assembly. However, do not use chassis grease, bear- Do not force parts into place. The transmission components and subassemblies are easily installed by If a part seems extremely difficult to install, it is either misaligned or incorrectly assembled. Also ver- The planetary geartrain, front/rear clutch assem- blies and oil pump are all much easier to install (1) Install rear servo piston, spring and retainer (Fig. 175). Install spring on top of servo piston and (2) Install front servo piston assembly, servo spring and rod guide (Fig. 176). (3) Compress front/rear servo springs with Valve Spring Compressor C-3422-B and install each servo Fig. 175 Rear Servo Components 1 – SERVO PISTON Fig. 176 Front Servo Components 1 – PISTON SEAL RINGS Fig. 177 Compressing Front/Rear Servo Springs 1 – SPRING COMPRESSOR TOOL C-3422-B 21 - 114 42RE AUTOMATIC TRANSMISSION WJ DISASSEMBLY AND ASSEMBLY (Continued) |
