321

Telephone Operation - Standard

R

RECEIVING A CALL

An incoming call automatically switches
the sound system into the phone mode.
The audio panel display will show CALL
and the phone will ring through the
vehicle’s audio system.

If automatic answer has been set in your
phone, the call will be automatically
answered by your mobile telephone.

To answer:

Press

 on the steering wheel or;

press

 on the audio panel.

To end:

Press

 on the steering wheel or;

press

 on the audio panel.

Call line Ident

If the caller has the Call Line Ident (CLI)
feature, CALL is shown on the audio
panel display, followed by the caller’s
phone number and name (when
available). The display may truncate
lengthy names.

REJECTING A CALL

Press CLEAR on the audio
panel to reject an incoming
call.

MAKING A CALL

When making a call, there are two
methods of dialling: keypad and memory
search.

Keypad dialling

To dial:

Press and hold

 on the steering wheel

or;

press

 on the audio panel.

PHONE will be displayed.

Key in the phone number on the audio
panel keypad. The number will be
displayed.

To connect:

Press

 on the steering wheel or;

press

 on the audio panel.

The display will show CALLING.

To end:

Press

 on the steering wheel or;

press

 on the audio panel.

Speed dialling

Note: Speed dialling selects the first nine
locations stored in your phone’s address
book.

To dial:

Press and hold

 on the steering wheel

or;

press

 on the audio panel.

PHONE will be displayed.

On the audio panel keypad, press and
hold the required speed dialling memory
location number 1 to 9, which
corresponds with locations 1 to 9 in your
mobile phone’s address book.

After three seconds, CALLING will be
displayed.

Telephone Operation - Standard

322

L

To end:

Press

 on the steering wheel or;

press

 on the audio panel.

Note: Speed dialling can only be used
once your mobile phone’s address book
has been transferred to the vehicle’s
phone system. For more information, refer
to page 328.

MEMORY RECALL DIALLING

Using audio panel

Press

 on the audio panel.

Phone will be displayed.

Press the MR button.

LOCATION will be displayed.

On the audio panel keypad, press
required memory number 1 to 499.

Note: The location number of phone book
entries stored on your mobile phone may
vary from those stored in the vehicle
phone book.

To connect:

Press

 on the steering wheel or;

press

 on the audio panel.

The display will show CALLING.

To end:

Press

 on the steering wheel or;

press

 on the audio panel.

Using steering wheel controls

Press and hold button 3, see page 315.

PHONE will be displayed.

On the audio panel keypad, press
required memory number 1 to 749.

To connect:

Press

 on the steering wheel or;

press

 on the audio panel.

The display will show CALLING.

To end:

Press

 on the steering wheel or;

press

 on the audio panel.

LAST NUMBER REDIAL

Note: Last number redial is only
supported on systems fitted with the
touch-screen.

323

Telephone Operation - Touch-Screen

R

Telephone Operation - Touch-Screen

OVERVIEW

On vehicles fitted with the navigation
system, the audio panel keyboard is
replaced with touch-screen controls.

Control of the system via the steering
wheel controls is unchanged, as
described in the previous section.

With the ignition switch in position I or II,
pressing the

 button to the left of the

screen will display the following screen
controls.

The message window to the right of the
screen will provide information on the
telephone system’s status. If the phone is
connected correctly then the display will
show Phone Connected, or if the phone
is not connected to the vehicle, Discover
Me will be displayed.

MAKING A CALL

Calls are made by using the digit and

 touch-controls, or the memory

functions described on page 324.

Erroneous digits can be deleted by
touching .

The number called is displayed at the top
of the screen.

The screen will display Calling when
establishing a call. On connection,
Connected is displayed and

 is

illuminated.

If the ignition is switched off, the call will
be maintained and the touch-screen can
be manually turned off. Touch

 to

terminate the call.

Telephone Operation - Touch-Screen

324

L

RECEIVING A CALL

On receipt of a call, the screen will display
Incoming Call regardless of the audio
system operating mode.

This is accompanied by Accept and
Cancel touch-controls, enabling the user
to answer the call or cancel it.

END CALL FUNCTION

A telephone icon is displayed whenever a
telephone call is in progress.

The icon is displayed during an incoming
call and during an outgoing call.

The telephone call may be ended by
touching the icon.

Telephone call is in progress. Call
may be ended by touching this
icon.

OTHER FUNCTIONS

Using the menu

Touch Menu to display the above screen.
This screen provides access to memory
functions and last number redial.

When the vehicle is in motion, it will not be
possible to use the Name touch-control.

Last number redial

The Last Number Redial memory
function enables the user to quickly recall
the previously used number.

Use of the List touch-control will display
the last ten numbers dialled.

Note: Last Number Redial recalls the
last ten numbers called from your mobile
phone, if your phone supports this
feature.

With certain mobile phones, the last
number redial may work in reverse order.
This is the way the phone sends the call
stack to the vehicle’s system.
