, or it shows a visual alert in the outside mirrors as well as play an audible alert when the
turn signal is on. When “Off” is selected, the Blind Spot Monitor (BSM) system is deactivated.
If your vehicle has experienced any damage in the area where the sensor is located, even if the fascia is not damaged,
the sensor may have become misaligned. Take your vehicle to an authorized dealer to verify sensor alignment. A sen-
sor that is misaligned results in the BSM not operating to specification.

Rain Sensing Auto Wipers

— If Equipped

Off

Hill Start Assist — If

Equipped

Off

Tilt Mirrors in Reverse

Off

Paddle Shifters

Enable

Disable

MULTIMEDIA

521

Setting Name

Selectable Options

Steering Feel Options

Sport

Normal

Comfort

NOTE:
The “Steering Feel Options” setting allows you to adjust the steering effort and feel. Press the “Comfort” button on
the touchscreen to provide a balance of steering feel and steering effort. Press the “Normal” button on the touch-
screen to provide greater steering feel, requiring greater steering effort. Press the “Sport” button on the touchscreen to
provide the greatest amount of steering feel, requiring the highest amount of steering effort.

Lights
After pressing the “Lights” button on the touchscreen, the following settings will be available:

Setting Name

Selectable Options

Headlight Off Delay

0 sec

30 sec

60 sec

90 sec

NOTE:
When the “Headlight Off Delay” feature is selected, it allows the adjustment of the amount of time the headlights
remain on after the engine is shut off.

522

MULTIMEDIA

Setting Name

Selectable Options

Headlight Illumination On

Approach

0 sec

30 sec

60 sec

90 sec

NOTE:
When this feature is selected, it allows the adjustment of the amount of time the headlights remain on after the doors
are unlocked with the key fob.

Headlights With Wipers — If

Equipped

Off

Auto High Beam — If Equipped

Off

NOTE:
When the “Auto High Beams” is selected, the high beam headlights will activate/deactivate automatically under cer-
tain conditions.

Daytime Running Lights

Off

Flash Lights With Lock

Off

MULTIMEDIA

523

Doors & Locks
After pressing the “Doors & Locks” button on the touchscreen, the following settings will be available:

Setting Name

Selectable Options

Auto Door Locks

Off

NOTE:
The “Auto Door Locks” feature locks all doors automatically when the vehicle reaches a speed of 12 mph (20 km/h).

Auto Unlock On Exit

Off

NOTE:
When the “Auto Unlock On Exit” feature is selected, all doors unlock when the vehicle is stopped, the transmission is
in the PARK or NEUTRAL position, and the driver’s door is opened.

Flash Lights With Lock

Off

Sound Horn With Lock

Off

1st Press

2nd Press

Sound Horn With Remote

Start — If Equipped

Off

524

MULTIMEDIA

Setting Name

Selectable Options

Remote Door Unlock

Driver Door

All Doors

NOTE:
When “Driver” is selected, only the driver’s door unlocks on the first push of the key fob unlock button, you must
push the key fob unlock button twice to unlock the passenger’s doors. When “All” is selected, all of the doors un-
locks on the first press of the key fob unlock button. If “All” is programmed, all doors unlock no matter which Pas-
sive Entry equipped door handle is grasped. If “Driver” is programmed, only the driver’s door unlocks when the
driver’s door is grasped. Touching the handle more than once only results in the driver’s door opening once. If the
driver’s door is opened, the interior door lock/unlock switch can be used to unlock all doors (or use key fob).

Passive Entry

Off

Memory Linked To FOB

— If Equipped

Off

NOTE:
The “Memory Linked To FOB” feature provides automatic recall of all settings stored to a memory location (driver’s
seat, exterior mirrors, steering column position and radio station pre-sets) to enhance driver mobility when entering
and exiting the vehicle.

Power Liftgate Alert — If

Equipped

Off

NOTE:
The “Power Liftgate Alert” feature plays an alert when the power liftgate is raising or lowering.

MULTIMEDIA

525

Auto-On Comfort — If Equipped
After pressing the “Auto-On Comfort & Remote Start” button on the touchscreen, the following settings will be available:

Setting Name

Selectable Options

Auto-On Driver Heated

Seat & Steering Wheel —

If Equipped

Off

Remote Start

All Starts

NOTE:
When this feature is selected, the driver’s heated seat and heated steering wheel will automatically turn ON when
temperatures are below 40° F (4.4° C). When temperatures are above 80° F (26.7° C), the driver vented seat will turn
ON.

