Parkbrake

128

L

Parkbrake

PARKBRAKE OPERATION

The switch that operates the parkbrake is
mounted on the center console to the rear
of the gear selector.

To engage the parkbrake: Pull the
parkbrake switch upwards and release.
The switch will return to the neutral
position. The parkbrake warning and
brake fluid low warning indicator on the
instrument pack will illuminate.

To disengage the parkbrake: With the
ignition switch in position II or with the
engine running, apply the foot brake
(automatic models only) and press the
parkbrake switch down.

The Drive Away Release feature allows
the parkbrake to release automatically as
the vehicle is driven away.

If the parkbrake is applied while the
vehicle is stationary and D or R is
selected, applying the throttle will
automatically release the parkbrake.

The parkbrake is also automatically
released when the gear selector is moved
from P position.

Inadvertent operation of the parkbrake
while the vehicle is in motion will cause
the message PARKBRAKE ON to be
displayed on the message center,
the warning indicator in the instrument
cluster will be illuminated and a warning
chime will sound.

If the parkbrake is applied while the
vehicle is moving, releasing the switch will
disengage the parkbrake. The parkbrake
cannot be applied while the vehicle is
moving and the throttle pressed.

Note: If the vehicle is in motion, the
parkbrake should only be used as an
emergency brake.

The parkbrake is automatically applied
when the key is removed from the ignition
switch. If you wish to keep the parkbrake
off, press and hold the parkbrake switch
down and, at the same time, remove the
key.

Caution: Take care that the vehicle is
safely parked to prevent it from rolling
if you wish to leave the parkbrake off.

The warning indicator in the instrument
pack will remain on for a short time if the
parkbrake is applied when the ignition
switch is turned to position 0, or if the
ignition key is removed.

If the battery has been discharged or
disconnected a message APPLY
PARKBRAKE will be displayed when the
ignition is next turned on. Depress the
footbrake and pull the parkbrake switch
up to apply the parkbrake. This is required
to reset the parkbrake system. The
parkbrake will now function correctly.

129

Interior Features

R

Interior Features

CENTER CONSOLE

The center console carries the
cupholders, cubby box and armrest.

!

WARNING:

• Do not place hot drinks in the

cupholders while the vehicle is
moving; there is a risk of scalding.

• Use soft cups only.

The sliding armrest is hinged at the rear
and has a release button located on the
front of the armrest.

The chromed button is pulled upwards to
raise the armrest and gain access to the
cubby box. As the armrest is lifted it slides
back under its own weight allowing full
access to the cubby box.

To slide the armrest to expose the two
cupholders, pull the button upwards and
slide the armrest rearwards.

An electrical accessory socket, is located
inside the cubby box. This 12-volt socket
should only be used for the temporary
connection of electrical items, such as a
vacuum cleaner, cool box or to charge a
telephone battery.

The cigar lighter is designed to be used
just to heat the lighter element and not for
providing a power source for accessories.

SUN VISORS AND VANITY
MIRRORS

Adjustable sun visors can be swung
downwards or unclipped and swung
sideways to reduce sun glare.

The sun visors are fitted with illuminated
vanity mirrors, behind a hinged flap. The
lamp comes on when the flap is lifted.

Interior Features

130

L

REAR CENTER ARMREST

To lower the rear center armrest, pull the
loop on the armrest. If not required, raise
the armrest to its upright position and
push firmly into place. Make sure that the
armrest is raised when lowering the seat
back to increase the luggage
compartment area.

There are two cupholders located in the
armrest.

!

WARNING:

• Do not place hot drinks in the

cupholders while the vehicle is
moving; there is a risk of scalding.

• Use only soft cups and cool liquids.

CIGAR LIGHTER

To gain access to the cigar lighter and
ashtray, press the lid at the bottom edge.

To operate the cigar lighter the ignition
must be in position II. Press the lighter in
and wait until the element has heated, it
will then pop-up.

Note: Never hold the lighter knob down.
Do not attempt to remove particles from
the heating element as it is self-cleaning.
The cigar lighter is designed to be used
just to heat the lighter element and not for
providing a power source for accessories.

To empty the ashtray, lift it out vertically
and remove. After emptying, push the
ashtray into the opening until it snaps
back into place.

The cigar lighter is replaced by a 12-volt
accessory socket on certain models.

Passenger door ashtrays (supplied
with smokers pack)

To remove the passenger door ashtray
bin, lift it out vertically and withdraw.

131

Interior Features

R

GLOVE COMPARTMENT

A glove compartment is located below the
passenger’s air bag.

To open the glove compartment, lift the
handle and allow the lid to drop down.
The compartment will be illuminated
when open.

If the compartment is left open, the lamp
will extinguish approximately 40 minutes
after the ignition has been set to
position 0.

The glove compartment can be locked
using the ignition key.

REAR SUN BLIND

The electrically operated rear sun blind is
fitted to the parcel shelf.

Push the switch to raise the sun blind.

To lower the sun blind, push the switch
again.
