38
Dual planes
Air is regulated and discharged from the upper air outlet and floor air outlet. The
air out of the floor air outlet is warmer than that from the upper air outlet in the
range of dual planes. But when the temperature control knob is turned to "
Warmest" or "Coldest", the air from the floor air outlet is the same as that from
the upper air outlet.
Bottom air outlet
Air is discharged from the bottom air outlet.
OWNER爷S MANUAL
JAC High end Light Trucks
Bottom air outlet and defroster
Air is discharged from the bottom air outlet, and small part of air is discharged
from the air outlets of defroster and the side window defroster.
Defroster
Air is regulated and discharged from the air outlet of the defroster; small part of
air is discharged from the side-window defrosting air outlet. This position is on鄄
ly recommended for heavy fog and freezing.
39
