These pneumatic suspensions show high flexibility and significant
vibration damping. Their main characteristic is that the distance
between chassis and road level, irrespectively of vehicle load,
remains constant due to the effect of the automatic adjustment
of the system.
Electronic-control
pneumatic
suspensions
are
activated
automatically when starting the vehicle.
Electronic-control pneumatic suspensions enable, through the
proper push buttons located in the cab, to change manually the
distance between chassis and road level and therefore the
height of the vehicle load bed.
The following two types of pneumatic suspensions are
currently adopted:
- WABCO pneumatic suspensions for 29L - 35S vehicles
- Streparava pneumatic suspensions for 35C - 40C - 45C -
50C - 60C - 65C vehicles.
PNEUMATIC SUSPENSIONS - WABCO TYPE (for 29L - 35S vehicles)
WABCO system in addition to known advantages offered by
pneumatic suspension, enables the following:
- significant air consumption reduction;
- ready response to the different adjustment processes;
- friendly systems;
- high safety performance;
- complete system diagnostic.
The WABCO system controls automatically the rated level of
vehicle pneumatic suspensions.
The above mentioned operations are bound to preset
operating conditions and to the relevant system safety
requirements.
The ECU controls automatically the chassis level (distance from
road level), through the real values provided by sensors and
compares these values to the rated ones stored in its memory.
If the driving position is changed, the electronic control unit
governs the electro-pneumatic assemblies, by means of which
the actual level is corrected in relation to the nominal level set
or saved by the driver.
Figure 94
62350
84
REAR AIR SUSPENSIONS
D
AILY
E
URO
GENERAL
