6A–20 ENGINE MECHANICAL (6VD1 3.2L) Installation 1. Install cylinder head cover. D Clean the sealing surface of cylinder head and D Apply sealant (TB-1207B or equivalent) of bead D The cylinder head cover must be installed with in 5 D Tighten bolts to the specified torque. Torque : 9 N·m (78 lb in) 010RW008 2. Install fuel injection harness bracket and tighten bolt to the specified torque. Torque : 9 N·m (78 lb in) 3. Connect ignition coil connector and ignition coil, then tighten bolt to the specified torque. Torque : 4 N·m (35 lb in) 060RY022 Legend (1) Ignition Coil Connector CAUTION: Ignition coil assembly #6 is different 060RY00002 Legend (1) Long Type Ignition Coil Assemblies (# 1 ∼ # 5) (2) Short Type Ignition Coil Assembly (# 6) 4. Connect ground cable and tighten bolts to the specified torque. Torque : 9 N·m (78 lb in) 5. Install positive crankcase ventilation hose. |
