9A–8 SEAT BELT SYSTEM 760RW025 Legend (1) Rear Seat Belt Upper Anchor Bolt Cover and (2) Quarter Upper Trim Cover (3) Dust Cover (4) Retractor (5) Rear Seat Belt Lower Anchor Bolt Cover and (6) Luggage Side Trim Cover (7) Rear End Floor Trim Cover (8) Rear Seat Belt Assembly Rear Seat Belt and Associated Parts (Short Wheel Base) 1 8 2 3 4 5 6 7 Removal 1. Disconnect the battery ground cable. and anchor bolt (2). 1 2 755RW038 |
