-05
Driver inspection bill
Inspect the inner vehicle, outer vehicle
and engine room regularly to keep the
vehicle safe and reliable.
Outer vehicle
淫 Tyre
The expansion is mild (see 野wheel and
tyre冶)
There is no crack on the tyre side and
tyre surface.
There is no foreign matter in the tyre
thread.
淫 Wheel
The bolt and nut are tightened. (See
section VI 野How to Replace the Flat
Tyre冶)
淫 Lamp
All the traveling lamp, headlamp, rear
lamp, width showing lamp, steering sig鄄
nal lamp, stop lamp and fog lamp can
work normally.
淫 Oil fluid
Check the oil level of all the fluid tanks
under the engine cover is suitable.
淫 Windshield wiper of Front wind鄄
screen
Check the state of the wiper arm and
wiper blade (including windshield wiper
of rear window, such as equipment)
Inner vehicle
淫 Steering
Check whether the steering wheel is
over loosened (idling).
淫 Parking brake
Ensure the travel of the control rod of
the parking brake is suitable.
淫 Console
Check whether the operation of the all
the console instruments, control button
and warning lamp is normal.
淫 Rear mirror
Ensure that all the reflecting surfaces of
three rear mirrors are in good condition
and clean.
Check whether all the rear mirrors can
be readjusted.
淫 Controlling
Check whether the clearance between
the brake pedal and the clutch pedal is
suitable.
MO TORS
Notes
Even if th e engine is not running, the
engine cooling fan inside the engine
cabin may be started and cause dam鄄
age to you. So, the hands, dresses and
tools shall be kept away from the fan in鄄
side the engine cabin.
-04
淫 In order to avoid accidental person
damage, turn off the ignition switch and
pull out the key when operating under
the engine cover, unless the mainte鄄
nance procedure requires the engine to
keep running. If the engine must be
kept running when working, take off the
loose coat and take away the jewelries,
otherwise, they will be winded-up at the
moving components and cause dam鄄
age.
Inspecting the inner components of the
engine cabin
Before any inspection of the engine, ex鄄
tinguish the engine and stop the fan
from working to avoid any damage by
the cooling fan.
Besides, the voltage of the electronic
ignition system is higher than that of the
common system, so, touch the live
components of the vehicle is very dan鄄
gerous when the ignition is on.
Notes
If the combustibles fall on the engine
components of high temperature, it may
cause fire. These combustibles include
fuel, oil, coolant, brake fluid, front
windscreen washing solution, etc, and
plastic and rubber. The fire may cause
damage to you and others. So, take
care to avoid the combustibles flatter鄄
ing or falling on the un-cooled engine.
