277

Touch-screen

R

IN-CAR TELEPHONE

The telephone is described in the
separate in-car telephone handbook.

JAGUARVOICE

JaguarVoice provides a safe and
convenient way for the driver and/or rear
occupants to control the following vehicle
systems (where fitted):
• Sound system (radio, CD player and

CD changer – as applicable).

• In-car telephone.
• Climate control system (front user

only unless 4-zone climate control is
fitted).

• Television and Teletext.
• Display screen (front user only).
• Navigation (front user only).

The system is controlled in the front of the
vehicle by the steering wheel voice
button, and, when fitted in the rear of the
vehicle by the rear multimedia switchpack
voice buttons, see the Voice Control
chapter of this handbook (starting on
page 331).

REAR MULTIMEDIA

For details of this system, see the
separate rear multimedia handbook.

WINDOW TINTING

!

WARNING:

Do not have your vehicle windows
tinted with a metal oxide tinting (for
maximum heat reduction from sun
load) if you have a Navigation system
fitted to your vehicle.

Metal oxide tinting prevents the reception
of the Global Positioning Satellite (GPS)
signals by the antenna causing the
navigation system to stop functioning.

A non-metal tinting should be used if you
require window tinting and if in doubt,
contact your Jaguar Dealer for advice.

Touch-screen Display

278

L

Touch-screen Display

TOUCH-SCREEN DISPLAY

TOUCH-SCREEN USE AND
CARE

When the ignition switch is initially turned
to position I or II, the touch-screen will
display the Jaguar logo screen followed
by activation and display of the mode
previously used. Display of buttons for
other systems can be obtained by
pressing the appropriate perimeter
button. Functions of the MENU button are
described on the following pages.

!

WARNING:

In the interests of road safety, only
operate, adjust or view the system
when it is safe to do so.

Caution: Care must be taken to avoid
spilling or splashing drinks onto the
screen. In the event of such an
occurrence advise your Jaguar Dealer.

Note: When operating touch-screen
buttons, always extend the tip of one
finger, and withhold the thumb and
remaining fingers from the screen.
Touching the screen with more than one
finger at a time may cause false inputs.

The touch-screen and inner bezel must be
kept clean to maintain optimum
performance. Finger marks and attracted
dust should be regularly removed using a
soft cloth and a Jaguar approved cleaning
agent.

279

Touch-screen Display

R

MENU

Pressing the MENU perimeter button will
display the system menu screen.

The screen display can be blanked out by
touching the Screen Off button.

Touch the screen, or press any of the
perimeter buttons, to restore the display.

VOLUME PRESET

After touching the Volume Preset button,
the screen displays the buttons for
adjustment of volume associated with the
navigation system, JaguarVoice,
telephone, Traffic Announcements (TA)
and Automatic Volume Control (AVC).
Adjustment of AVC varies the rate at
which volume is increased or decreased
relative to vehicle speed.

Touch or hold the + or – button to adjust
the volume of the selected function.

Note: If any of the volume slides are
adjusted to the fully – position, then the
volume is turned fully off.

Confirm your selection by touching OK
and the system menu screen will once
again be displayed.

Touch-screen Display

280

L

BRIGHTNESS/CONTRAST

After touching the Brightness/Contrast
button, the screen displays the buttons
for adjustment of the screen display
characteristics. The centre window shows
the currently selected navigation view.

Touch the + or - button to adjust the
selected function.

Screen brightness and contrast can also
be dimmed for night driving. This is
achieved either manually via the Day,
Night or Twilight buttons (independent of
the exterior light master switch position),
or automatically via the Auto button
(controlled by the exterior light master
switch position).

Touch the Default button to restore the
default settings.

Confirm your selection by touching OK.

SYSTEM SETUP

After touching the System Setup button,
the screen displays the buttons for
selecting user settings or vehicle settings.

Note: Vehicles which have the
JaguarVoice system fitted will have an
additional button on the system setup
screen for voice training.
