49

Alarm Systems

R

BATTERY RECONNECTION

If the battery has been disconnected and
is subsequently reconnected, the alarm
system will rearm as the battery is
reconnected.

Note: Make sure that a key transmitter is
available to disarm the system when
reconnecting the battery. Either press the
unlock button on the transmitter, or insert
the key in the ignition switch.

REMOTE HEADLIGHT
CONVENIENCE

By pressing the key transmitter button
with the dipped headlamp symbol once,
the headlamps will come on for 25
seconds, unless the headlamp button is
pressed again, or if the key is inserted in
the ignition switch and turned to
position II.

PANIC ALARM

When in or near the vehicle, the panic
alarm can be set off to deter a possible
offender. For this feature to operate, the
key must not be in the ignition switch.

Pressing the headlamp convenience and
panic button on the key transmitter three
times within three seconds will activate
the Panic Alarm.

The alarm is stopped by inserting the key
in the ignition switch or by pressing the
headlamp convenience and panic button
on the key transmitter three times within
three seconds.

Garage Door Opener

50

L

Garage Door Opener

GARAGE DOOR OPENER
TRANSCEIVER

The garage door opener transceiver is
located in the roof console. This
transceiver can be programmed to
transmit the radio frequencies of up to
three different transmitters, which can be
used to activate garage doors, entry
gates, home lighting, security systems, or
other radio frequency operated devices.

Although this section mainly describes
the procedures for a garage door opener,
it also equally applies to the previously
mentioned applications.

In some countries this feature is also
known as the HomeLink® Universal
Transceiver.

The transceiver radio frequency approval
numbers for the USA and Canada are
shown below:

USA - FCC: K8597 R315.

Canada - CAN: 2145 101 790A.

For further information, or for assistance,
contact your Jaguar Dealer, or the
supplier, by phone or via the internet. For
details, see Information and assistance on
page 53.

!

WARNING:

• Do not use the transceiver with any

garage door opener that lacks the
safety stop and reverse feature, as
required by safety standards. A
garage door opener which cannot
detect an object, signalling the
door to stop and reverse, does not
meet current safety standards.
Using a garage door opener
without these features increases
the risk of serious injuries or death.

• When programming the transceiver

to a garage door opener or entry
gate, make sure that people,
vehicles and objects are out of the
way to prevent potential harm or
damage, as the gate or garage door
will activate during the programme.

• This device may suffer from

interference if operated in the
vicinity of a mobile or fixed station
transmitter. This interference is
likely to affect the hand-held
transmitter as well as the in-car
transceiver.

51

Garage Door Opener

R

Before Programming

Caution: When programming a garage
door opener or entry gate, that may
require you to press and re-press the
hand-held transmitter (cycle), unplug
the device during the cycling process
to prevent possible motor failure.

It is recommended that for best results, fit
a new battery to the hand-held transmitter
of the garage door opener (or other
device) before programming. If your
garage door opener receiver (located in
the garage) is equipped with an antenna,
make sure that the antenna is hanging
straight down.

To erase all programming

For first time programming, make sure
that the engine is switched off:

1. Turn the ignition switch to position I.

2. Press and hold the two outer buttons

on the garage door opener in the
overhead console. Keep the buttons
pressed; the indicator lamp will
illuminate. The indicator lamp is part
of the middle button in the garage
door opener in the overhead console.

3. Release the buttons when the lamp

begins to flash (this will take
approximately 20 seconds).

All memories in the garage door opener
have now been cleared.

Note: Do not perform this procedure
when programming the additional garage
door opener buttons.

Programming the vehicle

Making sure that the engine is switched
off:

1. Turn the ignition switch to position I.

2. Hold the end of the original garage

door opener hand-held transmitter
approximately 5.0 to 15.0 cm
(2 to 6 inches) away from the
transceiver in the roof console,
keeping the indicator lamp in view.

3. Using both hands, simultaneously

press and hold both the desired
garage door opener button on the
overhead console and the hand-held
transmitter button. Keep both buttons
pressed. The lamp will flash slowly at
first and then change to a fast flash.
When the indicator lamp flashes
rapidly, release both buttons. The
rapid flashing lamp indicates
successful programming.

Garage Door Opener

52

L

4. If, after 60 seconds, the indicator lamp

does not flash rapidly, release both
the transceiver and the hand-held
transmitter buttons and repeat the
procedure starting with Step 2.
Position the hand-held transmitter at
a different angle and or distance.

5. Press and hold the programmed

overhead console garage door opener
button and observe the indicator
lamp.

• If the indicator lamp is solid or

continuous, programming is complete
and your device should activate when
the garage door opener button is
pressed and held for approximately
one to two seconds and then
released.

• If the indicator lamp blinks rapidly for

two seconds and then turns a solid or
continuous light, proceed with the
following programming instructions
for rolling code device equipment.

Note: To programme additional

garage door opener buttons, begin at
Step 2.

Rolling code device equipment
programming

Note: A second person may make the
following steps quicker and easier, as
once the button has been pressed there
are only 30 seconds in which to complete
Step 3.

1. At the garage door opener receiver

(motor head unit) in the garage, locate
the learn or smart button or switch.

Note: The name of the button or

switch may vary between
manufacturers.

2. Press and release the learn or smart

button.

3. Return to the vehicle and firmly press

and hold the programmed garage
door opener button for two seconds
and release.

4. Repeat the press and hold and

release sequence three times to
complete the training process.

The garage door opener in the overhead
console should now activate the rolling
code device.

Reprogramming a single garage door
opener button

To programme a device to previously
trained button:

1. Press and hold the desired

pre-programmed garage door opener
button for at least 20 seconds, but no
longer than 30 seconds, until the
indicator lamp begins to flash.

2. Without releasing the overhead

console button, position the
hand-held transmitter approximately
5.0 to 15.0 cm (2 to 6 inches) away
from the transceiver in the overhead
console, keeping the indicator lamp in
view.

3. Carry out Step 3 of Programming the

vehicle on page 51.

Entry gate - Canadian programming

The technology of some entry gates
requires you to press and re-press (cycle)
the hand-held transmitter button every
two seconds during programming.

Continue to press and hold the desired
overhead console button while you cycle
your hand-held transmitter, until the
indicator lamp flashes rapidly.
