103

Message Center

R

FORWARD ALERT OFF None

None

Forward alert feature has been
switched OFF.

!

WARNING:

A warning will not be given for
objects detected in the vehicle
path of travel.

FORWARD ALERT

None

None

Forward alert feature has been
switched ON or the setting
changed. A warning will be given
for objects detected in the
vehicle path of travel. A longer
gap indicates that the system will
warn when detected objects are
further away than the previous
setting.

Message

Warning
Indicator

Priority
Indicator

Meaning

Trip Computer

104

L

Trip Computer

COMPUTER DISPLAY

The computer memory stores data for a
journey, or series of journeys, until it is
reset to zero.

The displayed information is for guidance
only, as it can be affected by traffic, road
and weather conditions.

Two independent memories are available
(A and B) to allow two separate journeys
to be recorded concurrently; for example,
work usage and evening or weekend
usage.

Trip distance, average fuel economy and
average speed will be prefixed A or B
depending on the current memory
selected.

Press the TRIP button on the end of the
left column lever switch repeatedly to
display the data in the following order:
• Trip distance.
• Distance to empty.
• Average fuel consumption.
• Current fuel consumption.
• Average speed.

Odometer

The odometer shows the total vehicle
distance travelled since the vehicle was
new.

When the ignition is switched ON
(position II) the display shows the
odometer and trip distance readings.

The odometer reading is displayed in
either miles or kilometres, depending on
the units selected with the trip computer.

Trip distance (A/B)

Distance travelled since the last memory
reset. The maximum trip reading is 16 090
kilometres (9 999.9 miles). The computer
will automatically reset to zero if this
distance is exceeded.

Distance to empty

Predicted distance, miles or kilometres,
that the vehicle should travel on the
remaining fuel, assuming average fuel
economy and fuel consumption stay
constant.

Average fuel consumption (A/B)

The average fuel consumption, miles per
gallon or litres per 100 kilometres, based
on the accumulated distance travelled
and the accumulated fuel used.

Current fuel consumption

This function shows the instantaneous or
at the moment fuel consumption, which is
continuously updated.

Average speed (A/B)

The average speed since the last press of
the reset button.

105

Trip Computer

R

TRIP COMPUTER
SWITCHPACK

ML/km

Pressing the ML/km switch alternately
displays data in metric or imperial units.

A/B

Selects either A or B trip memory. Select
the required data using the column lever
TRIP button and then pressing A/B will
show the A or B information for that data.

RESET
• One short press clears (hides) the

displayed message. Continue to give
brief presses to clear one message
after another until all messages are
cleared. If a further press is made, all
hidden messages are displayed
again.

• Press and hold for three seconds to

reset or clear the selected trip, A or B,
to zero.

Note: If warning messages are hidden,
the warning or fault still exists and requires
investigation.

Warning and information messages have
priority over trip data and, if active, will be
displayed when the ignition is at
position II.

Display language

To change the display language, switch
the ignition ON while pressing the ML/km
switch. The trip computer will display the
current language.

Press the ML/km switch repeatedly to
cycle through the available languages.
Once the correct language is selected,
press the A/B switch. The new language
will be selected after a delay of three
seconds.

Note: If you wish to exit the language
selection function without changing the
display language, you can either press the
RESET switch and wait for ten seconds or
switch the ignition OFF.

JAG0590

Trip Computer

106

L

SETTING THE TRIP COMPUTER

At the start of the journey (or series of
journeys) to be recorded, reset the
computer memory to zero as follows:

1. Press the TRIP button on the end of

the left column lever switch to select a
trip function. The computer will
display either TRIP A: or TRIP B: data.

2. Press the A/B switch to select the trip

(A or B) to be reset.

3. Press the RESET switch and hold for

three seconds.

The display will read:
RESETTING TRIP A (or B).

Then it will reset and display:
A: 0 (or B: 0) or the new value.

Note: All trip functions for A or B,
depending on which was selected, will be
reset.

CLEARING MESSAGES

Messages can be hidden by pressing
RESET on the trip computer switchpack.
One press will hide one message. Once all
messages have been hidden, the display
will show trip data.

If RESET is pressed again, all active
messages will be re-displayed.
Repeatedly pressing the RESET button
will cycle through the trip and message
modes.

If a fault occurs when in trip computer, the
relevant message will be displayed
immediately.

If a trip computer function is selected by
pressing the TRIP button while messages
are displayed, the trip data will be
displayed for ten seconds then the
message will reappear.

Hidden messages re-appear after an
ignition OFF and ON cycle, if the fault
remains.
