Iveco Daily. Manual - part 315

32786

6

HYDRO-PNEUMATIC SYSTEM - BRAKES

D

AILY

Base - May 2004

DESCRIPTION

SYMBOL

DUMP VALVE

2

1

BRAKE CONTROL VALVE

21

11

22

12

P

A

BRAKE CONTROL VALVE

21

11

BRAKE CONTROL VALVE

21

11

4

22

12

PARKING BRAKE CONTROL VALVE

22

11

21

PARKING BRAKE CONTROL VALVE

2

1

BRAKE VALVE

2

1

CONTROL VALVE

2

1

CONTROL VALVE

22

1

21

RETARDER CONTROL VALVE

23

13

R

SERVO CONTROL VALVE

2

1

4

32787

32786

HYDRO-PNEUMATIC SYSTEM - BRAKES

7

D

AILY

Base - May 2004

DESCRIPTION

SYMBOL

SERVO CONTROL VALVE

2

1

42

41

SERVO CONTROL VALVE FOR
SINGLE LINE

2

1

4

TRAILER BREAKING TRIPLE CONTROL
VALVE

2

1

42

41

43

TRAILER BREAKING TRIPLE CONTROL
VALVE WITH BUILT-IN SERVO
SWITCHING

22

11

42

41

43

12

LOAD PROPORTIONING VALVE

2

1

DUAL LOAD PROPORTIONING
VALVE

21

11

22

12

LOAD PROPORTIONING VALVE
WITH BY-PASS

21

12

11

LOAD PROPORTIONING VALVE
WITH BUILT-IN RELAY

2

1

4

LOAD PROPORTIONING VALVE
WITH BUILT-IN RELAY WITH AIR
CONTROL

4

42

41

1

2

32788

32787

8

HYDRO-PNEUMATIC SYSTEM - BRAKES

D

AILY

Base - May 2004

DESCRIPTION

SYMBOL

LOAD PROPORTIONING VALVE
WITH AIR CONTROL

42

41

1

2

LOAD PROPORTIONING
VALVE WITH AIR CONTROL

1

4

2

PROPORTIONAL REDUCING VALVE

1

2

SLAVED PROPORTIONAL
REDUCING VALVE

1

4

2

SLAVED LIMITING VALVE

1

2

LEVELLING VALVE

1

21

22

LEVELLING VALVE

1

2

HAND OPERATED SUSPENSION
RAISING CONTROL VALVE

11

21

12

23

LEVELLING VALVE WITH
BUILT-IN TRAVEL LIMITER

24

23

21

22

32788

HYDRO-PNEUMATIC SYSTEM - BRAKES

9

D

AILY

Base - May 2004

DESCRIPTION

SYMBOL

PROPORTIONAL CONTROL VALVE

1

2

41

42

HAND OPERATED SUSPENSION
CONTROL VALVE WITH ELECTRICAL
MONITORING

21

11

12

22

13

1

3

ELECTROPNEUMATIC VALVE

1

2

ELECTROPNEUMATIC VALVE

1

2

ELECTROPNEUMATIC VALVE

1

21
22

HYDRAULIC MODULATOR FOR ABS

HL

HR

HZ1

VL

VR

HZ2

ABS

AUGMENTER VALVE

1

4

2
