6D3–15 STARTING AND CHARGING SYSTEM Main Data and Specifications General Specifications Model HITACHI GD002350 Rating Voltage 12 V Output 1.4 Kw Time 30 sec Number of teeth of pinion 9 Rotating direction(as viewed from pinion) Clockwise Weight(approx.) 34 N No load characteristics Voltage /Current 11V/90A or less Speed 2700rpm or more Load characteristics Voltage/current 8.4V/250A Torque 7.3N·m(64lb·in.) or more Speed 1200rpm or more Locking characteristics Voltage/current 3V/750A or less Torque 19N·m(14lb·in) or more |
