Engine JAC HFC4DA1-2C. Manual

SUNRAY

SUNRAY Special

Special

Special Service

Service

Service Tools

Tools

Tool

Tool Number

Number

Tool

Tool Name

Name

Illustration

Function/Applied

Function/Applied Part

Part

JAC-T8F013

Cylinder liner puller

For removing cylinder liner (engine)

JAC-T8F014

Piston installer

For installing piston (engine)

JAC-T8F015

Crankshaft front oil

seal installer

For installing crankshaft front oil seal (engine)

JAC-T8F016

Camshaft bushing

puller

For removal/installation of camshaft bushing

(engine)

JAC-T8F017

V-block for camshaft

measurement

For measuring damage of camshaft (engine)

JAC-T8F018

Hose clamp pliers

For removing hose clamp

JAC-T8F019

Piston ring extractor

For removal/installation of piston circlip

(engine)

JAC-T8F020

Valve oil seal

extractor

For removing valve oil seal (engine)

JAC-T8F021

End fork clip

For fixing flywheel (engine)

JAC-T8F022

Crankshaft rear

bearing puller

For removing crankshaft rear bearing

JAC-T8F023

Crankshaft rear

bearing installer

For installing crankshaft rear bearing

JAC-T8F024

Diesel common rail

tool kit

Diesel common rail detector can diagnose
accurately and efficiently the diesel engine
injection by performed diesel common rail
system.

JAC-T8B001

Fork lock pin puller

For removing shift fork spring pin (transmission)
