Engines Iveco C10,C13, Cursor 10, Cursor 13. Manual - part 39

Diagrams and symbols have been widely used to give a clearer and more immediate illustration of the subject being dealt with, (see
next page) instead of giving descriptions of some operations or procedures.

Example

Ø 1 = housing for connecting rod small end bush

Ø 2 = housing for connecting rod bearings

α

Tighten to torque
Tighten to torque + angular value

1

∅

∅ 2

3

F3B CURSOR ENGINES

SPECIAL REMARKS

4

F3B CURSOR ENGINES

Base - May 2007

Removal
Disconnection

Intake

Refitting
Connection

Exhaust

Removal
Disassembly

Operation

Fitting in place
Assembly

ρ

Compression ratio

Tighten to torque

Tolerance
Weight difference

α

Tighten to torque + angle value

Rolling torque

Press or caulk

Rotation

Regulation
Adjustment

Angle
Angular value

Visual inspection
Fitting position check

Preload

Measurement
Value to find
Check

Number of revolutions

Equipment

Temperature

Surface for machining
Machine finish

bar

Pressure

Interference
Strained assembly

Oversized
Higher than

….

Maximum, peak

Thickness
Clearance

Undersized
Less than

….

Minimum

Lubrication
Damp
Grease

Selection
Classes
Oversizing

Sealant
Adhesive

Temperature < 0

°C

Cold
Winter

Air bleeding

Temperature > 0

°C

Hot
Summer

Replacement
Original spare parts

CORRESPONDENCE BETWEEN TECHNICAL CODE AND COMMERCIAL CODE

SECTION 1 - GENERAL SPECIFICATIONS

3

F3B CURSOR ENGINES

Technical Code

Commercial Code

F3BE0684H*E901
F3BE0684G*E901
F3BE0684J*E902

C13 ENT X

F3BE9687A*E001

C13 ENT X

F3BE9687B*E001
F3BE9687C*E001

LEFT-HAND SIDE VIEW

RIGHT-HAND SIDE VIEW

104768

104769

Figure 1

VIEWS OF ENGINE (FOR TYPES: F3BE0684H*E901 - F3BE0684G*E901)

Figure 2

SECTION 1 - GENERAL SPECIFICATIONS

5

F3B CURSOR ENGINES
