309

Compact Disc Changer

R

CD CHANGER - STANDARD
AUDIO

CD changer mode

The audio display indicates the CD and
track being played, and CD status.

Below is an example of the display when
playing track 1 from CD4.

CDC button

Press CDC to select CD changer
mode.

This function can also be controlled from
the appropriate switch on the steering
wheel.

CD selection

Preset buttons 1 to 6 select the compact
discs in those positions in the magazine.
If there is no disc in the selected position,
NO DISC will be displayed. If there is no
magazine in the CD changer,
NO MAGAZINE will be displayed.

MIX

To play random tracks from the
disc, press and release the MIX
button. MIX will be displayed. To
cancel, press the MIX button
again.

To play random tracks from all discs
present in the magazine, press the MIX
button for two seconds. DISC MIX will be
momentarily displayed, followed by
D MIX. To cancel, press and hold the MIX
button.

Seek up and down

This control selects seeking
of tracks up or down.
Momentarily press the

right-hand button to skip to the next track.
Repeated pressing will select further
tracks.

The left-hand button returns to the
beginning of the current track. Repeated
pressing selects previous tracks.

Pushing and holding either button selects
cue and review of the CD.

Other messages:
CD1 LOADING

CD1 is being
loaded.

NO DISC

In the selected
position.

NO MAGAZINE

In the CD
autochanger.

CD1 MIX 10

The player is playing
CD1 in MIX mode
(track 10).

D MIX

All CDs are in MIX
mode.

MAG EJECT

Magazine is being
ejected.

PAUSED

The CD changer is
paused and ready to
play.

Compact Disc Changer

310

L

Note: Sound level is reduced when
cueing and reviewing a CD.

REPEAT

Momentarily press the
REPEAT button to repeat the
current CD track being played,

R-ONE will be displayed. To cancel,
momentarily press the REPEAT button
again.

Press and hold the REPEAT button for
two seconds to repeat the current CD,
R-ALL will be displayed. To cancel, press
and hold the REPEAT button again for
two seconds.

Pause

When playing a CD, press CDC
button to pause play. Press again
to continue play.

CD CHANGER WITH TOUCH-
SCREEN

CD changer mode

In CD changer mode, touch-screen
buttons (shown above) provide for track
and disc selection. Discs present in the
magazine are highlighted in the display.

A disc is selected by touching the
appropriate disc button which, when
playing, has a red active surround.

The track and track duration are
displayed during play.

CDC button

Press CDC to select CD changer
mode.

Note: This function can also be controlled
from the appropriate button on the
steering wheel (see page 284).

Mix and CD mix

To play random tracks from a
selected disc, press and release
the Mix button. MIX TRACKS

will be displayed. To cancel, touch the
Mix button again.

311

Compact Disc Changer

R

To play random tracks from all discs
present in the magazine, touch and hold
the Mix button for more than
two seconds. MIX ALL will be displayed.
To cancel, touch and hold the Mix button.

Seek up and down

Touch and release to seek
tracks up or down.
Momentarily press the

right-hand button to skip to the next track.
Repeated pressing will select further
tracks.

The left-hand button returns to the
beginning of the current track. Repeated
pressing selects previous tracks.

Pushing and holding either button selects
cue and review of the CD.

Note: Sound level is reduced when
cueing and reviewing a CD.

Repeat

Momentarily press the Repeat
button to repeat the current CD
track being played. REPEAT

TRACK will be displayed. To cancel,
momentarily press the Repeat button
again.

Press and hold the Repeat button for
two seconds to repeat the current CD.
REPEAT DISC will be displayed. To
cancel, press and hold the Repeat button
again for two seconds.

Pause

Touch the pause button to
pause CD play.

Note: Pause button function changes to a
play button, a subsequent press will
resume CD play.

Telephone Introduction

312

L

Telephone

INTRODUCTION

What is Bluetooth?

Bluetooth is an international standard that
allows electronic components to
communicate with each other, using a
short-range radio link. Bluetooth
eliminates the need for wires or cables:
typically, devices can communicate at a
range of up to 10 metres (33 feet).

The Bluetooth in-car telephone system
allows certain mobile phones to be used
hands-free in your vehicle: there is no
need to connect the mobile phone to a
cradle or cable.

Bluetooth is a registered trademark of
Bluetooth SIG, Inc.

SYSTEM OVERVIEW

The vehicle’s Bluetooth telephone system
can be used with an appropriate,
Bluetooth-equipped mobile phone.

The mobile phone must be paired with the
vehicle system before use. See
page 316 for more information.

Once paired, the mobile phone can be
operated via the steering wheel switches
or the keypad and phone buttons on the
audio panel or touch-screen. The mobile
phone doesn’t need to be physically
connected to the vehicle: it can be left in
a jacket pocket, for instance. Calls are
routed through the vehicle’s audio
speakers, and a dedicated microphone is
fitted to the roof lining, near the driver’s
head.

You can use the system to answer or
reject incoming calls, make outgoing calls
or alter the call volume. The system does
not support SMS text messages.

Note: The vehicle ignition must be set to
position I or II in order to use the phone.

Call volume

The volume of telephone calls can be
adjusted for hands-free phone operation.
To adjust the volume, operate the audio
system’s ON/OFF volume control during
a phone call.

If the audio system is in use when the
phone becomes active, the audio system
source is suppressed for the duration of
the call.

The Jaguar telephone system is designed
to function with a wide variety of
Bluetooth-equipped mobile phones. The
audio and echo characteristics vary
between models of mobile phones: as a
result, it may take a few seconds for the
vehicle system to adapt to provide
optimal audio performance.

In order to achieve the best possible
audio performance, it may be necessary
to reduce the system volume slightly
when using certain mobile phones.

Audio panel display

Phone related messages are shown on
the audio panel display or touch-screen
(where fitted) when the phone system is
active.
