6G–8 ENGINE LUBRICATION C. Install crankcase, tighten crankcase fixing bolts to the specified torque. Torque : 10 N·m (89 lb in) 013RW004 2. Install oil pan 1. Remove residual sealant, lubricant and moisture from mounting surface, then dry thoroughly. 2. Properly apply a 4.5 mm (07 in) wide bead of sealant (TB-1207C or equivalent) to mounting D The crankcase must be installed within 5 013RW003 3. Install oil pan, tighten oil pan fixing bolts to the specified torque. Torque : 25 N·m (18 lb ft) 3. Install starter and tighten fixing bolts. Torque: 40 N·m (30 lb ft) 4. Install axle housing assembly and tighten fixing bolts to the specified torque. (For 4 × 4) Axle case bolts 013RW005 5. Install relay lever assembly and tighten fixing bolts. Torque: 44 N·m (32 lb ft) 6. Engage teeth of pitman arm and steering unit, and tighten nut to the specified torque. Torque : 216 N·m (159 lb ft) 013RW006 Legend (1) Pitman Arm |