Engine Off Options
After pressing the “Engine Off Options” button on the touchscreen, the following settings will be available:

Setting Name

Selectable Options

Engine Off Power

Delay — If

Equipped

0 sec

45 sec

5 min

10 min

NOTE:
When the “Engine Off Power Delay” feature is selected, the power window switches, radio, Uconnect Phone system
(if equipped), power sunroof (if equipped), and power outlets will remain active for up to ten minutes after the igni-
tion is cycled to OFF. Opening either front door will cancel this feature.

526

MULTIMEDIA

Setting Name

Selectable Options

Headlight Off Delay

0 sec

30 sec

60 sec

90 sec

NOTE:
When the “Headlight Off Delay” feature is selected, it allows the adjustment of the amount of time the headlights
remain on after the engine is shut OFF.

Easy Exit Seat — If

Equipped

Off

NOTE:
When the “Easy Exit Seat” feature is selected, it provides automatic driver seat positioning to enhance driver mobility
when entering and exiting the vehicle.

Auto Entry/Exit — If

Equipped

Off

NOTE:
The “Auto Entry/Exit” feature automatically lowers the vehicle ride height position when shifted into PARK, when it
is selected.

MULTIMEDIA

527

Compass Settings — If Equipped
After pressing the “Compass Settings” button on the touchscreen, the following settings will be available:

NOTE:

Before compass calibration is performed, the compass variance zone should be set for best results.

Setting Name

Selectable Options

Compass

Variance

When the “Compass Variance” feature is selected, it allows the compass variance to be set to any number from 1 to
15 per the compass variance zone map figure.
Compass Variance is the difference between Magnetic North and Geographic North. To compensate for the differ-
ences, the variance should be set for the zone where the vehicle is being driven, illustrated in the zone map. Once
properly set, the compass will automatically compensate for the differences when calibrated, and provide the most
accurate compass headings.

528

MULTIMEDIA

Compass Calibration

Start

NOTE:
Press “Compass Calibration” on the touchscreen to enter calibration. To start calibration of the compass, press the
“Yes” button on the touchscreen and complete one or more 360-degree turns (in an area free from large metal or me-
tallic objects). A message will appear on the touchscreen when the compass has been successfully calibrated.
Keep magnetic materials away from the rear view mirror, such as Mobile Phones, Laptops and Radar Detectors. This
is where the compass module is located, and it can cause interference with the compass sensor, and it may give false
readings.

Compass Variance Zone Map

MULTIMEDIA

529

Audio

After pressing the “Audio” button on the touchscreen, the
following settings will be available:

Setting Name

Selectable Options

Balance/Fade

Up Arrow

Button

Down Ar-

row Button

Left Arrow

Button

Right Ar-

row Button

Center “C”

Button

NOTE:
When in this display you may adjust the “Balance/Fade” of the audio by using the “Arrow” button on the touch-
screen to adjust the sound level from the front and rear or right and left side speakers. Press the “Center ‘C’ Button”
on the touchscreen to reset the balance and fade to the factory setting.

Equalizer

Bass

Mid

Treble

NOTE:
When in this display you may adjust the “Bass”, “Mid”, and “Treble” settings. Adjust the settings with the “+” and
“–” setting buttons on the touchscreen or by selecting any point on the scale between the “+” and “–” buttons on the
touchscreen. Bass/Mid/Treble also allow you to simply slide your finger up or down to change the setting as well as
press directly on the desired setting.

Speed Adjusted Volume

Off

Surround Sound — If Equipped

Off

530

MULTIMEDIA

Setting Name

Selectable Options

Auto Play

Off

NOTE:
When selecting the “Auto Play” sub setting, a message will pop up stating “USB devices will automatically play me-
dia when AutoPlay is turned On.”

Loudness — If Equipped

Yes

NOTE:
This feature improves sound quality at lower volumes when enabled.

AUX Volume Offset — If Equipped

-3

NOTE:
This feature provides the ability to tune the audio level for portable devices connected through the AUX input.

Phone/Bluetooth
After pressing the “Phone/Bluetooth” button on the touchscreen, the following settings will be available:

Setting Name

Selectable Options

Do Not Disturb

List of Settings

NOTE:
Press “Do Not Disturb” to access the available settings. The following settings are: Auto Reply (both, text, call), Auto
Reply Message (custom, default) and Custom Auto Reply Message (create message).

MULTIMEDIA

531
