PNEUMATIC SYSTEM - BRAKES
45
Base - February 2003
TORQUE
Nm
(kgm)
Rear brakes (Rear axle MS08-125)
Ring nut for securing wheel hub bearings
864.5
± 86.5
(88.1
± 8.8)
Self-locking screw for securing brake calipers
187
± 19
(19
± 1.9)
Screw for securing brake disc to wheel hub
40
± 4
(4
± 0.4)
Brake cylinder securing nut
195
± 15
(19.8
± 1.5)
Screw for securing half-shaft to wheel hub
150
± 15
(15.2
± 1.5)
Wheel securing nut
490
± 50
(49.9
± 5)
Manual unbraking screw
30
+ 6
-
0
3
+ 0.6
-
0
Rear brakes (Rear axles MS10-144; MS10-164)
Brake caliper fastening screw
187
± 19
(19
± 1.9)
Screw fastening the brake disc to the wheel hub
40
± 4
(4
± 0.4)
Screw fastening the axle shaft to the wheel hub
150
± 15
(15
± 1.5)
Wheel hub bearing fastening ring
932
± 98
(93
± 9.8)
Wheel fastening nut
490
± 50
(49.5
± 5)
Rear brakes (Rear axles MS13-165)
Screw fastening the brake disc to the wheel hub
281.5
± 13.5
(28
± 1.3)
Brake caliper support fastening screw
289.5
± 14.5
(29
± 1.5)
Wheel hub bearing fastening ring
932
± 98
(93
± 9.9)
Screw fastening the axle shaft to the wheel hub
262
± 35
(26
± 3.5)
Brake caliper fastening screw
738.5
± 61.5
(74
± 6)
Rear brakes (Rear axles SP145E)
Wheel hub adjusting nut securing ring
392.3
± 20
(40
± 2)
Nut for brake support fastening screw
289.5
± 14.5
(29
± 1.5)
Wheel fastening nut
600
+ 50
-
20
(60
)
+ 5
-
2
Screw fastening the axle shaft to the wheel hub
232.4
± 24.5
(23.2
± 2.4)
