109

Driving Position Memory

R

4. Press button 1, 2 or 3 and then press

any button on the integrated key. Both
button presses must occur while the
red LED is illuminated.

5. Repeat for the other integrated key,

pressing the remaining memory
buttons.

To cancel integrated key memory recall:

1. Place a key into the ignition switch

and leave in the OFF position.

2. Press the M button: The red LED will

illuminate for a five second period.

3. Press any button on the integrated

key (except the panic button, if fitted)
then press the M button again. Both
button presses must occur while the
red LED is illuminated.

Note: If memory recall is performed using
an integrated key with the vehicle in
entry/exit position, the steering column
and seat will not return to the memorised
position until either the integrated key is
placed in the ignition switch or the driver’s
door is closed.

Operating tips
• When making adjustments to a set

driving position, reset the new
position in the same memory channel.

• A driving position will only be

memorised during the five second
period when the red memory LED is
illuminated.

• Previous memory is erased when a

new driving position is entered.

Luggage Compartment

110

L

Luggage Compartment

LUGGAGE TIE-DOWN LOOPS

!

WARNING:

Locate heavy loads in the luggage
compartment towards the front of the
vehicle and secure them to stop them
sliding. Loose items can be a hazard.

!

WARNING:

Do not drive with the luggage
compartment lid open as exhaust
fumes can be drawn into the passenger
compartment.

Four loops are positioned in the luggage
compartment for attaching straps to
secure loads and prevent them from
sliding over the luggage floor.

These loops are not to be used for
securing passengers or animals nor as
anchorages for child restraints.

It is advisable to distribute luggage weight
evenly over the entire luggage floor area.

A range of Jaguar storage accessories,
including a luggage retaining net, are
available from your Jaguar Dealer.

!

WARNING:

A luggage net is not designed to
restrain objects in the event of a
collision.

E86382

111

Instruments

R

On the Road

INSTRUMENT PANEL

None of the instruments will show correct
indications until the ignition is switched
ON (position II).

If the exterior lamps switch is ON and the
ignition is ON, the display brightness can
be varied using the dimmer switch.

The instruments shown above are:

1. Tachometer.

2. Speedometer.

3. Message centre.

4. Fuel gauge.

5. Engine temperature gauge.

Tachometer

The tachometer indicates engine speed in
revolutions per minute and is calibrated in
increments of 250 rev/min extending to:
• 8000 rev/min for naturally aspirated

engines.

• 7000 rev/min for supercharged

engines.

Do not allow the needle to enter the red
sector.

Speedometer

Speed indications are either:

USA - Miles per hour, the outer figures,
and kilometres per hour on the inner ring.

Canada and Mexico - Kilometres per
hour, the outer figures, and miles per hour
on the inner ring.

Odometer

The odometer is displayed in the
message centre unless a message has
priority or a trip computer function has
been selected.

The odometer records the total distance
covered by the vehicle.

The odometer reading is displayed below
the speedometer, along with the trip
distance since it was last reset. To reset
the trip distance, press the reset button
on the trip computer switchpack. The trip
distance will roll-over at
16,090 kilometres (or 9999.9 miles).

JAG0742

Instruments

112

L

Engine temperature

Drive at moderate road and engine
speeds until normal operating
temperature is reached. This is indicated
when the pointer is between the blue
(cold) segment and the red (hot) segment.

The engine operating temperature will
vary with changes in weather and engine
load. The engine temperature may rise in
some circumstances, such as:
• Idling for long periods in slow moving

traffic.

• Driving up a long hill in hot weather.
• Driving slowly or stopping after driving

at high speed.

• Towing a trailer or caravan.

Should the pointer move into the red
segment (H) of the coolant gauge, stop
the vehicle as soon as it is safely possible,
turn off the engine and open the hood to
allow the engine to cool.

Caution: Serious engine damage can
occur if the vehicle is driven whilst the
engine is overheating.

!

WARNING:

The radiator cooling fans may continue
to run after the ignition has been
switched off but will automatically
switch off when the engine has cooled
sufficiently.

!

WARNING:

It is unsafe to run the engine in an
overheated condition.

!

WARNING:

Do not remove the coolant reservoir
filler cap while the engine is hot. If it is
essential, then protect your hands
against escaping steam. SLOWLY turn
the cap counter-clockwise to allow the
steam pressure to escape completely
before removing the cap.
