Jaguar XJ (X350). Manual - part 1401
1
-
Radiator closing panel
2
-
Cowl vent screen
3
-
Secondary bulkhead center panel
4
-
Fender splash shield
5
-
Air deflector (petrol variant)
6
Air deflector (diesel variant)
7
Radiator splash shield
Radiator Closing Panel
The radiator closing panel is fitted to the body by retaining clips and is easily removed to give
access to the rear of the headlamps.
Cowl Vent Screen - Vehicles built up to G45170
An injection molded plastic cowl vent screen is retained to the bodywork by retaining clips.
The cowl vent screen has two access panels and allows easy access to the brake fluid reservoir
and the cabin air filter.
Cowl Vent Screen - Vehicles built from G45171
An injection molded plastic cowl vent screen is retained to the bodywork by retaining clips.
The cowl vent screen has two access panels and allows easy access to the brake fluid
reservoir, the windshield washer reservoir filler neck and the cabin air filter.
Secondary bulkhead center panel
The secondary bulkhead center panel is fitted to prevent engine noise from being transmitted
through the bulkhead into the passenger compartment. It also retains the heat in the engine
bay compartment to maintain engine bay temperatures and to prevent heat bleeding through
into the passenger compartment.
Fender Splash Shield
Protective injection moulded plastic liners are fitted to the inside of the fenders, these help
prevent dirt and water ingress into the vehicle body.
Air Deflector
An air deflector is retained to the front subframe. On the diesel variant the air deflector
incorporates a transmission undertray. The air deflector assists the flow of air under the
vehicle, it also gives protection to the engine bay from dirt and water ingress. On top of the air
deflector an acoustic pad is fitted which is covered by a heat shield, this is designed to reduce
engine, transmission and road noise.
Item Part Number
Description
