1. Switch
2. Instrument panel vent
3. Combined switch handle
4. Steering wheel
5. Instruments
6. Horn button
7. Windshield wiper/cleaner handle
8. Air conditioner switch
9. Ashtray
10援Radio
11援Tea cup holder
12援Manual accelerator knob
13援Ashtray
14. Clutch pedal
15. Brake pedal
16. Accelerator pedal
17. Cigarette lighter
18. Glove compartment
员
2
3
4
5
6
7
9
8
10
11
12
13
16
14
15
18
17
14
OWNER爷S MANUAL
JAC High end Light Trucks
Tachometer
The tachometer indicates the engine 's round per minute. The red zone means
the critical rpm.
When the tachometer hand is in the red zone of the scale plate, driving is not
allowed. If a driver does not stop the vehicle when the tachometer hand is get鄄
ting into the red zone, serious damage will occur to the engine.
Fuel gauge
It indicates the present fuel level in the fuel tank, "F" stands for "Full", and "E"
stands for "Empty".
Fuel tank should be always replenished in time to avoid fuel shortage during
driving.
15
