Engine JAC HFC4DA1-2C. Manual - part 135

BR

BR

BR

BR Brake

Brake

Brake

Brake System

System

System

System

- 60 -

Removal/installation

Removal/installation

Removal/installation

Removal/installation of

of

of

of parking

parking

parking

parking brake

brake

brake

brake lever

lever

lever

lever

Removal
1.

Loosen the parking brake lever.

2.

Remove the wavy dust shield of parking brake.

3.

Remove the parking brake lever assembly:

�

Remove the spring clip and the clevis pin for
fixing cable.

�

Remove the mounting bolts from parking
brake lever.

Installation
4.

Reinstall the parking brake assembly:

�

Tighten the mounting bolts of parking brake
lever.

�

Install the spring clip and the clevis pin for
fixing the main cable.

�

Install the wavy dust shield of parking brake.

BR

BR

BR

BR Brake

Brake

Brake

Brake System

System

System

System

- 61-

Removal/installation

Removal/installation

Removal/installation

Removal/installation of

of

of

of parking

parking

parking

parking brake

brake

brake

brake cable

cable

cable

cable

Removal
1.

Loosen the parking brake lever.

2.

Remove the spring clip and the clevis pin from the
main cable and remove the cable from the parking
brake lever.

3.

Separate the main cable from the equalizer:

�

Remove the spring clip and the clevis pin.

�

Remove the return spring from the equalizer.

4.

Remove the main cable.

Installation

1.

Reinstall all parts in the reverse order of removal.

2.

Regulate the parking brake in accordance with
specification when necessary.

BR

BR

BR

BR Brake

Brake

Brake

Brake System

System

System

System

- 62 -

Replacement

Replacement

Replacement

Replacement of

of

of

of parking

parking

parking

parking brake

brake

brake

brake cable

cable

cable

cable

Removal:

1.

Loosen the parking brake lever.

2.

Remove the main cable from the equalizer:

�

Remove the spring clip and the clevis pin.

�

Remove the return spring from the equalizer.

3.

Remove the rear brake drum.

4.

Remove the rear cable from the brake shoe control
lever.

5.

Remove the rear cable from the brake bottom plate.

6.

Remove the cable from the bracket hook.

Installation

1.

Reinstall all parts in the reverse order of removal.

2.

Regulate the parking brake in accordance with
specification when necessary.

BR

BR

BR

BR Brake

Brake

Brake

Brake System

System

System

System

- 63-

Removal/installation

Removal/installation

Removal/installation

Removal/installation of

of

of

of brake

brake

brake

brake pedal

pedal

pedal

pedal

Removal
1.

Disconnect the negative cable of battery.

2.

Remove the clevis pin and spring clip from the
vacuum booster control rod of brake pedal.

3.

Remove the brake switch:

�

Disconnect the harness connector.

�

Remove the brake switch.

4.

Remove the brake and clutch pedal spider clip from
the pedal bracket.
