4A2–30 DIFFERENTIAL (REAR) D Pressure ring 425RY003 Legend (3) Sliding surface with the friction disc. When nicks or scratches are found, polish with an oil (4) Sliding spherical surface with the pinion gear. –shaped section of the pinion shaft. (7) Fitting section with the case. differential case. Repair burrs and nicks using D Thrust washer 425RS058 Legend (9) Sliding surface with the side gear or case. (10) Peripheral groove of the side gear. Repair light nicks and burrs using an oil stone. D Case 425RS059 Legend (11) Contact surface with the spring disc. (12) Inner groove of the differential cage B. Repair light nicks and burrs using an oil stone. 425RS060 Legend (7) Fitting section with the case. differential case. Repair burrs and nicks using an oil stone. (9) Sliding surface with the side gear or case. (11) Contact surface with spring disc. |
