137

Interior Lighting

R

Interior Lighting

CABIN LIGHTING

1. Front and rear courtesy lamps and

footwell lamps.

2. Reading/map lamps.

3. Centre console illumination.

Interior lighting comprises front overhead
courtesy lamp and two front and two rear
reading/map lamps. Vanity mirror, glove
compartment, footwell and luggage
compartment lamps are also provided.

Pressing the centre switch (1) in the
overhead console turns the front and rear
courtesy lamps and footwell lamps on. A
second press turns the lamps off.

The centre console area is illuminated by
a small lamp from the overhead console
(3). This is on whenever the sidelamps are
on and can be controlled by the dimmer
switch.

Reading/map lamps

The reading/map lamps are turned on and
off by individual switches (2).

The reading/map lamps will remain on for
up to 15 minutes after the ignition has
been turned off.

Rear Lighting

The rear interior lamps can be switched
on or off by pressing the lens cover.

Illuminated entry/Exit

The interior lamps fade on when a door is
opened and go out when the engine is
started or 15 seconds after the last door is
closed. If any door is left open, the lamps
will fade off after two minutes.

When the vehicle is unlocked with a key or
the key transmitter, the courtesy lamps
will come on at maximum brightness for
two minutes if a door is not opened.

With the engine running, opening any
door will put on all interior lamps, they will
go out immediately after the last door is
closed.

Glove compartment

The glove compartment will be
illuminated when the lid is opened.

Luggage Compartment Lighting

The luggage compartment will be
illuminated when the lid is opened.

1

2

2

3

E86314

E86315

Interior Lighting

138

L

DIMMER SWITCH

The instruments, switchpacks, in-car
entertainment panel and climate control
panel will be lit when the exterior lamps
are switched on.

Push and release the knob to extend it for
ease of operation.

Rotate the knob to adjust the illumination
to the required level.

Push the knob again to place it in the
stowed position.

BATTERY SAVER

If the interior lamps are switched on using
the centre switch in the overhead console
and the ignition switch is turned to
position 0, the lamps will automatically
turn OFF after 40 minutes.

If the interior lamps are switched on by
opening a door and a key is left in the
ignition switch in position 0, the lamps will
automatically turn off after ten minutes.

If the glove compartment or vanity mirror
lamps are switched on and the ignition
switch is turned to position 0 or the key is
removed, the lamps will automatically
turn OFF after 40 minutes.

JAG0800

139

Parking Assist

R

Parking Assist

INTRODUCTION

!

WARNING:

Parking aids may not detect moving
objects such as children and animals
until they are dangerously close.
Always use extreme caution when
manoeuvring.

Parking assist is always automatically
switched on when the ignition is turned
on.

Caution: Parking aids are for guidance
only, and are not intended to replace
the driver's visual checks for
obstructions when manoeuvring.

Caution: PDC sensors may not detect
some obstructions. Obstructions such
as narrow posts, small objects close to
the ground, and some objects with
dark non-reflective surfaces, for
example.

Caution: Systems which use the same
frequency band as the front PDC
sensors may cause irregular tones to
be emitted.

Caution: When washing the vehicle do
not aim high pressure water jets
directly at the sensors. Do not use
abrasive materials or hard/sharp
objects to clean the sensors. Only use
approved vehicle shampoo.

Note:

•

For reliable operation, the sensors in
the front (if fitted) and rear bumpers
should be kept free from frost, ice and
grime.

•

When using a high pressure spray the
sensors should only be sprayed briefly
and at least 200 mm (8 inches)
distance from the sensors.

•

Front parking assist may sound
spurious tones if it detects a
frequency tone using the same band
as the sensors, for example, a motor
cycle exhaust.

Towing

When an approved Jaguar tow bar
electrical system is fitted, the rear parking
assist is automatically turned off if a trailer
is attached to the vehicle.

Rear fitted accessories

Particular care must be taken with rear
fitted accessories, for example, a tow bar
or a bicycle carrier, as the rear park assist
will only indicate the distance from the
bumper to the obstacle.

Parking Assist

140

L

PARKING ASSIST

When reverse gear is selected and
ignition is on, rear parking assist
automatically provides an audible
proximity warning (to the nearest
detected obstacle) when reversing the
vehicle, if obstacles are detected within
the operating range, shown in the
illustration above, between
approximately:

1. 600 mm (24 inches)

2. 1600 mm (63 inches)

1

2

E86368
