4C–64 DRIVE SHAFT SYSTEM 2. Install a new needle bearing into inner shaft by using a Installer J–41694 and grip J–8092. 412RS051 3. Place a new snap ring(internal) in inner shaft. Install a new inner shaft bearing into the inner shaft. 412RS044 4. Install snap ring(external). NOTE: Be careful not to damage the inner shaft. 5. Clean the housing contact surface of the front axle case and insert inner shaft assembly into the front NOTE: Be careful not to damage seal. 6. Install snap ring internal in the groove of front axle case. NOTE: Be sure to install the snap ring properly. 412RW017 7. Apply differential gear oil to clutch gear, then install clutch gear. 8. Apply differential gear oil to sleeve, then install sleeve. 9. Clean contact surface with the front axle and actuator mounting surface. Apply liquid gasket to the contact 412RW023 10. Tighten bolts to specified torque. Torque: 75N·m(55 lb ft) 11. Clean the actuator contact surface with the housing then Install and tighten shift position switch to the Torque: 39N·m (29 lb ft) |
