Index Iveco Engines Iveco C10,C13, Cursor 10, Cursor 13 (CURSOR TIER 3 SERIES) - service repair manual 2007 year
|
|
60498 60500 60499 60501 104257 Figure 23 Figure 24 Figure 25 Figure 26 Figure 27 Unscrew the screws (2) and remove the transmission gear (1). Stop the engine flywheel (3) rotation by means of tool Apply the extractor 99340054 (2) and pull out the seal Unscrew the screws (1) and take down the gearbox (2). - Disconnect the electrical connections from the pump injectors from the pump injector solenoid valves. - Unscrew the screws (1) fixing the rocker arm shaft. In sequence, take out the: - idle gear (1); - oil pump gear (2). Figure 28 99364 12 SECTION 3 - INDUSTRIAL APPLICATION CURSOR ENGINES F3A Base - May 2007 |
