Jaguar XK. Manual - part 10

Keys and remote controls

CHANGING THE REMOTE
CONTROL BATTERY

Battery renewal

When the battery needs renewing there
will be a significant decrease in the
effective range of the key transmitter and
the message SMART KEY BATTERY
LOW is displayed on the message centre.

To renew the battery, follow the
procedure below:

1. Remove the key blade from the

Jaguar Smart Key. See USING THE
REMOTE CONTROL (page 37).

2. Remove the two side covers, one at a

time, by inserting a small, flat-bladed,
screwdriver between the cover and
body and twist the screwdriver.

3. Insert a small, flat-bladed,

screwdriver between the two body
halves of the remote handset. Apply
light pressure to the screwdriver and
separate the two halves.

4. Remove the printed circuit board,

taking care not to touch the battery
terminals. Remove the old battery
and dispose of it safely.

5. Fit a new battery cell, type CR2032

(available from your Jaguar Dealer),
with the side marked with the positive
symbol (+) downwards in the battery
receptacle. Avoid touching the new
battery as moisture and oil from the
fingers can reduce the life of the
battery and corrode the contacts.

Refit the parts in the reverse order
making sure that they click securely into
place.

PROGRAMMING THE REMOTE
CONTROL

The remote handset, Jaguar Smart Key,
and various features of the vehicle
security system can be programmed to
your individual requirements by use of the
touch-screen.

The programmable features are as
follows:
• drive-away locking

E90710

Keys and remote controls

• central or two stage locking
• sensor override
• window global open or close, passive

entry vehicles only

• valet key mode.

Selecting drive-away locking

From the main Home touch-screen
menu, select Vehicle:

1. Select Veh. settings.

2. The Security button is selected

automatically as the default.

3. Scroll down to - Drive away locking

- and select either On or Off.

Selecting central or two stage
locking

From the main Home touch-screen
menu, select Vehicle:

1. Select Veh. settings.

2. The Security button is selected

automatically as the default.

3. Select: - 2 stage unlock - On or Off.

Valet mode

From the main Home touch-screen
menu, select Vehicle:

1. Select Veh. settings.

2. The Security button is selected

automatically as the default.

3. Select Valet mode.

4. Enter a four digit Personal

Identification Number (PIN)
(personally chosen) by touching the
digit screen pad. On completion
touch the OK button. The screen
indicates that the PIN has been
accepted by displaying Valet on. If
you wish to cancel the PIN, touch the
C button at any time during entering
the number.

Vehicle

Security

Parking

Valet mode

2 stage unlock

Off

Vehicle

Security

Parking

Valet mode

Off

Global close

Off

Global open

Drive away

locking

12 : 26 pm

E93768

Vehicle

Security

Parking

Valet mode

2 stage unlock

Off

12 : 26 pm

E93769

Keys and remote controls

• Using the key blade, lock the glove

box.

• The luggage compartment is now

securely locked in the valet mode.

• On exiting and securing the vehicle,

hand the Jaguar Smart Key, less the
key blade, to the attendant.

Note: Ensure that the emergency key
blade is kept safely at all times.

De-selecting valet mode: When entry
into the vehicle has been gained, access
the Valet mode screen.

1. Enter your four digit PIN and touch

the OK button. The screen will
indicate that your PIN has been
accepted by displaying Valet off.

2. The luggage compartment will return

to the previously set security
requirement.

3. Unlock the glove box using the key

blade.

4. Insert the key blade into the Jaguar

Smart Key.

Note: If the PIN number has been
forgotten, the luggage compartment can
be unlocked by using the key blade in the
luggage compartment lock. This will
cancel the valet mode. See LOCKING
AND UNLOCKING (page 46).

Valet off - enter pin

Vehicle

Security

Parking

Valet mode

12 : 26 pm

E93770

Valet on - enter pin

Vehicle

Security

Parking

Valet mode

12 : 26 pm

E93771

Locks

KEYLESS ENTRY

The Keyless Entry function operates in
the following manner:

1. As a door handle is operated, the

vehicle emits a search signal.

2. As long as the Jaguar Smart Key is

within approximately 1.0m (3 feet 3
inches) of the operated door handle,
the signal will be acknowledged.
• The Jaguar Smart Key requires only

to be on the driver's person or in a
bag or non-metallic briefcase; it
does not require to be exposed or
handled.

3. The vehicle accepts the valid

response and allows access via either
door. The direction indicators will
flash twice (in certain markets two
audible warnings will be emitted).
• You are unlikely to notice a time lag

during this momentary process.

Two stage unlocking: Access to the
vehicle is via the first door handle
operated. The other door can be opened
by releasing the internal door lock or via
operating the exterior door handle with
the Jaguar Smart Key present.

Jaguar Smart Key check

When the last open door is closed, the
vehicle will perform a search of the
vehicle interior for the Jaguar Smart Key.
If one is not found a message SMART
KEY NOT FOUND, PLEASE INSERT IN
SLOT will be displayed for four seconds
on message centre. This is to alert the
driver that the Jaguar Smart Key may
have been inadvertently removed from
the vehicle.

LOCKING AND UNLOCKING

Note: It will not be possible to lock the
vehicle if any door, bonnet or luggage
compartment is ajar or if the inertia switch
has been tripped. See DRIVING AFTER
A COLLISION (page 260). An audible
warning will be emitted.

E90715

WARNING

The door windows partially lower
and raise automatically when the
door is opened and closed. Keep

fingers away from the windows when
closing the door. Closing an electrically
operated window on fingers, hands or
any vulnerable part of the body, can
result in serious injury.
